Date: November 3, 2000
YEAR
MODEL
MX* Z 600
2001
MX* Z 700
MX* Z 800
X package for above mentioned models gives a
sport calibrated ride as far as rear shock absorber
is concerned.
In order to obtain a softer dampening, similar to
what the adrenaline package gives, customer could,
at his own expense, change rear shock calibration
by removing five 36 x 0.203 and one 40 x 0.203
washers inside the shock absorber (P/N 503 189
609). Following table summarizes the operation.
ORIGINAL
FUNCTION
"X" VALVING
Piston
by-pass
2.0 mm dia.
hole
4 x 40 x 0.203
1 x 24 x 0.203
3 x 40 x 0.152
2 x 24 x 0.203
9 x 36 x 0.203
Rebound
1 x 24 x 0.203
Printed in Canada (mbs2001-001a.fm MD)
®*Trademarks of Bombardier Inc. and/or its subsidiaries.
©2000 Bombardier Inc. All rights reserved.
PKGE
X
1663/1664/1665/1666/1667/1668/1669
ACTION
RECALIBRATED
TO BE
DAMPENING
TAKEN
none
2.0 mm dia.
Remove
3 x 40 x 0.203
1 washer
none
1 x 24 x 0.203
none
3 x 40 x 0.152
none
2 x 24 x 0.203
Remove
4 x 36 x 0.203
5 washers
none
1 x 24 x 0.203
SUBJECT: Rear Shock Absorber
Dampening
MODEL NUMBER
1825/1826/1827/1828/1829/1830
1670/1671/1672/1673/1674/1675
Parts Required
DESCRIPTION
Shock Absorber Oil
The following 2000 Racing Manual revised pages
describe the entire procedure.
Valving and Dampening
In the HPG shock, the piston passages are covered
by a stack of thin metal shims of various thicknesses
and diameters. The shims provide dampening by
acting as spring loaded valves offering resistance
to the oil traveling through the piston. There is a
stack of shims on both sides of the piston. One
side controls compression dampening and the other
side controls rebound dampening. By varying the
number and thickness of shims the dampening
characteristics can be very accurately obtained.
Special Tools
Special tools specific to the HPG T/A shock will be
the seal pilot, shock wrench (P/N 529 035 727) and
piston guide from Bombardier for C-46 shock.
NOTE: Tools P/N 529 035 727 and 529 035 728
will be available in early December.
2001-7
No. 2001-7
SERIAL NUMBER
All
QTY
PART NUMBER
293 600 035
1 bottle
Page 1 of 7
