User Manual - TRANSLATION
POLARIS REMOTE
POLARIS Remote KVM Digital
Typ B7-72V2-....
ATEX
Zone 2 and Zone 22
Document no. B1-72V2-7D0002
Revision 2 / Status: May 2020
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.
GmbH
Max-Eyth-Straße 16
Phone: +49 7931 597-0
97980 Bad Mergentheim
Fax: +49 7931 597-119
GERMANY
GmbH
Max-Eyth-Straße 16
Telefon: +49 7931 597-0
97980 Bad Mergentheim
Telefax: +49 7931 597-119
Content
Pages
English
1-45
Support:
Download:
Internet:
Support:
Download:
support-polaris@bartec.de
http://automation.bartec.de
www.bartec.de
support-antares@bartec.de
http://automation.bartec.de
Max-Eyth
97980 Ba
Deutschl
Max-Eyth
97980 Ba
Advertisement
Table of Contents
Related Manuals for Bartec POLARIS Remote
Summary of Contents for Bartec POLARIS Remote
- Page 1 User Manual - TRANSLATION POLARIS REMOTE POLARIS Remote KVM Digital Typ B7-72V2-…. ATEX Zone 2 and Zone 22 Document no. B1-72V2-7D0002 Revision 2 / Status: May 2020 Reservation: Technical data subject to change without notice. Changes, errors and misprints may not be used as a basis for any claim for damages.
- Page 3 POLARIS REMOTE - for Zone 2/22 Table of Contents POLARIS Remote KVM Digital Technical data subject to change. 09/2017...
-
Page 4: Table Of Contents
Technical data............................9 POLARIS Control ........................9 4.1.1 Characteristics POLARIS Remote 15”................ 10 4.1.2 Characteristics POLARIS Remote 15" Sunlight ............10 4.1.3 Characteristics POLARIS Remote 19.1" ..............11 4.1.4 Characteristics POLARIS Remote 17,3" ..............11 4.1.5 Characteristics POLARIS Remote 24" ............... 12 Keyboard .......................... - Page 5 POLARIS REMOTE - for Zone 2/22 Table of Contents POLARIS Remote KVM Digital Terminal compartments ......................26 PE conductor connection ......................27 Terminal compartments X10 ....................28 6.6.1 Cable entries ......................28 6.6.2 Supply voltage terminal assignment) ................28 6.6.3 Terminal Assignment for USB ..................29 6.6.4 Terminal assignment LSA-Plus Terminal (X17-1 to X17-8) ........
- Page 6 POLARIS REMOTE - for Zone 2/22 Table of Contents POLARIS Remote KVM Digital Technical data subject to change. 09/2017...
-
Page 7: Basic Safety Instructions
The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this user manual. -
Page 8: Languages
1.1.2 Changes in the document BARTEC reserves the right to change the content of this document without notification. No warranty is assumed for the correctness of the information. In cases of doubt, the German safety instructions apply because it is not possible to rule out errors of translation or printing. -
Page 9: Unintended Use
POLARIS REMOTE - for Zone 2/22 Basic POLARIS Remote KVM Digital safety instructions 1.3.2 Unintended use Any other use is not in accordance with the intended purpose and can cause damage and accidents. The manufacturer will not be liable for any use beyond that of its "Exclusive II"... -
Page 10: Servicing
1.6.4 Repairs Repairs to explosion-proof equipment may only be performed by persons authorized by BARTEC, who must employ the latest technological practices, observe the manufacturer's instructions and use only original spare parts. The applicable regulations are to be observed here. - Page 11 – human control). BARTEC grants a warranty period of one year on the POLARIS series, starting from the BARTEC delivery date. The warranty period for accessories is 1 year from the date of delivery. This warranty covers all parts of the delivery and is limited to the free-of-charge replacement of or repair of the defective parts by BARTEC.
