  • Page 1 POLARIS COMFORT 5.7" up to 12.1" Zone 1/Zone 21 User Manual...
  • Page 3 Reservation: Technical data subject to change without notice. Changes, errors and misprints may not be used as a basis for any claim for damages. Content Pages English 1-57 GmbH Max-Eyth-Straße 16 Phone: +49 7931 597-0 Support: support-polaris@bartec.de 97980 Bad Mergentheim Fax: +49 7931 597-119 Download: http://automation.bartec.de GERMANY Internet: www.bartec.de...

  • Page 4: Table Of Contents

    POLARIS COMFORT - for Zone 1/21 Table of Contents POLARIS Touch Panel 5.7" / 10.4" / 12.1" Basic safety instructions ........................1 Notes on this manual ........................ 1 1.1.1 Languages ........................2 1.1.2 Changes in the document ..................... 2 Handling the product ......................... 2 Intended use ..........................
  • Page 5 Ex i terminal compartment ...................... 33 6.7.1 Connection of Ex i input device to the POLARIS (optional) ........33 6.7.2 Ex i USB interface for BARTEC Ex i memory stick............. 34 6.7.3 Ex d socket (optional) ....................34 6.7.4 Connection of a BARTEC BCS 160 hand scanner (optional) ........
  • Page 6 blank...

  • Page 7: Basic Safety Instructions

    The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this user manual.

  • Page 8: Languages

    1.1.2 Changes in the document BARTEC reserves the right to change the content of this document without notification. No warranty is assumed for the correctness of the information. In cases of doubt, the German safety instructions apply because it is not possible to rule out errors of translation or printing.

  • Page 9: Unintended Use

    POLARIS COMFORT - for Zone 1/21 Basic POLARIS Touch Panel 5.7" / 10.4" / 12.1" safety instructions 1.3.2 Unintended use Any other use is not in accordance with the intended purpose and can cause damage and accidents. The manufacturer will not be liable for any use beyond that of its eclusive intended purpose.

  • Page 10: Servicing

    The device features an explosion protection label, as well as a test certificate. For an explanation of the symbols and information used, see chapter 4 "Technical data". The POLARIS COMFORT series complies with Directive 2014/34/EU on equipment and protective systems intended for use in potentially explosive atmospheres (ATEX Directive).
  • Page 11 BARTEC grants a warranty period of one year on the POLARIS series, starting from the BARTEC delivery date. The warranty period for accessories is 1 year from the date of delivery. This warranty covers all parts of the delivery and is limited to the free-of- charge replacement of or repair of the defective parts by BARTEC.

  • Page 12: Product Description

    Illustration 1: POLARIS COMFORT- Series The POLARIS COMFORT series works with the new generation of BARTEC BMS-Graf- pro 7.x.x.x visualisation software. It has sufficient processing power to comfortably manage all tasks such as image presentation, communication for controlling, and the transfer of projects through Ethernet.

  • Page 13: Schematic Design

    Ethernet, PROFIBUS-DP or serial COM interfaces. A finger mouse, trackball, touchpad and joystick are available as options. Standard assembly of the POLARIS COMFORT series is mounting on the front panel which can be performed quickly and easily. On request we also supply the POLARIS COMFORT series as a turn-key system solution in a stainless steel enclosure for wall and floor mounting.

  • Page 14: Explosion Protection And Approvals

    Explosion protection and POLARIS COMFORT - for Zone 1/21 approvals POLARIS Touch Panel 5.7" / 10.4" / 12.1" Explosion protection and approvals POLARIS COMFORT Type 17-71V1-…. ATEX Ex protection type II 2G Ex eb qb [ib op pr] IIC T4 bzw. II 2G Ex db eb qb [ib op pr] IIC T4 II 2D Ex tb IIIC T120°...
  • Page 15 INMETRO 11/UL-BRHZ-0131X Customs Union Russia (EAC) TC RU C-DE.GB06.B.00334 Korea KTL 14-KB4BO-0258X India CCEs P261984 More test certificates www.bartec.de EU-conformity RoHS-Directive 2011/65/EU Standards in accordance with EN/IEC 61000-6-2:2005 EMC Directive 2014/30/EU EN 61000-6-4:2007 + A1:2011 IEC 61000-6-4:2006 + A1:2010 EN 60529:1991 + A1 2000 + A2 :2013...

