Instructions for Use
Connecting to the App
The robot supports the Roborock or Xiaomi Home app. Choose
the one that best meets your needs.
1. Download App
Option 1: Search for "Roborock" in the App Store or Google Play or scan the QR
code to download and install the app.
Option 2: Search for "Xiaomi Home" in the App Store or Google Play or scan the
QR code to download and install the app.
2. Reset WiFi
Press and hold the
and
alert. The reset is complete when the WiFi indicator flashes slowly. The robot will
then wait for a connection.
Note: If the mobile phone fails to connect to the robot because your router configuration changes or you forget
your password or for any other reason, reset the WiFi and add the robot again when it is waiting for a connection.
3. Add Device
On the homepage of the app, tap "+" in the top right corner and add the device
according to the in-app guide.
Note:
• The actual process may vary due to ongoing app updates. Follow the instructions provided in the app.
• Only 2.4 GHz WiFi is supported.
• If the robot waits more than 1 hour for a connection, WiFi will be automatically disabled. If you want to recon-
nect, reset the WiFi before proceeding.
16
buttons until you hear the "Resetting WiFi" voice
WiFi Indicator
• Off: WiFi disabled
• Flashing slowly: Waiting
for connection
• Flashing quickly:
Connecting
• Steady: WiFi connected
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Roborock X7 WashVac
Summary of Contents for Roborock X7 WashVac
- Page 1 1. Download App Option 1: Search for "Roborock" in the App Store or Google Play or scan the QR code to download and install the app. WiFi Indicator •...
-
Page 2: Start Cleaning
Note: The robot cannot be turned off when it is being charged. Note: • To prevent corrosion or damage, do not use cleaning fluid or disinfectant not specified by Roborock in the water tank. • Do not use hot water as this may cause the tank to deform. - Page 3 Instructions for Use Pause Charging When the robot is running, press any button to pause it, or press the button to After cleaning, the robot will automatically return to the dock to charge. In Pause send it back to the dock. mode, press the button to send the robot back to the dock.
-
Page 4: App Features
App Features Routine Maintenance Cleaning Map To ensure optimal performance of the robot, refer to the following table for routine maintenance: Multi-map management | Real-time vacuuming/mopping route | Carpet display | Parts Maintenance Frequency Replacement Frequency Map zoning | Map editing Omni-Directional Wheel Clean as needed Custom Cleaning Modes... -
Page 5: Side Brush
Routine Maintenance Main Brush and Mop Roller Side Brush 1. Turn over the robot, press the roller cover latches to open them, and remove the 1. Unscrew the side brush screw. main brush and/or mop roller. 2. Remove and clean the side brush. Reinstall the brush and tight- en the screw. -
Page 6: Main Wheel
Routine Maintenance Main Wheel 2. Open the dustbin cover and empty the dustbin. 3. Fill the dustbin with clean water and close the cover. Gently shake the dustbin, Clean the main wheel with a soft, dry cloth. and then pour out the dirty water. 4. - Page 7 Pour out the dirty water. Close the lid and then re-install. Note: • To prevent corrosion or damage, do not use cleaning fluid or disinfectant not specified by Roborock in the water tank. • Do not use hot water as this may cause the tank to deform.
- Page 8 Routine Maintenance Cleaning Tank and Water Filters 1. Remove the primary and secondary water filters and rinse them with water. 2. Wipe and clean the cleaning tank with a wet cloth. 3. Fit the two filters back in place.
- Page 9 Routine Maintenance Robot Sensors Charging Contact Areas Use a soft, dry cloth to wipe the charging contacts on the robot Use a soft, dry cloth to wipe all sensors, including: and on the dock. 1. The dock locator in the front. 2.
-
Page 10: Basic Parameters
Basic Parameters Robot Model X170RR Battery 14.4V/4900mAh lithium battery Weight Approx. 4.8kg Wireless Connection WiFi Smart Connect Rated Input 20V 1.8A Charging Time <6h Robot Cleaning Dock Model CDZ18RR or CDZ19RR Rated Power 42 W Rated Input 100-240V Rated Output 20V 1.8A Rated Frequency 50-60Hz... -
Page 11: Troubleshooting
Environment Protection Informa- Troubleshooting tion Malfunction with the Robot Removing The power indicator of the robot will flash red and a voice alert will sound. Follow The following information applies only when disposing of the robot and should not be followed for day-to-day operations. the voice prompts and instructions in the app for troubleshooting. - Page 12 Unable to connect to WiFi. There may be an error with Unable to return open area. your router settings. Contact Roborock customer service to dock The robot is too far from the dock. Place it closer and for help with troubleshooting.
- Page 13 FAQs Is power always The robot will draw power while it is docked to maintain being drawn battery performance, but the power consumption is when the robot extremely low. is on the dock? Does the robot need to be charged for at No.
- Page 15 Address of Manufacturer: Floor 6, Suite 6016, 6017, 6018, Building C, Kangjian Baosheng Plaza, No.8 Heiquan Road, Haidian District, Beijing, P.R.CHINA For more product information, visit our website: www.roborock.com For after-sales support, email our after-sales service team: US/Non-Europe Support: support@roborock.com...
