2.2.2 Interior View

1
2
3
4
5
1.
Print head
2.
Gap sensor (transmitter)
3.
Media viewer
6
4.
Media holder
5.
Platen roller
6.
Media holder lock switch
7.
Black mark sensor/ Gap sensor (receiver)
7
11
