- Page 1 INSTRUCTION MANUAL Video Interface and Wireless Carplay & Wired Android Auto MASERATI TD MASERATI INTERFACE DATA. 2021.10.01 CONTACT W kaptrader.com E kap@kaptrader.com A (05854) A-912 RM Tera-tower2, 201 Songpa-Dearo, Songpa-gu, Seoul, Korea F (+82) 6204 - 0913...
- Page 2 INSTRUCTION MANUAL CAR COMPATIBILITY SHEET BRAND MODEL YEAR Quattroporte 2009 ~ 2013 MASERATI GranTurismo 2009 GranTurismo MC...
- Page 3 INSTRUCTION MANUAL COMPONENT INTERFACE POWER CABLE RGB NAVI CABLE MODE SWITCH OSD BOARD LVDS CONNECTOR LVDS OUT CABLE LVDS IN CABLE Touch Cable 7.0˝ Capacitive Touch Screen Touch Board ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing.
- Page 4 INSTRUCTION MANUAL COMPONENT KPLAY KPLAY Power Cable HDMI Cable Wifi/Bluetooth Antenna AUX Cable ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing. ...
- Page 5 INSTRUCTION MANUAL INTERFACE SPEC KPLAY INPUT • Wireless APPLE CARPLAY • Wired APPLE CARPLAY • Wired ANDROID AUTO • USB storage media INPUT • 1 x Digital RGB Input (Navigation System source) • 1 x Analog RGB Input (Navigation System output) •...
- Page 6 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS LCD OUT LCD IN PROGRAM DIP SWITCH OSD connection IMAGE Interface error check POWER/CAN DIGITAL RGB RESISTIVE TOUCH ALNALOG RGB 4PIN Touch FRONT REAR CAPACITIVE TOUCH FRONT CAMERA IN REAR CAMERA IN ...
-
Page 7: Dip Switch Setting
INSTRUCTION MANUAL DIP SWITCH SETTING INFORMATION FUNCTION ▲ OFF ▼ ON NAVIGATION Not use AV1 (DVB-T) Not use AV2 (DVD) Not use No function Quattroporte 2009 ~ 2013 GranTurismo 2009 Car Type GranTurismo MC... -
Page 8: Connector Pin Assignment
INSTRUCTION MANUAL CONNECTOR PIN ASSIGNMENT PORT INFORMATION Color Signal Assignment Color Signal Assignment POWER Brown REAR DET Blue FRONT DET /CAN Green CAN1-L Brown CAN1-H REAR VCC FRONT VCC Green MODE Black Black Color Signal Assignment TOUCH Green Blue White Color Signal Assignment R DATA... - Page 9 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS DIP SWITCH DIGITAL POWER MICROPHONE RESISTIVE TOUCH SPEAKER Smartphone 4PIN Touch USB storage WIFI/BLUETOOTH ANTENNA...
- Page 10 INSTRUCTION MANUAL KPLAY CONNECTOR PIN ASSIGNMENT PORT INFORMATION FUNCTION 800x480 Resolution SWITCH 1280x480 Resolution ▶ Warning DIP switch No. 2 has no function POWER Color Signal Assignment Black Color Signal Assignment TOUCH Black Green White...
- Page 11 INSTRUCTION MANUAL KPLAY CONTROL MAIN SCREEN APPLE CARPLAY ANDROID AUTO USB MEDIA SETTINGS Wireless Cable VIDEO Cable MUSIC IMAGE Apple CarPlay – 800 x 480 Android AUTO – 800 x 480 Apple CarPlay – 1280 x 480 Android AUTO –...
- Page 12 INSTRUCTION MANUAL KPLAY CONTROL Apple Carplay Voice Control (Siri) Home Press Long...
- Page 13 INSTRUCTION MANUAL KPLAY CONTROL SETTINGS INFORMATION SELECTION FUNCTION Language Languages You can change the language of the settings screen settings Automatically launch Android AUTO or Apple CarPlay Activation Auto Phone when smartphone is connected Connect (Only for wired Charge only when connecting a smartphone, select icon Disabled connection) to launch Android AUTO or Apple CarPlay...
