1.5 Digital Outputs
Module Output:
Module Output Type:
Voltage Range:
Max. Output Current:
Isolation:
Figure 6 RTU300 Digital Output Connection Diagram
11
8 Channel, Mosfet Output
PNP Transistor
12-36V DC
2A @ 30V DC
Optical
RTU300 SERIES – HARDWARE MANUAL
