Michelangelo Gateway
To Create a new Server
Click "Clear Form"
Enter the required data
Click "Add"
To Modify (Edit) a defined Server
Select it from the drop-down list,
Click "Get Data"
Make any desired changes. Note that you can "Enable" and "Disable" a Server using this process.
Click "Update"
To Delete a defined Server
Select it from the drop-down list,
Click "Delete"
To List all Servers
Click "List All"
Enter data on this screen as follows.
Enable
Use this to Enable or Disable support for this Server, as required.
Protocol Select the protocol (TCP or UDP) used by the Server.
Name Names can not contain spaces or punctuation, and are case insensitive (case is ignored).
IP Address
The IP Address of the PC on your LAN which is running the Server software.
Internal Port Number Enter the port number used by the Server to connect to clients.
External Port Number The port number used by clients when connecting to the Server. This is normally the same as the Internal Port Number.
If it is different, this device will perform a "mapping" or "translation" function, allowing you to configure the server to use
one port address, while clients use a different port address
VPN (Virtual Private Networking) Servers
Michelangelo Gateway supports VPN, using PPTP (Peer-to-peer Tunneling Protocol).
If accessing remote VPN Servers, no configuration is required. Just use your VPN Client software normally.
To allow remote users to access a VPN Server on your LAN, you must create a Virtual Server entry for the VPN Server, using the procedure
described above.