- Page 14 INSTRUCTION MANUAL KPLAY CONTROL MEDIA CONTROL POWER DIGITAL DIP_S/W ANDROID AUTO APPLE CARPLAY KPLAY Smartphone connection TOUCH Connect AUX to your car and use KPLAY's microphone USB Media INFORMATION Can be used CONTROL NOTICE Wireless connection Use all Apple Apple CarPlay CarPlay Functions Cable...
- Page 15 INSTRUCTION MANUAL KPLAY CONTROL iPhone Wireless connection - Connection method In KPLAY on iPhone 1. Activate Wireless Carplay in KPLAY Settings 2. Choose CarPlay-BT in Bluetooth on iPhone Menu (If Wireless Carplay is enabled, you cannot connect by wire) on iPhone on iPhone 3.
- Page 16 INSTRUCTION MANUAL KPLAY CONTROL If your iPhone fails to connect Make sure Siri is active 2. Delete the Bluetooth and CarPlay records as shown below, 3. disable and re-enable WiFi and Bluetooth, then try to connect again. Forget Bluetooth history Forget CarPlay History ▶...
- Page 17 INSTRUCTION MANUAL KPLAY CONTROL If your Android Phone fails to connect Check if your smartphone has ANDROID AUTO application 2. Replace the cable ANDROID AUTO APP Download Changing the cable ▶ Warning Android Auto may not run even if the cable is not broken ...
-
Page 18: Firmware Update
INSTRUCTION MANUAL FIRMWARE UPDATE 1. Add the firmware file provided in root folder Root folder * of the USB firmware files *Root folder : Top-level folder without adding folder 2. Connect USB to the KPLAY board with the update file. The USB media will be scanned automatically Press the Home button on the top right corner of the USB Media screen and select... -
Page 19: Button Control
INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen BUTTON PRESS FUNCTION OEM screen to interface screen Press Interface screen to the OEM screen CALL ▶ Screen change sequence : OEM > NAVI > AV1 > AV2 > OEM ▶ Warning To use the steering wheel button, "SteeringWheelBtn"... -
Page 20: Gesture Control
INSTRUCTION MANUAL GESTURE CONTROL Change Mode to Interface Screen INTERFACE INTERFACE GESTURE FUNCTION Swipe left Interface screen ▶ OEM screen Swipe Swipe right OEM screen ▶ Interface screen ▶ Warning To use gesture , "Gesture" must be "ON" in the OSD menu ... - Page 21 INSTRUCTION MANUAL HOME ICON CONTROL Change Mode to OEM Screen BUTTON PRESS FUNCTION Return Touch Interface screen to the OEM screen ▶ Warning To use the icon, “HomeICon" must be "ON" in the OSD menu ...
-
Page 22: Touch Control
INSTRUCTION MANUAL TOUCH CONTROL Connecting a Capacitive Touch C-TOUCH Capacitive Touch Screen Touch Cable Touch Board ▶ Warning When connecting the capacitive touch board, the cable must be properly oriented After completing the connection, you need to do "Calibration" in the OSD menu ... - Page 23 INSTRUCTION MANUAL TOUCH CONTROL Touch Calibration Select OSD menu> Utility> Calibration. MENU Config NAVI Factory Reset Execute Cancel IR-Ctrl Calibration Execute Cancel Utility Version Interface version Press and hold the display for longer than 10 seconds. On interface Screen (NAVI, AV1, AV2) + Touch according to the shape coordinates ▶...
- Page 24 INSTRUCTION MANUAL INSTALL MANUAL KPLAY Connection – Screen Setting 2 3 4 5 6 7 8 OSD Board Control DIP switch No.1 is OFF PROGRAM MASERATI TD VIDEO INTERFACE DIGITAL DIGITAL-KPLAY If " " cannot be found, set to DIGITAL...
