User Manual - TRANSLATION
POLARIS Remote Digital
POLARIS II Remote 24"/ Remote 22"/ Remote 19.1"
Type 17-72V5-....
ATEX Zone 2
ATEX Zone 21/Zone 22
Document No.
May, 2019
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.
GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
Germany
Contents
English
Phone: +49 7931 597-0
Fax:
+49 7931 597-119
Page
1 - 45
Contact:
support-polaris@bartec.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bartec POLARIS Remote
Summary of Contents for Bartec POLARIS Remote
- Page 1 User Manual - TRANSLATION POLARIS Remote Digital POLARIS II Remote 24”/ Remote 22"/ Remote 19.1" Type 17-72V5-…. ATEX Zone 2 ATEX Zone 21/Zone 22 Document No. May, 2019 Reservation: Technical data subject to change without notice. Changes, errors and misprints may not be used as a basis for any claim for damages.
-
Page 3: Table Of Contents
Technical Data ............................. 8 General data ....................... 8 4.1.1 Characteristics POLARIS Remote KVM Digital 19,1" ........9 4.1.2 Characteristics POLARIS Remote KVM Digital PC 22" ........9 4.1.3 Characteristics POLARIS Remote KVM Digital PC 24" ......... 10 4.1.4 Technical data Keyboard ................11 4.1.5 Heating (Optional) for Version up to -20°C ............ - Page 4 POLARIS Remote Table of Contents POLARIS II Remote Digital 6.4.1 POLARIS Junction Box ................. 22 6.4.2 Terminal assignment X1 ................22 6.4.3 Terminal assignment X1 with Heating HCS (optional) ........23 6.4.4 Terminal assignment X2 (RJ45 Connector)........... 24 6.4.5 Technical Data Local Unit ................24 6.4.6 Properties of Local Unit .................
- Page 5 - blank -...
-
Page 7: Basic Safety Instructions
They are not necessarily true to scale and may deviate slightly from the actual construction of the device. The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this user manual. -
Page 8: Languages
In case of doubt, the German safety instructions shall apply because it is not possible to rule out errors in translation or in printing. In the event of a legal dispute, the “General Terms and Conditions” of the BARTEC group shall apply in addition. -
Page 9: Improper Use
POLARIS Remote Basic POLARIS II Remote Digital Safety Instructions 1.3.2 Improper Use Any other use is not in accordance with the intended purpose and can cause damage and accidents. The manufacturer will not be liable for any use beyond that of its exclusive intended purpose. -
Page 10: Maintenance
Basic POLARIS Remote Safety Instructions POLARIS II Remote Digital 1.5.2 Maintenance Regular servicing is not necessary if the equipment is operated correctly in accordance with the installation instructions and environmental conditions. In this context, please refer to Chapter "Maintenance, Inspection, Repair". -
Page 11: Warranty
We guarantee the POLARIS and its accessories for a period of 1 year starting from the BARTEC delivery date. This guarantee covers all parts of the delivery and is restricted to the replacement free of charge or the repair of the defective parts in our Bad Mergentheim factory. -
Page 12: Product Description
Illustration 2: e.g. local unit with STP cable The POLARIS Remote KVM Digital series is optimised for signals such as DVII/HDMI and USB. A local monitor can be connected via "HDMI Out". The touch screen is connected via USB. -
Page 13: Schematic Design
POLARIS Remote Technical Data POLARIS II Remote Digital Schematic design Local Unit Illustration 3: Simple system structure Explosion protection and approvals Explosion protection POLARIS II Panel PC Typ 17-72V4-**** ATEX Ex protection II 3G Ex nA ic IIC T5 Gc... -
Page 14: Technical Data
USB for Keyboard, Mouse & Touchscreen (Local Unit) Extension by means of an STP/S 4x2x23 AWG Conductor length up to 100 m POLARIS Remote II Terminal for Power Optional USB for keyboard & mouse STP Cable directly with RJ45 Rated voltage... -
Page 15: Characteristics Polaris Remote Kvm Digital 19,1
With Mounting adapter and keyboard 730 mm x 520 mm x 400 mm Masse ca. 17 kg 4.1.2 Characteristics POLARIS Remote KVM Digital PC 22" Display 22" graphics-capable TFT display WXGA resolution 1.680 x 1.050 pixels 16.7 million colours Brightness 300 cd/m Visible surface approx. -
Page 16: Characteristics Polaris Remote Kvm Digital Pc 24
POLARIS Remote Technical Data POLARIS II Remote Digital 4.1.3 Characteristics POLARIS Remote KVM Digital PC 24" Display 24" graphics-capable TFT display Full HD resolution 1.920 x 1.080 pixels 16.7 million colours Brightness 300 cd/m Visible surface approx. 531 x 299 mm... -
Page 17: Technical Data Keyboard
