Amcrest IP2M-851EB User Manual page 19

Section 1: This bar allows the user to select which stream type and which protocol they want to choose.
Section 2: The functions bar allows the user to perform different camera functions while in live mode. See the table
below for an explanation of the different functions available:
Button Function Name
Optical/Digital Zoom Click this button to activate the zone selection function. This allows the user to
Snapshot
Triple Snapshot
Manual Record
Section 3: This bar allows the user to change video settings for the live playback screen. See the below table for an
explanation of the video settings:
Button Function Name
Image Adjustment
Adapt/Original Size
Full Screen
Width/Height Ratio
Function Description
use the mouse to select a zone to zoom in on.
Click this button to take a screenshot of the live feed. The picture is saved at
the path specified in Setup -> Camera -> Video -> Path.
Click this button to take 1 screenshot per second for 3 seconds. The pictures
are saved at the path specified in Setup -> Camera -> Video ->
Path.
Click this button to manually record video. The video is saved at the path
specified in Setup -> Camera -> Video -> Path.
Function Description
This button opens the image adjustment toolbar, which allows the user to
adjust brightness, contrast, saturation, and hue for the live feed's picture.
TThis button allows the user to switch between displaying the original size of
the stream in its set resolution, or to adapt to the size of the monitor display
the feed is being viewed on.
This button allows the user to make the live feed go into full screen mode.
Double click the mouse or click the ESC button to exit full screen mode.
This button allows the user to change the width/height ratio for the live feed.
The options are Original and Adaptive. Original uses the aspect ratio of the
stream's set resolution, and adaptive fits the feed to the aspect ratio of the
monitor display the feed is being viewed on.
19