-
Page 12: Product Description
2. Product description Definition The POLARIS Remote KVM Digital System consists of a remote unit and a local unit. The remote unit is installed internally and the local unit is contained in the scope of delivery. The data are transferred in real time. -
Page 13: Schematic Design
Illustration 1: System design with STP cable up to 130 m 2.2.2 Special Application - Cascade Connection When several POLARIS Remote devices are cascaded, the POLARIS Remote devices are peers in the system. The use of the touch function must be checked in each individual case. -
Page 14: Explosion Protection And Approvals
Explosion protection and POLARIS REMOTE- for Zone 2/22 approvals POLARIS Remote KVM Digital Explosion protection and approvals POLARIS REMOTE KVM Digital Type B7-72V2-…. ATEX Ex protection type II 3G Ex nA IIC T4. II 3D Ex tb IIIC T120° -20 °C ≤ Ta ≤ 60 °C... -
Page 15: Technical Data
POLARIS REMOTE - for Zone 2/22 Technical data POLARIS Remote KVM Digital 4. Technical data POLARIS Control Construction Front panel fitting; Optional turn-key system solutions in a stainless steel enclosure as wall, floor or table mounting versions. Connection to the PC with local unit (plug &... -
Page 16: Characteristics Polaris Remote 15
Wall cut-out 394.5 mm x 315.5 mm + 0.5 mm (width x height) approx. 12 kg Weight 4.1.2 Characteristics POLARIS Remote 15" Sunlight Display 15" graphics-capable TFT display XGA resolution, 1024 x 768 pixels 16.7 million colours Brightness 1000 cd/m Visible surface approx. -
Page 17: Characteristics Polaris Remote 19.1
POLARIS REMOTE - for Zone 2/22 Technical data POLARIS Remote KVM Digital 4.1.3 Characteristics POLARIS Remote 19.1" Display 19.1" graphics-capable TFT display SXGA resolution, 1280 x 1024 pixels 16.7 million colours Brightness 300 cd/m Visible surface approx. 380 x 305 mm... -
Page 18: Characteristics Polaris Remote 24
POLARIS REMOTE- for Zone 2/22 Technical data POLARIS Remote KVM Digital 4.1.5 Characteristics POLARIS Remote 24" Display 24" graphics-capable TFT display WSXGA resolution, 1920 x 1080 pixels 16.7 million colours Brightness 300 cd/m Visible surface approx. 521 x 299 mm... -
Page 19: Keyboard
POLARIS REMOTE - for Zone 2/22 Technical data POLARIS Remote KVM Digital 4.2 Keyboard 4.2.1 Explosion Protection Type B7-72VZ-40.. Ex protection type ATEX II 3G Ex nA IIC Gc II 3D Ex tc IIIC T120°C Dc -20 °C ≤ Ta ≤ +60 °C... -
Page 20: Characteristics Of Enclosure For Mouse And Keyboard
POLARIS REMOTE- for Zone 2/22 Technical data POLARIS Remote KVM Digital 4.2.3 Characteristics of enclosure for mouse and keyboard 05-0041-0277 Bestellnummer Edelstahl 1.4301; AISI 304 Material Abmessungen (Breite x Höhe x Tiefe) 600 mm x 85 mm x 220 mm... -
Page 21: Variants
POLARIS REMOTE - for Zone 2/22 Technical data POLARIS Remote KVM Digital Dimensions (width x height) 130 mm x 170 mm Wall cut out (width x height) 100 mm x 140 mm Dimensions and wall cut-out (mm) 4.3.3 Variants Finger mouse... -
Page 22: Product Labelling
POLARIS REMOTE- for Zone 2/22 Technical data POLARIS Remote KVM Digital Product Labelling Type label with label ATEX Label for Local Unit Warnings on the device Warning on terminal compartment! Teest sticker Technical data subject to change. EN 16/45 05/2020... -
Page 23: Transport, Storage, Scope And Assembly
A written report of any transport damage or missing items must be given to the appointed forwarder and to BARTEC GmbH immediately on receipt of the delivery. Damage caused by incorrect storage and transport shall not fall within the warranty provisions of BARTEC GmbH. -
Page 24: Assembly
Transport, Storage, POLARIS REMOTE- for Zone 2/22 Scope and Assembly POLARIS Remote KVM Digital Assembly Before assembling the device, make sure you have all the components and documents. POLARIS 1 x hex key 3 mm Required (mounting clamps) 1 x slotted screwdriver... -
Page 25: Installation
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital 6. Installation We recommend setting up and testing the entire system before its ultimate installation in the ex-area. If a long connection cable is not available, please use a patch cable to test the basic functions. -
Page 26: Mechanical Installation
POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" Choose the optimum height for operating the POLARIS. – Ensure good lighting conditions for a perfectly legible display – (no direct exposure to the sun’s rays). Do not mount in direct proximity to switching or current changing devices. –... -
Page 27: Installation In 3G-/3D-Enclosure
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital 6.2.1 Installation in 3G-/3D-enclosure In order to guarantee the IP degree of enclosure protection = IP54 for installation in 3G enclosures of protection (e.g. control equipment), and = IP6X for installation in 3D enclosures in areas where combustible dusts exist - with “protection through the enclosure”... -
Page 28: Installation As A System Solution In The Stainless Steel Enclosure "Exclusive Ii
POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" Work steps (1) Insert the POLARIS into the cut-out in the enclosure. (2) From the back, place the reinforcement frame over the POLARIS. (3) Using the M4x12 (2) screws to fasten the mounting clamps (1) to the rear side of the POLARIS and tighten to 1.37 Nm. -
Page 29: Floor Mounting
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital Work steps Prepare supply and data line(s). – Prepare installation on the basis of the drilling template (see illustration 7-9). – Install supply and data line(s) in the base. - Page 30 POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" 6.2.5 Table mounting swivel/tilt (Stainless steel enclosure "Exclusive II") CAUTION Movable enclosure parts on the swivel-mounted enclosure. There is a risk of injury by hands being crushed. 3 people are needed for assembly/disassembly. ...
-
Page 31: Electrical Installation
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital Electrical Installation 6.3.1 Installation guidelines Only qualified personnel, i.e. trained electricians will have the required specialised knowledge to be able to do all the electrical work. Familiarity with and the technically perfect implementation of the safety instructions described in this manual are preconditions for safe installation and commissioning. -
Page 32: Terminal Compartments
POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" Terminal compartments DANGER Sealed locking screw! The device is closed in the factory. The explosion protection is lost if opened, and danger to life exists in an explosive atmosphere! Do not open the locking screw! ... -
Page 33: Pe Conductor Connection
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital PE conductor connection DANGER Death or danger of injury as a result of no PE conductor connection. There is no explosion protection. Equipotential bonding with a core cross-section of at least 4 mm is to be set up for ... -
Page 34: Terminal Compartments X10
POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" Terminal compartments X10 6.6.1 Cable entries When connecting cables and leads to supplies / communications equipment in increased safety protected areas, Ex certified cable entries must be used which are suitable for each type of cable and lead. -
Page 35: Terminal Assignment For Usb
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital Mains Connection Variant DC 24 V Terminal Interface Signal Remarks Supply DC 24 V ± 10 % Supply Neutral Supply Protective earth 6.6.3 Terminal Assignment for USB Only for external keyboard and mouse. -
Page 36: Terminal Assignment Lsa-Plus Terminal (X17-1 To X17-8)
POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" 6.6.4 Terminal assignment LSA-Plus Terminal (X17-1 to X17-8) POLARIS Remote STP-cable RJ45-RJ 45 jack Terminal Colour Signal (T568B colour sequence) X17-8 X17-7 BN/WH X17-6 X17-5 BU/WH X17-4 X17-3 GN/WH X17-2... -
Page 37: Terminal Compartment X1
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital Terminal compartment X1 6.7.1 Cable entries When connecting cables and leads to supplies / communications equipment in the Ex area, Ex certified cable entries must be used which are suitable for the respective type of cable and lead. -
Page 38: Local Unit
6.7.4 STP Cable Connection The POLARIS Remote KVM Digital and the local unit are connected by a CAT 7 cable. Requirements for CAT 7 cable: The cables must be twisted in pairs and shielded in conformance to the EIA/TIA-568 B standard (standard types)! Recommended cable: LAN STP cable CAT.7 4 x 2 x 23 AWG, see Accessories... -
