1.9 Serial Ports

1.9.1 RS485 Serial Port
RS485 Port Count:
Maximum Slave Count
Isolation:
Communication Distance:
Data Bits:
Stop Bits:
Parity:
Baudrate:
Figure 10 RTU300 RS485 Serial Port Connection Diagram
15
1 Port, 3 kV ESD Protection
Limited to Hardware
Galvanic and Optical
1000 m
7-8
1-2
None-Even-Odd
300 bps to 200 kbps
RTU300 SERIES – HARDWARE MANUAL