  • Page 16: Technical Data

    POLARIS COMFORT - for Zone 1/21 Technical data POLARIS Touch Panel 5.7" / 10.4" / 12.1" Technical data General data Construction Front panel fitting optional turn-key system solutions in a stainless steel enclosure as floor or wall mounting. Computer capacity LX800 Prozessor, 500 MHz Compact Flash 4 GB Operating system...

  • Page 17: Characteristics Polaris Touch Panel 5.7

    POLARIS COMFORT - for Zone 1/21 Technical data POLARIS Touch Panel 5.7" / 10.4" / 12.1" 4.1.1 Characteristics POLARIS Touch Panel 5.7" Display 5.7" graphics-capable TFT colour display VGA resolution , 640 x 480 pixels 262,144 colours Brightness 700 cd/m Visible surface approx.

  • Page 18: Characteristics Polaris Touch Panel 12.1

    IECEx IBE 11.0007X Ex protection type Class I, Zone 1 (A)Ex ib IIC T4; Gb Class II, Zone 21 (A)Ex ib IIIC T120 °C; Db Certification CSA 15.70010166 More test certificates www.bartec.de Technical data subject to change. EN 12/57 06/2017...

  • Page 19: General Data

    POLARIS COMFORT - for Zone 1/21 Technical data POLARIS Touch Panel 5.7" / 10.4" / 12.1" 4.2.2 General data Construction Front panel fitting Material Polyester foil on aluminium sheet (conditionally UV-resistant) Protection class Fingermouse/Joystick/Touchpad IP65 front site Trackball Static IP65 front site Dynamic IP56...

  • Page 20: Ex I Memory Stick

    IECEx IBE 11.0007X Standards IEC 60079-0:2007 Edition: 5 IEC 60079-11:2011-06 Edition: 6 IEC 60079-31:2008 Edition: 1 More test certificates www.bartec.de 4.3.2 General data Product type USB flash drive Storage capacity 4 GB Dimensions approx. 92 mm x 22 mm x 7.2 mm...

  • Page 21: Product Labelling

    POLARIS COMFORT - for Zone 1/21 Technical data POLARIS Touch Panel 5.7" / 10.4" / 12.1" Product labelling Example: Type label with label ATEX and IECEx Type label with label INMETRO Warnings on the device Warning on terminal compartment! depending on the operating system Licence sticker Test sticker Technical data subject to change.

  • Page 22: Transport, Storage, Scope And Assembly

    A written report of any transport damage or missing items must be given to the appointed forwarder and to BARTEC GmbH immediately on receipt of the delivery. Damage caused by incorrect storage and transport shall not fall within the warranty provisions of BARTEC GmbH.

  • Page 23: Assembly

    POLARIS COMFORT - for Zone 1/21 Transport, Storage, POLARIS Touch Panel 5.7" / 10.4" / 12.1" Scope and Assembly Assembly Before assembling the device, make sure you have all the components and documents. POLARIS 1 x hex key 3 mm Required (mounting clamps) 1 x slotted screwdriver...

  • Page 24: Installation

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Installation We recommend setting up and testing the entire system before its ultimate installation in the ex-area. If a long connection cable is not available, please use a patch cable to test the basic functions.

  • Page 25: Mechanical Installation

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Do not mount in direct proximity to switching or current changing devices. − Only install the POLARIS in conjunction with the reinforcement frame in an IP65 −...
  • Page 26 POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" DANGER If there is no reinforcement frame, it will not be possible to maintain the IP protection. There is a risk of fatal injury in an explosive atmosphere! Only use enclosure with at least 2 mm wall thickness.

