Michelangelo Gateway
Select a suitable location which is close to:
xDSL or Cable modem.
Power outlets.
10BaseT or 100BaseTX hub.
2. Connect the Router to LAN
Use standard UTP network cable, with RJ45 connectors, to connect Michelangelo Gateway to a
10BaseT or 100BaseTX hub.
Michelangelo Gateway will auto-detect the network speed and full/half duplex mode.
If your LAN has an existing DHCP Server, set DIP switch 2 ON to disable the DHCP Server in
Michelangelo Gateway.
3. Connect to xDSL or Cable modem
Using a cable fitted with RJ45 plugs, connect the WAN port on Michelangelo Gateway to the
Ethernet port on the xDSL or Cable modem.
4. Power Up
Connect the supplied power adapter to Michelangelo Gateway.
Only use the provided power adapter. Using a different one may
cause hardware damage and warranty void.
5. Check the LEDs
When Michelangelo Gateway is powered On, both the LEDs on the top face should light briefly.
If the Data/Status starts flashing (Yellow, Green, Yellow, Green ....), there is a hardware problem.
For more information on the LEDs, refer to the LED table in Device Details.
