NCR 7610-K453 Kit Instructions

NCR 7610-K453 Kit Instructions

Lcd customer display tilt mount
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

7610-K453
LCD Customer Display Tilt
Mount
Kit Instructions
Issue A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7610-K453 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NCR 7610-K453

Summary of Contents for NCR 7610-K453

  • Page 1 7610-K453 LCD Customer Display Tilt Mount Kit Instructions Issue A...
  • Page 2 Revision Record Issue Date Remarks Feb 2011 First issue...
  • Page 3 This kit provides a VESA tilt mount which supports 6.5”, 12.1” and 15” NCR LCD customer displays. Includes (4) VESA mount screws for NCR 12 & 15” LCDs and (4) VESA mount screws for 5982 (6.5”) LCD. Note: This kit requires the Customer Display Base Kit (7610-K452).
  • Page 4 1. Install the Tilt Mount Assembly on the back of the LCD Customer Display. Use the M4 x 10 screws for the 12” and 15” NCR Displays or the 6-32 x 0.312 screws for the NCR 5982 Display. (The M4 screw has a larger diameter than the 6-32.)
  • Page 5 3. Insert the Customer Display Pole into the Customer Display Base. Customer Display Pole 29180 4. Connect the Display Cables (DVI/VGA and Powered USB) to the Customer Display. 5. Route the Display Cable down the Customer Display Pole. 6. Connect cables to I/O Panel connectors on the 7610. 7.
  • Page 6 8. Align the hole in the Customer Display Pole with the slot in the Tilt Mount Assembly and then insert the Dome Plug into the hole. The plug locks the plastic components together. Dome Plug 29282...