  • Page 27: Installation As A System Solution In The Stainless Steel Enclosure

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.2.2 Installation as a system solution in the stainless steel enclosure The POLARIS is available as a ready-made system solution in a stainless steel enclosure e.g.

  • Page 28: Floor Mounting Stainless Steel Enclosure

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.2.3 Floor mounting stainless steel enclosure Illustration 8: Base – drilling template base plate 6.2.4 Wall mounting Stainless steel enclosure Illustration 9 Wall mounting – dimensions of mounting straps Technical data subject to change.

  • Page 29: Electrical Installation

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Electrical Installation 6.3.1 Installation guidelines Only qualified personnel, i.e. trained electricians will have the required specialised knowledge to be able to do all the electrical work. Familiarity with and the technically perfect implementation of the safety instructions described in this manual are preconditions for safe installation and commissioning.

  • Page 30: Terminal Compartments

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Terminal compartments DANGER Sealed locking screw! The device is closed in the factory. The explosion protection is lost if opened, and danger to life exists in an explosive atmosphere! Do not open the locking screw! ...

  • Page 31: Pe Conductor Connection

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" PE conductor connection DANGER Death or danger of injury as a result of no PE conductor connection. There is no explosion protection. Equipotential bonding with a core cross-section of at least 4 mm is to be set up for ...

  • Page 32: Ex E Terminal Compartments

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Ex e terminal compartments 6.6.1 Cable entries When connecting cables and leads to supplies / communications equipment in increased safety protected areas, Ex certified cable entries must be used which are suitable for each type of cable and lead.

  • Page 33: Ethernet Terminal Assignment

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.6.3 Ethernet Terminal Assignment Configuration Ethernet 10BaseT Terminal Interface Signal Remarks Ethernet RxD + 100/10 BaseT Receive positive Ethernet RxD - 100/10 BaseT Receive negative Ethernet TxD + 100/10 BaseT Transmit...

  • Page 34: Rs422 Interface

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.6.4 RS422 Interface Configuration RS422 Terminal Interface Signal Remarks Jumper between terminal X17 and Termination X18 for activation of the terminator On/Off resistors Interface COM 1 TxD B (TxD+) Transmission cable Input...

  • Page 35: Bartec Profibus-Dp Interface (Optional)

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.6.5 BARTEC PROFIBUS-DP interface (optional) Configuration PROFIBUS-DP Terminal Interface Signal Remarks not connected not connected Interface COM 1 Termination B2 Bridge for terminating network (B1-B2)

  • Page 36: Tty Interface (Optional)

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.6.6 TTY interface (optional) Configuration TTY Terminal Interface Signal Remarks Not connected Not connected Interface COM 1 Signal ground for receiver Interface COM 1 Cathode Interface COM 1 Anode Interface COM 1...

  • Page 37: Rs232 Interface (Optional)

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.6.7 RS232 interface (optional) Configuration RS232 Terminal Interface Signal Remarks Not connected Not connected Not connected Not connected Not connected Not connected Not connected Interface COM 1 Receive Interface COM 1 Transmit...

  • Page 38: Usb Interface (Optional)

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.6.8 USB interface (optional) Configuration USB Terminal Interface Signal X17 - X22 not connected +5 V Data- USB data signal Data+ USB data signal The individual conductors are colour-coded in a 4-wire USB cable as follows: Touch Panel USB connection Colour...

  • Page 39: Ex I Terminal Compartment

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Ex i terminal compartment DANGER Accessories which have not been approved jeopardise the explosion protection. Danger to life exists in an explosive atmosphere! Only use POLARIS accessories! ...

  • Page 40: Ex I Usb Interface For Bartec Ex I Memory Stick

    Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.7.2 Ex i USB interface for BARTEC Ex i memory stick USB socket, 4-pole, Type A ATTENTION The Ex i interface has not been designed for USB devices with their own power supply.