POLARIS Remote Technical Data POLARIS II Remote Digital 4.1.4 Technical data Keyboard Keyboard with integrated Touchpad Variants Keyboard with Trackball 38 mm Keyboard with Trackball 50 mm Material (conditionally UV-resistant) Polyester foil of Aluminium plate mounted in stainless steel enclosure... -
Page 18: Heating (Optional) For Version Up To -20°C
POLARIS Remote Technical Data POLARIS II Remote Digital 4.1.5 Heating (Optional) for Version up to -20°C Type HCS 40 Ex protection type II 2G Ex db IIC T4 II 2D td IIIC T135°C Product marking Certification PTB 03 ATEX 1139 X... -
Page 19: Product Labelling
POLARIS Remote Technical Data POLARIS II Remote Digital Product Labelling Type label example Technical data subject to change without notice. 13/37 07/2018... -
Page 20: Transport And Assembly
A written report of any transport damage or missing items must be given to the appointed forwarder and to BARTEC GmbH immediately on receipt of the delivery. BARTEC GmbH’s warranty conditions do not cover damage caused by incorrect storage. Required Tools:... -
Page 21: Installation
POLARIS Remote Technical Data POLARIS II Remote Digital Installation We recommend setting up the complete system under laboratory conditions and testing it before it is permanently installed. If a long connection cable is not available, please use a patch cable to test the basic functions. -
Page 22: Mechanical Installation
POLARIS Remote Technical Data POLARIS II Remote Digital Mechanical installation The POLARIS units will be delivered ready for use inside a rotable/tiltable stainless steel enclosure which can be mounted at different carry systems for Floor, Wall or Table mounting. CAUTION This device is heavy (approx .17 kg). -
Page 23: Floor Mounting
POLARIS Remote Technical Data POLARIS II Remote Digital 6.2.1 Floor mounting Illustration 4: Drilling pattern - supporting system for floor mounting 6.2.2 Wall mounting Illustration 5: Drilling pattern - supporting system for wall mounting Technical data subject to change without notice. -
Page 24: Rotating/ Inclining
POLARIS Remote Technical Data POLARIS II Remote Digital 6.2.3 Table mounting Illustration 6: Drilling pattern - supporting system for table mounting 6.2.4 Rotating/ Inclining Rotating The POLARIS is fixed using two side T screws. The angle of rotation can be changed once the screws have been loosened... -
Page 25: Electrical Installation
POLARIS Remote Technical Data POLARIS II Remote Digital Electrical Installation 6.3.1 Installation guidelines Only qualified personnel, i.e. trained electricians will have the required specialised knowledge to be able to do all the electrical work. Familiarity with and the technically perfect implementation of the safety instructions described in this manual are preconditions for safe installation and commissioning. -
Page 26: Pe Conductor Connection
POLARIS Remote Technical Data POLARIS II Remote Digital 6.3.2 PE conductor connection DANGER Death or danger of injury as a result of no PE conductor connection. There is no explosion protection. Equipotential bonding with a core cross-section of at least 4 mm is to be set up for the POLARIS (see Figure). -
Page 27: Junction Box
POLARIS Remote Technical Data POLARIS II Remote Digital Junction Box DANGER Non-certified cable glands and non-sealed cable entries endanger the IP protection and accordingly the protection against explosions. There is a risk of fatal injury in an explosive atmosphere! Use Ex-certified cable glands. -
Page 28: Polaris Junction Box
POLARIS Remote Technical Data POLARIS II Remote Digital 6.4.1 POLARIS Junction Box Illustration 9: POLARIS II junction box 6.4.2 Terminal assignment X1 Interface AC/DC Signal Description X1-1 Supply Internal protective, protective earth X1-2 Supply L1/+ AC 230 V ± 10 %/ DC 24 V ± 10 %... -
Page 29: Terminal Assignment X1 With Heating Hcs (Optional)
POLARIS Remote Technical Data POLARIS II Remote Digital 6.4.3 Terminal assignment X1 with Heating HCS (optional) Terminal Interface AC/DC Signal Description X1-1 Supply Internal protective, protective earth X1-2 Supply L1/+ AC 230 V ± 10 % or DC 24 V ± 10 %... -
Page 30: Terminal Assignment X2 (Rj45 Connector)
POLARIS Remote Technical Data POLARIS II Remote Digital 6.4.4 Terminal assignment X2 (RJ45 Connector) For Dataconnection Local Unit For the POLARIS II Digital we are using the following KVM. Please read the attached Manual of the Manufacturer carefully and also observe the warnings given by the Manufacturer. -
Page 31: Establishing The Lan Connection
