  • Page 1 KIT  INSTRUCTIONS 2x20 Customer Display Integrated Release 1.0 7761-K451 Issue A...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3 Revision Record Issue Date Remarks Jan 2016 First Issue...
  • Page 4 2x20 Customer Display Integrated Introduction This kit provides the components to add a 2x20 Customer Display integrated to the P- Series Stand.
  • Page 5 7761 - K451 (2x20 Customer Display Integrated) Installation Procedure 1. Open the Head Assembly. 2. Secure the 2x20 Display Bracket to the sled with a screw. 3. Secure the 2x20 Customer Display into the display bracket with screws (2).
  • Page 6 7761 - K451 (2x20 Customer Display Integrated) 4. Connect the 2x20 Customer Display cable to the VFD1 connector on the motherboard.
