Asha Entertainment Unit
Assembly Instructions
11
Note: If the door is not sliding smoothly or
sitting straight, there is a screw in the
middle of the wheel on the bottom of each
door that can be tightened/loosened until
the door is sitting properly.
Attach doors [3] as shown, starting with the back door first and then the
front door. Press the clip down on the back of the door to assemble the door.
Push the clip back up to lock into place.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3
back
OK
12
V
Z
1
11
Attach 4x wedges (H) into the corners of the back of the unit
and secure with 4x screws (L). Tighten with a screwdriver.
Attach 1x safety strap (V) to the top of the back side of the
unit as shown using 1x washer (Z) and 1x screw (W). Tighten
with a screwdriver.
H
L
W
H
L
V
11
Z
W
7
