- Page 1 Product & Installation Manual ® H E AT S T R I P C l a s s i c w i t h R e m o t e ( T H H A - R ) T h e h e a t e r t h a t i s a d e s i g n f e a t u r e !
-
Page 2: Product Overview
Rev B MAR21 ® There are 5 different ranges within the electric HEATSTRIP product category. Each has a different temperature rating making them suited to a variety of applications. Below is a list of some common applications, to assist with the selection of the most effective and efficient series. - Page 3 Efficient, cost effective electric heating ® The innovative design of the HEATSTRIP enables comfortable and even heat dispersion from the surface with minimal operating costs. Design flexibility ® Two HEATSTRIP models are available, ensuring the heating requirements of any undercover outdoor or open indoor area is possible.
- Page 4 ® spot heating in factories, warehouses and showrooms. Within your home, HEATSTRIP can provide comfort heating for undercover alfresco dining and BBQ area, patios, verandas, courtyards and balconies.
- Page 5 Specifications - Australia MODEL POWER CURRENT DIMENSIONS WEIGHT LEAD PLUG (WATTS) (AMPS) (mm) (Kg) LENGTH (mm) 1371 x 165 x 48 THH2400AR 2400 1000 1780 x 165 x 48 THH3200AR 3200 13.3 MODEL HEATER TYPE High intensity electric radiant overhead heater with high surface area profiled alloy OUTPUT Refer to model code chart above...
- Page 6 ® HEATSTRIP is supplied to many international markets, and therefore is available in a range of voltages and ® lead configurations to meet local market approvals. HEATSTRIP is fully compliant to the following international standards. Europe CE, ROHS, IEC 60335-2-30:2002...
- Page 7 Not only are the hourly running costs considerably less with HEATSTRIP , but you never have to worry ® about running out of gas, no refilling, no unattractive gas bottle to waste space; and HEATSTRIP actually im- proves the value of your property.
-
Page 8: Spot Heating Principle
Option 1 and 2 show a comparison between heating an entire area or spot heating over a table. ® The bottom layout shows the flexibility of using HEATSTRIP to provide a comfortable environment, even when the layout of the area is very unusual. -
Page 9: Radiant Footprint
(ie. people), are within the direct radiant footprint of the heater. The diagram to the left shows the radiant ® footprint of HEATSTRIP Classic, and is an approximate guide based on a fully enclosed outdoor environment. -
Page 10: Selection Guide
Selection guide ® General recommendations for HEATSTRIP Classic with remote: • Ideal mounting height: 2.3m to 2.5m. Maximum is 2.7m in a fully protected/enclosed outdoor environment. • Ideal mounting location: ceiling mounted, directly above area to be heated (eg. above a table) •... - Page 11 ® Selections are based on HEATSTRIP Classic with remote being mounted at 2.4m from the floor in a fully enclosed undercov- er outdoor area.
-
Page 12: Installation Requirements
For mounting heights more than 2.7m, we recommend the use of the optional accessories to reduce the height of the ® heater to 2.3m—2.5 m. This will increase the effectiveness of your HEATSTRIP . Refer to the Mounting Accessory section for more information. -
Page 13: Installation Location
Installation location — the diagrams below provide the minimum recommended clearances in mm. WARNING: This heater is not equipped with a device to control the room temperature. Do not use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own, unless constant supervision is provided. -
Page 14: Mounting Options
Mounting options ® Installing the HEATSTRIP Classic with remote is simple and easy using the standard mounting brackets supplied. For other irregular locations there are range of mounting options available - refer to diagrams below ® The HEATSTRIP Classic with remote can be mounted directly to the ceiling, angled downwards on a wall, fitted flush with the ceiling, suspended on chains or poles, attached to beams or poles, or mounted end-to-end. -
Page 15: Standard Mounting Brackets
Standard mounting brackets ® The HEATSTRIP Classic comes with a pair of standard mounting brackets. These adjustable brackets allow direct ceiling or wall mount, and come with preset angle options of parallel, 22.5° and 45°. “X” MODEL MINIMUM DISTANCE (mm) -
Page 16: Flush Mount Enclosure
Flush mount enclosure ® The Flush Mount Enclosure is an ideal way to neatly install the HEATSTRIP into a ceiling. They are available for ® all HEATSTRIP Classic models, and are supplied as a one-piece unit suitable for mounting individual heaters. - Page 17 HEATSTRIP Wall Mounting Kit - (THHAC-028) HEATSTRIP Wall Mounting Kit is an ideal way to install units into hard to mount applications where wall mounting is preferable to direct overhead mounting, applications include heating over tables, lounges, work stations etc. These kits are suitable for all HEATSTRIP Elegance &...
-
Page 18: Suspension Mount Bracket
2.3m—2.5m. The Suspension Mount bracket provides a cheap, easy ® and effective option for lowering the HEATSTRIP Classic from high ceilings. The bracket is designed to be used with chains or wires. There can be multiple chain/wire arrangement options, as per the diagram below. -
Page 19: Extension Mount Bracket
Extension Mount Bracket ® The Extension Mount bracket allows HEATSTRIP Classic units to be lowered from high ceilings using rigid connections. The brackets are designed to be used with 20mm x 1mm round tube (and supplied as a complete kit that attaches to standard mounting brackets supplied with the heater. - Page 20 ® HEATSTRIP Classic with Remote The THHA-R is a custom designed and manufactured heater. It has been designed for ease of use and provide low running cost of your heater. It provides 3 levels of temperature control, Adjustable set timer option from 0-24 hours with the touch of a button.
-
Page 21: Remote Control Operation
Remote Control Operation Receiver is located on the heater. Signal Transmitter LED / control panel • To use the remote controller, aim the transmitter to the heater. A line of sight transmission is required for the unit to function. • The controller does not have a protec- tion rating. -
Page 22: Warranty Terms And Conditions
® Thermofilm warrants to the original owner that HEATSTRIP products will be free from defects in materials and workmanship for a period of 24 months for residential applications and 12 months for commercial applications from the date of purchase in accordance with the following warranty terms and conditions.