  • Page 41: Connection Of A Bartec Bcs 160

    55.8 µF The BCS 160 hand scanner series can only be used with the original connection cable from BARTEC. Not compatible is the hand scanner BCS 160 with 1D72D Imager (Typ 17-21BA-M31S/I0000000) Connection cable to BCS 160 Barcode hand scanner (pre-assembled)

  • Page 42: Fibre-Optic Port (Optional)

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.7.1 Fibre-Optic Port (optional) For the fibre-optic transmission a fibre-optic converter is used inside the POLARIS and it converts the Ethernet/IP to fibre-optic signals (Ethernet/IP Ex e connection is not required).

  • Page 43: Emc (Electromagnetic Compatibility)

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" EMC (Electromagnetic Compatibility) This is a class A unit and can cause radio interference in residential areas; if it does, the owner/managing operator may be required to implement suitable measures and pay for loss or damage.

  • Page 44: Back-Up Fuse

    Eska 2 A M 1000A@250VAC We recommend that the POLARIS is secured with a back-up fuse to avoid triggering the internal fuse in the device. The internal fuse can only be replaced by BARTEC. Back-up fuse DC: 2.5 A slow-blowing The I value is to be observed for other versions of the fuses.

  • Page 45: Shielding

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" 6.8.4 Shielding Only cables with braided shielding should be used − (recommended cover density > 80%). Sheet shielding should not be used. − Generally, connection of the shielding at both ends results in optimum damping of −...

  • Page 46: Ethernet

    POLARIS COMFORT - for Zone 1/21 Installation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Single-sided shield connection on the connecting cables: Illustration 13: Example of single-sided shield connection Connection of the shielding at one end only is recommended when there is inadequate equipotential bonding, or none at all.

  • Page 47: Commissioning

    POLARIS COMFORT - for Zone 1/21 Commissioning POLARIS Touch Panel 5.7" / 10.4" / 12.1" Commissioning For electrical systems the relevant installation and operating specifications (e.g. Directives 2014/34/EU, BetrSichV and the applicable national ordinances, IEC 60 079-14 and the DIN VDE 0100 series) must be observed. The operator of an electrical system in a hazardous environment must keep the operating equipment in an orderly condition, operate it correctly, monitor it and do the required maintenance and repairs.
  • Page 48 POLARIS COMFORT - for Zone 1/21 Commissioning POLARIS Touch Panel 5.7" / 10.4" / 12.1" The CF card (4 GB) used is divided into: Partition C Size: approx. 2 GByte boot drive with operating system protected by EWF Partition D Size: approx.

  • Page 49: Network (Ethernet) Setup

    POLARIS COMFORT - for Zone 1/21 Commissioning POLARIS Touch Panel 5.7" / 10.4" / 12.1" Activating the EWF (1) Select "RUN" in the START menu. (2) Enter CMD In the command field. (3) Confirm with "OK". (4) Enter the "ewfmgr c: /enable" command line into the command window.

  • Page 50: Keyboard Settings

    POLARIS COMFORT - for Zone 1/21 Commissioning POLARIS Touch Panel 5.7" / 10.4" / 12.1" To select the function Internet Protocol click (figure 1) on sub item "Properties" – With a < double click > on Internet Protocol (figure 2) the function is started. –...
  • Page 51 POLARIS COMFORT - for Zone 1/21 Commissioning POLARIS Touch Panel 5.7" / 10.4" / 12.1" PS/2 Code zu 49600217 Keycodes Keycodes for Keycodes for Keycodes for Hard-ware definition for level 0 level 1 level 2 level 3 Windows BMS-Graf-pro WinCC flexable Rockwell button lettering...

  • Page 52: Touch Screen

    Scroll-Lock 7.2.4 Touch Screen In the POLARIS with touch screen, the touch screen software is pre-installed already. The touch screen software is available for download under http://automation.bartec.de Calibration Open the program by clicking on – Start> All programs> UPDD> Calibrate.

