Attach Doors And Secure - Mocka Asha Entertainment Unit Assembly Instructions Manual

Asha Entertainment Unit
Assembly Instructions
9
A
D A
A D
A
D
2
4
5
Attach panel [1] to the rest of the unit with 10x dowels (A) and secure
with 8x locking nuts (D). Tighten with a screwdriver.
