Do not start the engine if anyone is standing in Safety instructions front of the cutter bar – the cutter and wheel drives must not be engaged. General comments Use the mower on grassy areas only. Read operating instructions carefully. The cutter drive must be disengaged when the Familiarise yourself with the correct operation of the mower.
Page 6
Spare parts and accessories For reasons of safety, replace a damaged petrol tank and/or tank cap. Use genuine spare parts and accessories only. We reserve the right to make changes to the design and construction without prior notice. Risk of burns! Non-permitted users: The exhaust as well as the areas around the Persons who are not familiar with the operating...
Assembly d).Throttle line adjustd -When the throttle lever “o”,but the engine is a).Assembly the Ex-arm-fixer(Fig.6) - not off,you can adjust the throttle line to Place the Ex-arm-fixer on the gear box. R(Fig.1A) direction. -Use the bolts1 to fix it. -When the throttle lever don’t reach the “0”, b).Assembly the rock frame(Fig.7) the engine is off,you can adjust the -insert the rock frame2 into the gear...
Engaging the wheel drive Temperature for use Degree of oil viscosity Squeeze the forward clutch lever9(Fig.A) From -10 C to 0 SAE 10W or 10W-30,10W-40 and hold tight to the handlebar From -0 C to 25 SAE 20W or 10W-30,10W-40 From -25 C to 35 SAE 30W or 10W-30,10W-40 Disengaging the wheel drive...
Page 9
Air filter Clean it every 3 months or after every 50 hours of use, and replace it if necessary. 7. Unscrew the filter box knobs 8. Remove the cover. 9. Remove the filter. Knock it gently on a flat surface. Replace the filter in its housing.
Page 10
Troubleshooting Before carrying out any maintenance or cleaning work, pull off the spark plug connector! Fault Remedial action Engine does not start If the engine is cold: press the primer Full up with petrol Move the throttle lever to the start position Push the spark plug connector onto the spark plug Check the spark plug.
Page 11
Οδηγίες ασφαλείας Γενικές συμβουλές ασφαλείας Διαβάστε προσεκτικά τις οδηγίες λειτουργίας. Ενημερωθείτε για τη σωστή λειτουργία του θεριστικού. Φυλάξτε τις οδηγίες λειτουργίας για μεταγενέστερη χρήση και για την ενημέρωση άλλων χρηστών. Ακολουθήστε τις οδηγίες ασφαλείας και τις προειδοποιήσεις σχετικά με το μηχάνημα. Προβλεπόμενοι...
Page 12
Προσοχή! Η βενζίνη είναι εξαιρετικά εύφλεκτη! Αποθηκεύετε την βενζίνη μόνο σε κατάλληλα για την χρήση αυτή δοχεία. Η επαναπλήρωση θα πρέπει να γίνεται μόνο σε εξωτερικούς χώρους. Μην καπνίζετε κατά την επαναπλήρωση! Μην ανοίγετε την τάπα της δεξαμενής ή γεμίζετε με βενζίνη ενώ λειτουργεί ο κινητήρας ή αν το μηχάνημα είναι ζεστό.
Page 14
Βασική ράβδος κοπής Ρυθμιζόμενα τμηματικά ύψος (μέγιστο. 6cm). • Χαλαρώστε τα παξιμάδια. • Ρυθμίστε τις γλίστρες στο απαιτούμενο ύψος. • Σφίξτε τα παξιμάδια. Και οι δύο γλίστρες πρέπει να ρυθμιστούν στο ίδιο ύψος! Στ.) Επαναφορά της τάσης της ράβδου κοπής Μετά...
Page 15
Πιέστε το μοχλό του συμπλέκτη μετάδοσης της κίνησης και κρατήστε τον σφιχτά με την βοήθεια της χειρολαβής. Διακοπή μετάδοσης της κίνησης στους τροχούς Απελευθερώστε το μοχλό του συμπλέκτη μετάδοσης της κίνησης. Απενεργοποίηση της ράβδου κοπής Απελευθερώστε το μοχλό του συμπλέκτη κοπής Απενεργοποίηση...
Page 16
• Αν ο ιμάντας V έχει βλάβη. Γρανάζια μετάδοσης την κίνησης Ελέγχετε τακτικά τη στάθμη λαδιού του κιβωτίου ταχυτήτων • Βεβαιωθείτε ότι το μηχάνημα βρίσκεται σε επίπεδο έδαφος, χωρίς κλίση. • Ξεβιδώστε την τάπα του λαδιού. • Στάθμη λαδιού: έως το κάτω άκρο του ανοίγματος πλήρωσης. Συμπληρώστε...