- Page 25 INSTRUCTION MANUAL INSTALL MANUAL KPLAY Connection – Touch Setting PROGRAM MASERATI TD VIDEO INTERFACE DIGITAL HDMI CABLE Connected via HDMI cable OSD Board Control UART TOUCH Setting UART Setting (In Interface OSD MENU) Touch Cursor To Calibrate TOUCH CALIBRATION (IN KPLAY)
-
Page 26: Can Connection
9. N.C 8. N.C 7. N.C CAN-H (Orange) CAN-L (Green) 4. Front-Camera Detect (Blue) 3. Rear-Camera Detect (Brown) 2. ACC (Red) 1. ACC (Red) IMAGE DIP_S/W PROGRAM LCD-IN LCD-OUT MASERATI TD VIDEO INTERFACE POWER/CAN DIGITAL R-TOUCH NAVI C-TOUCH FRONT REAR... - Page 27 INSTRUCTION MANUAL INSTALL MANUAL Quattroporte LVDS cable connection...
- Page 28 INSTRUCTION MANUAL INSTALL MANUAL GranTurismo LVDS cable connection...
-
Page 29: Osd Control
INSTRUCTION MANUAL OSD CONTROL Basic information MENU Option NAVI Config RearCam-Type ExtDevice Option RearCam-Power Auto Image RearCam-Det GEAR Screen AV Mode Parking FrontCam-Type ExtDevide OSD(On Screen Display) Menu MENU Mode State Interface Status First Menu Second Menu Third Menu OSD(On Screen Display) Board Control •... -
Page 30: Config Menu
INSTRUCTION MANUAL OSD CONTROL Config Menu First Menu Second Menu Third Menu Description DIGITAL Config NAVI-RGB ： Setting the Connected NAVI Model ： Default DVB-T(DMB) ： Setting the Connected DVB-T Model ： Default Setting the Connected DVD Model ： ： Execute Reset Reset to default value of Config menu... -
Page 31: Option Menu
INSTRUCTION MANUAL OSD CONTROL Option Menu First Menu Second Menu Third Menu Description FINE Set up manufacturer of woodworking device for UART Touch use Option NAVI COM Disable feature Original Camera RearCam-Type ExtDevice Equipped with external camera + 12V continuous supply RearCam-Power AUTO + 12V supply only in Rear camera mode... -
Page 32: Image Menu
INSTRUCTION MANUAL OSD CONTROL Image Menu First Menu Second Menu Third Menu Description Brightness Adjust the value of brightness Image Contrast Adjust the value of contrast [AV / REAR / FRONT / DVD / DVBT MENU] Saturation Adjust the value of Saturation [AV / REAR / FRONT / DVD / DVBT MENU] Adjust the value of Hue [AV / REAR / FRONT / DVD / DVBT MENU]... -
Page 33: Screen Menu
INSTRUCTION MANUAL OSD CONTROL Screen Menu First Menu Second Menu Third Menu Description Horizontal Output screen horizontal movement Screen Vertical Output screen vertical movement Scale X Up Reduce / increase output screen width Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset... - Page 34 INSTRUCTION MANUAL OSD CONTROL OSD Menu First Menu Second Menu Third Menu Description Horizontal value OSD Menu Horizontal Shift value Vertical OSD menu vertical Shift value Display Time OSD Menu Display Time (in seconds) value Transparency OSD menu transparency Language OSD menu display language Reset Execute...
- Page 35 INSTRUCTION MANUAL OSD CONTROL IR-Ctrl Menu First Menu Second Menu Third Menu Description IR-Ctrl DVB-T(DMB) Learn Cancel Learn Cancel In order to work with the IR learning function, a separate IR cable is required. 1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents). 2.
-
Page 36: Utility Menu
INSTRUCTION MANUAL OSD CONTROL Utility Menu First Menu Second Menu Third Menu Description Factory Reset Execute Initialize all settings Utility Calibration Execute Run Calibration mode FDSYOOKRX-180209 Version (Check for future upgrades) Hardware Special Software Software Software Motor Model PIP Model National Version Version... - Page 37 A-912 Rm Tera-tower2, 201 Songpa-daero, Songpa-gu, Seoul, Korea F. (+82) 6204-0913 E. kap@kaptrader.com...
