1.6 Relay Outputs
Module Output:
Relay Contact Outputs:
Contact Max. Current:
Isolation
12
Figure 7 RTU300 Relay Connection Diagram
4 Channel
NO(Normally Open) Contact
3A@30VDC – 5A@250VAC
Dry Contact
RTU300 SERIES – HARDWARE MANUAL
