Summary of Contents for Ingenico L5KCLWBTV3

  • Page 1 28-32, boulevard de Grenelle, 75015 Paris - France / (T) +33 (0)1 58 01 80 00 / (F) +33 (0)1 58 01 91 35 Ingenico - SA au capital de 47 656 332 / 317 218 758 RCS Nanterre...
  • Page 2: Table Of Contents

    4_3 Installing the Terminal 4_3_1 Installing SAM (Secure access module, optional) 4_3_2 Installing MicroSD Card (optional) 4_3_3 Connecting the terminal to the host 4_4 USB port (optional) 4_5 Stylus pen (optional) Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 3 7_1 WARNING TO USERS IN THE UNITED STATES 7_2 NO UNAUTHORIZED MODIFICATIONS 7_3 ANTENNA REQUIREMENT 7_4 WARNING TO USERS IN THE CANADA 7_5 WARNING TO USERS IN JAPAN 7_6 Markings Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 4: 1_Introduction

    WARRANTY / SECURITY To benefit from the guarantee-related product, and to respect the security, we ask you to use only the Ingenico power supply entrusting maintenance operations only to an authorized person. Failure to comply with these instructions will void the manufacturer’s responsibility.
  • Page 5: 2_Unpacking

    It is certified with the Lane/5000. Do not use any other power supply. ADVICE Keep the packaging. It must be re-used whenever the terminal is shipped. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 6: 3_Recommendations

    PSM24W- TECHNOLOGY Desktop 296198809 Class VI 080L6IN-R Co. Ltd PHIHONG 12VDC 2,5A PSAC30U- TECHNOLOGY Desktop 296204884AB Class VI 120L6INA-R Co. Ltd PSU class VI must be used in US. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 7: 3_2 Security Of Your Terminal (Tampering Attempt Detection)

    Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 8 NEVER ask the customer to divulge their PIN Code. Customers should be advised to ensure that they are not being overlooked when entering their PIN Code Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 9: 3_3 Main Characteristics

    2nd USB Host Option connections USB Slave Serial 1 R232 Option Powered USB Power supply 12V (USB retail) Powered R232 Powered Ethernet PoE 802.3af compliant Option External power Option supply Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 10: 3_3_2 Power Characteristics

    If not, it will be necessary to use an external power supply unit. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 11: 3_3_3 Terminal Connectivity

    ISM band 2400 MHz to 2483.5 MHz Frequency band GFSK, Pi/4 QPSK, 8 DPSK Type of modulation 79 (1 MHz BW) Number of channels <4 dBm Max output power Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 12: 4_Installation

    Ambient temperature from 0°C to +45°C Max relative humidity 85% RH non-condensing at +40°C Max altitude 2000 m Storage conditions Storage temperature -20°C, +55°C Max relative humidity 85% at +55°C Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 13: 4_2 Connections

    Multipoint connector (Power Supply and SAM2 (Optional)* communications) µSD(Optional)* Speaker (Optional)* SAM1 (Optional)* SAM3 (Optional)* 3.5mm audio jack * according to the model (Optional)* Front view of the Audio Jack Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 14: 4_3 Installing The Terminal

    , or Take care to ensure that the SAM Card is inserted in the correct manner. The cut corner must be positioned as indicated on the figure below. Cut corner Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 15: 4_3_2 Installing Microsd Card (Optional)

    Slide the metallic part on the left and lift it up to open the card holder, marked (SD) Insert completely the MicroSD Card into the slot as indicated on the figure. The contacts must be positioned down side. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 16: 4_3_3 Connecting The Terminal To The Host

    4_3_3 Connecting the terminal to the host CAUTION Connecting must be made when the terminal is powered off. Trapdoor screw (optional) Connector screws (below the handle, optional) Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 17 : 2 USB ports (1 Host, 1 Device) 1 RS485 serial link (not usable on Lane/5000) 1 RS232 serial link 2 Ethernet ports 1 power lead Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 18 Special USB Shielded cable Special USB Shielded cable 12 V Ethernet cable (optional) Reference : 296114829AC (length 2m) Power supply unit Connector for terminal Connector for terminal Ethernet connector Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 19: 4_4 Usb Port (Optional)

    There is one magnet in the stylus and another in its holder. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 20: 5_Daily Use

    5_1_3 Reading a contactless card Bring the card to the active zone above the contactless logo (at about 1cm). Keep the card close to the contactless logo during the transaction. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 21: 5_2 Keyboard Details And Functionality

    The red key cancels the procedure The yellow key The green key validates input in progress cancels the last selections and information. character It is also used to switch on the terminal Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 22: 5_3 Signature Capture (Optional)

    This option is not designed to play music, but to facilitate the use of the Lane/5000. The audio connector is a standard 3.5mm Audio jack, (impedance is 32 ohms) audio connector Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 23: 6_Maintenance

    It is just as important to clean the outside of the Ingenico terminal, with a safe and approved product, as it is to clean the inside. The Ingenico dual wipe has both a cleaning wipe for removing everyday contaminants and a dry wipe to completely remove any remaining dirt or solution.
  • Page 24: 6_2 Transport And Storage

    To determine if the problem is with the card : a. If your host device has a magnetic stripe reader, try swiping the card there. b. If you have another working Lane/5000 device, try swiping the card there. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 25: 6_4 Environment (Wee, Batteries And Packaging)

    Ingenico ensures that efficient collection and recycling schemes are set-up for WEEE and batteries according to the local regulation of your country. Please contact your resellers for more detailed information about the compliance solution in place for disposing of your old product and used batteries.
  • Page 26: 7_Standards

    This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 7_2 NO UNAUTHORIZED MODIFICA- TIONS Federal Communication Commission Interference Statement 47 CFR Section 15.21. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 27 CAUTION This equipment may not be modified, altered, or changed in any way without signed written permission from Ingenico. Unauthorized modification may void the equipment authorization from the FCC and will void the Ingenico warranty. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818...
  • Page 28: 7_3 Antenna Requirement

    être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. Ce transmetteur ne doit pas etre place au meme endroit ou utilise simultanement avec un autre transmetteur ou antenne. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 29: 7_5 Warning To Users In Japan

    This device is granted pursuant to the Japanese Radio Law ( and the Japanese Telecommunications Business Law ( This device should not be modified (otherwise the granted designation number will become invalid. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 30 NOT have a safety connection to Earth). This logo indicates that the product operates with a continuous voltage. This symbol is followed by the ratings (voltage and current for instance). Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 31 The Electrical Appliance and Material Safety Law applies to enterprises that manufacture or import products in Japan. China Compulsory Certification (CCC) is similar to other certifications for product quality standardization–such as the European CE system. Lane/5000 Copyright© 2018 Ingenico 900021971 R11 000 06/0818 All rights reserved...
  • Page 32 28-32, boulevard de Grenelle, 75015 Paris - France / (T) +33 (0)1 58 01 80 00 / (F) +33 (0)1 58 01 91 35 Ingenico - SA au capital de 47 656 332 / 317 218 758 RCS Nanterre Lane/5000 Copyright©...