POLARIS Remote Technical Data POLARIS II Remote Digital 6.4.8 Establishing the LAN connection Two RJ45 connectors for customer assembly are enclosed for the connection. Illustration 12: RJ 45-plug For an Ethernet connection, observe the instructions in Chapter 4.5 "EMC". Assembly The plug connector can be used for cables with an external diameter of 4.5...8.0 mm... -
Page 32: Terminal Assignment In Conformance To T568B
POLARIS Remote Technical Data POLARIS II Remote Digital Use a small diagonal cutter to cut the core wires (see illustration). Establish core contact by pressing the terminal (10) blocks together (see fig.) It is also possible to use standard pliers as an aid. -
Page 33: Emc (Electromagnetic Compatibility)
POLARIS Remote Technical Data POLARIS II Remote Digital EMC (Electromagnetic Compatibility) 6.5.1 Note This is a class A unit and can cause radio interference in residential areas; if it does, the owner/managing operator may be required to implement suitable measures and pay for loss or damage. -
Page 34: Back-Up Fuse
PE/PA. 6.5.3 Back-up fuse We recommend protecting the POLARIS with an upstream fuse to prevent blowing the fuse inside the device. Only BARTEC can change the internal fuse. Upstream fuse for AC: 5 AT DC: 5 AT 6.5.4... -
Page 35: Connection Of Shielding
POLARIS Remote Technical Data POLARIS II Remote Digital 6.5.6 Connection of shielding A low impedance connection to the circuit protective conductor is important to ensure a low current fault path. When sub-D connectors are used, the shielding should always be connected to the metal casing of the sub-D plug. - Page 36 POLARIS Remote Technical Data POLARIS II Remote Digital Connection of the shielding at one end only is recommended when there is inadequate equipotential bonding, or none at all. In such cases an electrically isolated power supply unit must be used. Before the equipment goes into service the directions from the controller manufacturer regarding proper assembly and operation must be read carefully.
-
Page 37: Commissioning
POLARIS Remote Technical Data POLARIS II Remote Digital Commissioning For electrical systems the relevant installation and operating specifications (e.g. Directives 99/92/EC and 94/9/EC, BetrSichV and the applicable national ordinances, IEC 60 079-14 and the DIN VDE 0100 series) must be observed. -
Page 38: Operation
POLARIS Remote Operation POLARIS II Remote Digital Operation Once the final inspection has been carried out, the device can be put into operation. The POLARIS series does not have any ON/OFF switch. An external power switch is used to turn the device on and off. -
Page 39: Troubleshooting
Check the power supply connection. / LED on the local unit is red (remote station and local unit) i.e. no communication with the POLARIS Remote device Check the data line and wiring LED on the local unit is orange No monitor connection signal No display (red and green), i.e. -
Page 40: Maintenance, Inspection, Repair
POLARIS Remote Maintenance, Inspection POLARIS II Remote Digital Repair Maintenance, Inspection, Repair Only trained and qualified personnel may commission and do maintenance work on the POLARIS! Trained qualified personnel are people who are familiar with the installation, assembly, commissioning and operation of the POLARIS, have been instructed about the risks and have the appropriate qualifications by virtue of the work they do. -
Page 41: 10.3.1 Instructions For Repairs
POLARIS Remote Accessories Spare Parts POLARIS II Remote Digital 10.3.1 Instructions for Repairs If you wish to send in a defective device for repair, please read the RMA procedure guidance first. Then fill in and sign the RMA (Return Merchandise Authorisation) form and send it to our "Retouren Center". -
Page 42: Accessories, Spare Parts
Repair, Disposal, POLARIS Remote Dispatch, Packaging POLARIS II Remote Digital Accessories, Spare Parts Keyboard including stainless steel enclosure Keyboard with integrated trackball 38 mm On request Keyboard with integrated trackball 50 mm Keyboard with integrated touchpad Stand for floor mounting Material: Stainless steel DIN 1.4301... -
Page 43: Order Numbers
POLARIS Remote Order Numbers POLARIS II Remote Digital Order Numbers 14.1.1 Order Numbers Code Code Code Code Version POLARIS II Remote 19” Without Touchscreen Trackball German 50 mm POLARIS II Remote 19” AC 90 to 253 V With Touchscreen POLARIS II Remote 22”... -
Page 44: Additional Information
POLARIS Remote Additional Information POLARIS II Remote Digital Additional Information Technical data subject to change without notice. 38/37 04/2012... -
Page 45: Eu Declaration Of Conformity
EU Declaration of conformity...