  • Page 53: Operation

    POLARIS COMFORT - for Zone 1/21 Operation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Operation The device can be put into operation after the final check has been made. The POLARIS series does not have any ON/OFF switch. Operating System The POLARIS series are fully pre-installed with the Windows XP Embedded operating systems.
  • Page 54 - for Zone 1/21 Operation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Transfer of the BMS-Graf-pro project data from the BARTEC USB stick to the POLARIS Insert the BARTEC USB stick (containing BMS-Graf-pro) into the intrinsically safe  USB port and start the transfer The BMS-Graf-Runtime starts automatically if the project was transferred ...

  • Page 55: Recovery/Backup Function

    The recovery stick image for the POLARIS Touch Panel can be found on the POLARIS type label. Addition z. B. Built 384 The POLARIS can be restored to the original state only with the BARTEC recovery stick or BARTEC recovery stick image. 8.3.2 Backup We expressly point out that it is the user´s responsibility to make a backup of the...

  • Page 56: Faults And Troubleshooting

    Return to manufacturer. The backlighting is coming to the Dark background end of its service life. Replace the backlighting. Check if the BARTEC Ex i memory Wrong USB flash drive (stick) used. stick is being used. Project cannot be transferred with the See user manual for BMS-Graf pro USB stick.

  • Page 57: Maintenance, Inspection, Repair

    POLARIS COMFORT - for Zone 1/21 Maintenance, inspection, POLARIS Touch Panel 5.7" / 10.4" / 12.1" repair Maintenance, inspection, repair Only trained and qualified personnel may commission and do maintenance work on the POLARIS! Trained qualified personnel are people who are familiar with the installation, assembly, commissioning and operation of the POLARIS, have been instructed about the risks and have the appropriate qualifications by virtue of the work they do.

  • Page 58: Instructions For Repairs

    If you wish to send in a defective device for repair, please read the RMA procedure guidance first. Then fill in and sign the RMA (Return Merchandise Authorisation) form and send it to our "Retouren Center". E-Mail: services@bartec.de Fax: +49 7931 597-119 We cannot guarantee any contractually agreed processing times for devices that are sent in without an RMA number.

  • Page 59: Accessories, Spare Parts

    POLARIS COMFORT - for Zone 1/21 Accessories, spare parts POLARIS Touch Panel 5.7" / 10.4" / 12.1" Accessories, spare parts Included in the scope of the delivery: Name Order no. POLARIS Touch Panel with Windows® XP Embedded Driver for Mainboard and Touch Mounting clamps Reinforcement frame POLARIS 5.7"...

  • Page 60: Order Numbers

    POLARIS COMFORT - for Zone 1/21 Order numbers POLARIS Touch Panel 5.7" / 10.4" / 12.1" Order numbers POLARIS Touch Panel 5.7" POLARIS Touch Panel 10.4" POLARIS Touch Panel 12.1" Technical data subject to change. EN 54/57 06/2017...

  • Page 61: Additional Information

    POLARIS COMFORT - for Zone 1/21 Additional infromation POLARIS Touch Panel 5.7" / 10.4" / 12.1" Additional information Technical data subject to change. EN 55/57 06/2017...

  • Page 62: 16. Declaration Of Conformity

    POLARIS COMFORT - for Zone 1/21 Declaration of conformity POLARIS Touch Panel 5.7" / 10.4" / 12.1" 16. Declaration of conformity Technical data subject to change. EN 56/57 06/2017...
  • Page 63 POLARIS COMFORT - for Zone 1/21 Declaration of conformity POLARIS Touch Panel 5.7" / 10.4" / 12.1" All certificates see www.bartec.de Technical data subject to change. EN 57/57 06/2017...
  • Page 64 Your partner for safety technology. Challenge us! BARTEC GmbH Max-Eyth-Str. 16 97980 Bad Mergentheim Germany Phone: +49 7931 597-0 info@bartec.de www.bartec.de...
