2.6 Analog Inputs

Module Input:
Analog Input Type:
Analog Input Resolution:
Analog Input Precision:
Common Input GND:
Figure 16 RTU302 Analog Input Connection Diagram
22
8 Channel
0-20 mA, 4-20 mA
16 Bit
%1 Precision
2 GND (8 Point / Common)
RTU300 SERIES – HARDWARE MANUAL