Page 39: Emc (Electromagnetic Compatibility)
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital EMC (Electromagnetic Compatibility) This is a class A unit and can cause radio interference in residential areas; if it does, the owner/managing operator may be required to implement suitable measures and pay for loss or damage. -
Page 40: Back-Up Fuse
6.8.2 Back-up fuse In the DC variant the POLARIS REMOTE is protected internally by a 4-A time-lag fuse and in the AC variant it is protected by a 1.6 A time-lag fuse. Voltage dips or undervoltage can blow the fuse. The fuse may be triggered in the case of voltage dips or undervoltage. -
Page 41: Shielding
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital 6.8.4 Shielding Only cables with braided shielding should be used – (recommended cover density > 80%). Sheet shielding should not be used. – Generally, connection of the shielding at both ends results in optimum damping of –... -
Page 42: Commissioning
POLARIS PROFESSIONAL Inbetriebnahme POLARIS Panel PC Professional 15" bis 24" Single-sided shield connection on the connecting cables: Illustration 11: Example of single-sided shield connection Connection of the shielding at one end only is recommended when there is inadequate equipotential bonding, or none at all. In such cases an electrically isolated power supply unit must be used. -
Page 43: Final Inspection
POLARIS REMOTE - for Zone 2/22 Commissioning POLARIS Remote KVM Digital Final Inspection Check the following requirements before commissioning the device: Only open the terminal compartment with terminals for the supply and data line(s) once it has been ensured that no potentially explosive atmosphere is present and that the power supply has been turned off. -
Page 44: Operation
Follow the instructions in the OSD menu. OSD menu Touch Screen In the POLARIS Remote devices the touch driver is on the CD included in the scope of supply. The touch driver for the respective operating system must be installed on the local server or PC. -
Page 45: Faults And Troubleshooting
Check the power supply connection. / LED on the local unit is red (remote station and local unit) i.e. no communication with the POLARIS Remote device Check the data line and wiring LED on the local unit is orange No monitor connection signal No display (red and green), i.e. -
Page 46: Maintenance, Inspection, Repair
Maintenance, inspection, POLARIS REMOTE- for Zone 2/22 repair POLARIS Remote KVM Digital 10. Maintenance, inspection, repair Only trained and qualified personnel may commission and do maintenance work on the POLARIS! Trained qualified personnel are people who are familiar with the installation, assembly, commissioning and operation of the POLARIS, have been instructed about the risks and have the appropriate qualifications by virtue of the work they do. -
Page 47: Instructions For Repairs
POLARIS REMOTE- for Zone 2/22 Repair, disposal, POLARIS Remote KVM Digital dispatch and packaging 10.3.1 Instructions for Repairs If you wish to send in a defective device for repair, please read the RMA procedure guidance first. Then fill in and sign the RMA (Return Merchandise Authorisation) form and send it to our "Retouren Center". -
Page 48: Accessories, Spare Parts
05-0205-0009 POLARIS 19.1" 05-0205-0010 POLARIS 24" 05-0205-0012 Local unit RJ45 Network box 03-9320-0080 RJ45 Patch cable 03-9609-0010 Accessories/spare parts for POLARIS Remote KVM Digital: Name Order no. Keyboard in respective national language B7-72VZ-40.0 Input devices Mouse B7-72VZ-1000 Trackball B7-72VZ -2000... -
Page 49: Order Numbers
POLARIS REMOTE- for Zone 2/22 Order numbers POLARIS Remote KVM Digital Order numbers Technical data subject to change. EN 43/45 05/2020... -
Page 50: Additional Information
POLARIS REMOTE - for Zone 2/22 Additional information POLARIS Remote KVM Digital 15. Additional information Technical data subject to change. EN 44/45 05/2020... -
Page 51: Declaration Of Conformity
POLARIS REMOTE - for Zone 2/22 Declaration of conformity POLARIS Remote KVM Digital Declaration of conformity All certificates see www.bartec.de Technical data subject to change. EN 45/45 05/2020...
