In order to ease the assembly, you should separate and identify the parts first Do not place the parts directly onto the floor. Use a cardboard sheet or a mat to place the parts, during the separation and assembly. IMPORTANT In order to avoid severe or even fatal injuries, follow the instructions carefully.
ASSEMBLED PRODUCT: H: 29.92'' W:13.77'' L:13.77'' Maximum weight supported distributed Hardware list 1000008297 1000008616 1000009033 1000000281 - WHITE 1000007352 - BLACK 1000010221 - BLUE Qty. 2 Qty. 2 Qty. 1 Qty. 2 1000010136 1000008285 1000008285 3000009645 - WHITE 3000009643 - BLACK 3000009649 - BLUE 3000009647 - GREY Qty.
Page 4
1 - Identify the parts as figure below: P8 with hole and P9 without hole. 1 - Attach the P9 part on the P1 and P2 parts in the indicated direction. 2 - Then attachthe P8 part on the P1 and P2 parts.
Page 5
1 - Check the alignment of the holes on the fitted parts. 2 - The hole in the horizontal bar of part P8, should be up. 1 - With the end of F3, smash the safety claw, locking part P8 and P9 to part P1 and P2.
Page 6
1 - Identify the cutout on the top end of the P6 part. 2 - Attach the P6 part on the P1, P2 and P9 parts. 3- Slide part P6 to support on parts P1 and P2. 1 - With the end of F3, smash the safety claw, locking part P6 to part P1 and P2.
Page 7
1 - Attach the joint of the front of the P4 part under the P8 part. 2 - Lower the P4 part as indicated. 1 - Check all the fittings before moving forward.
Page 8
1 - Attach the P3 part on the parts P1 and P2. 2 - Pull the front of the P3 part.
Page 9
1 - With the end of F3, smash the fety claw, locking part P3 to part P6. 1- Slightly turn the P5 part and place it inside the cabinet, as indicated. 2- Check all the fittings before continuing.
Page 10
1 - Lay the cabinet against the wall and mark the hole. IMPORTANT: CABINET MUST BE ATTACHED TO THE WALL 1 - Drill the wall on the marked point, using a ½” drill bit. ½”...
Page 11
1 - Insert the metal part of the bushing into the hole until it overcomes the wall. WALL 2 - Pull the bushing driving it against the wall and then push the plastic ring until it leans close to the wall WALL Plastic ring 3 - Break the bushing's rods...
Page 12
1 - Insert the screw F2 into the hole of part P6 2 - Turn screw F2 with part F3 clockwise 3 - Press part F4 against the heads of the F2 screws. 1 - Attach the F5 into the P8 part.
Page 13
1 - Attach the F7 handle to the door P7 as indicated below 1 - Attach the F6 into the P7 holes.
Page 14
1 - Attach part P7 to the bottom of the cabinet through part F5 2 - Finish engaging part P7 through the pivoting wrench as shown below. 1 - Glue F8 to part P7 in the indicated area..
Page 15
TAKING GOOD CARE OF YOUR CABINET Cleaning and caring instructions: - Avoid dragging objects on top of the cabinet. They might scratch the finishing. - Only non-abrasive natural chemical products are recommended to clean your cabinet. Simply wipe the cabinet down with a wet cloth to remove the cleaning product excess.
Page 16
ITEMS EXCLUDED FROM WARRANTS This limited warranty does not cover: 1. In-home service including, but not limited to, service calls to correct the installation of any Manhattan Comfort Smart Diy products or to instruct the consumer on how to use or install them.
