Michelangelo Gateway
In order to delete an existing entry:
Select the entry from Existing Entries in Routing Table.
Click on Get Data.
Click on Delete.
Create a new entry:
Type in Destination IP Adress, Network Mask, Gateway, Interface and Metric.
Click on Add .
In order to refresh the displayed informations click on Update
In order to display all the existing routes (Routing Table) click on List All
Routing Table data
Destination The network address of the remote LAN segment. For standard class "C" LANs, the net-work address is the first 3 fields of this
IP Address
Destination IP Address. The 4th (last) field can be left at 0.
Network Mask The Network Mask used on the remote LAN segment. For class "C" networks, the standard Network Mask is 255.255.255.0
Gateway
Select the appropriate interface - LAN (Internal LAN) or WAN (External LAN or WAN) from the drop-down list.
IP Address
Metric The number of routers which must be traversed to reach the remote LAN segment. The default value is 1.
Figura 2: LAN
