1.4 Ribbon Specification

Ribbon Specifications
Ribbon outside diameter
Ribbon length
Ribbon core inside diameter
Ribbon width
Ribbon wound type

1.5 Media Specification

Media Specifications
Media roll capacity
Media core diameter
Media type
Media wound type
Media width
Media thickness
Label length
Label length (peeler mode)
Label length (cutter mode)
Black mark
Gap height
Max. 40 mm OD
110 meter
0.5" ID core
40 mm ~110 mm
Ink coated outside wound
Max. 5" OD
1" & 1.5 ID core
Continuous, die-cut, black mark, external fan-fold, notch
Outside wound
20 mm ~ 112 mm
0.06 mm ~ 0.19 mm
10 mm ~ max. print length
25.4 mm ~ 152.4 mm (1" ~ 6")
25.4 ~ max. print length
Min. 8 mm (W) x 2 mm (H)
Min. 2 mm
