- Page 1 Roborock Xiaowa Robotic Vacuum Cleaner Manual Please read this manual carefully before using the product and store it properly...
-
Page 2: Safety Information
Safety Information Restrictions This product is designed for indoor floor cleaning only, do not use it outdoors (such as on an open-ended terrace), on any surface other than the ground (such as a sofa), or in any commercial or industrial environment Do not use this product on elevated surfaces without barriers such as the floor of a loft, an open-ended terrace, or on top of furniture Do not use the product when the ambient temperature is higher than 40℃, lower... - Page 3 Safety Information This product can be used by children aged age 8 years and above and persons with reduced physical, sensory or mental capabilities or a lack of experience and knowledge once they have been given supervision or instruction concerning the safe use of the product and understand the hazards involved. Children should not play with the appliance.
- Page 4 WARNING For the purposes of recharging the battery, only use the detachable supply Unit Xiaowa CDZ03RR or CDZ04RR provided with this product Do not dismantle, repair or modify the battery or charging dock Keep the charging dock away from heat (such as heating vents)
- Page 5 Does not power on Main brush, side brush, fan or main wheel issue Charging dock Main unit does not charge Power cable Charging dock has no power Charging dock Xiaowa CDZ03RR/ CDZ04RR s Xiaowa Rechargeable Li-on battery pack information BRR-1P4S-2600S/BRR-1P4S-2600D 2600mAh/37.44Wh Cell number...
-
Page 6: Main Unit
Introduction Main unit Spot cleaning Press to start spot cleaning Clean/ON&OFF Press to start cleaning Press and hold to power on or off POWER light White: battery capacity ≥ Red: battery capacity ＜ Slow flashing: Charging or starting up Flashing red: Error Recharge Press to return to charging dock... - Page 8 Introduction Dust bin Main unit Dustbin lid Dustbin latch WIFI indicator Slow blinking: Waiting to connect Fast blinking: Connecting Strainer Stable: WIFI is connected Air vent Speaker Accessories Charging dock Power cable Main brush cleaning tool...
- Page 9 Introduction Main unit and sensors Charging dock Charging dock indicator Signal transmission area Infrared deceleration sensor Power connector Charging point Charging point Cliff Sensor Omni-directional Omni-directional wheel charging dock sensor Charging contact points Bumper Side brush Main wheels Main brush Main brush cover latch...
-
Page 10: Installation
Installation 3 Powering on and charging 1 Connect the power cable and use a cable tie to clear excess wiring Press and hold the button to power on, wait until the power light sops flashing, then dock the main unit to the charging dock to charge The product is equipped with a high-performance lithium- ion rechargeable battery. -
Page 11: Quick Setup
Installation The product is compatible with the Mi Home smarthome platform and can be controlled in the Mi Home app. It supports the MIUI system and can be linked with other Mi Home intelligent products. Quick Setup Download App Search "Mi Home" in App store/Google play or scan the QR code below to download and install the Mi Home app. Add Device Go to the "My Device"... -
Page 12: Routine Maintenance
Installation Routine Maintenance Main brush WIFI indicator Clean weekly Slow blinking: Waiting for connection 1. Turn over the main unit and press the latch to Fast blinging: Connecting remove the main brush cover Stable: WIFI connected 2. Lift out the main brush and clean its bearings 3. - Page 13 Routine Maintenance Dust bin and filter Clean weekly 1. Open the top cover of the product and press the 3. Turn the dust bin over and pour out the dust dust bin latch then lift and remove the dust bin Note: To avoid filter blockage, tap the dustbin lightly on the edge of the bin 2.
- Page 14 Routine Maintenance Battery Do not wash the filter with water, this may cause filter blockages The product is equipped with a high-performance lithium-ion rechargeable battery. Keep the product Note: Replacing the filter every 3-months is recommended for charged for maximum battery performance. maximum cleaning effectiveness Note: If to be left unused for a long period of time, fully charge the product and switch it off before storing it in a cool, dry place.
-
Page 15: Firmware Update
Routine Maintenance Sensors Charging dock Clean monthly Clean monthly Use soft dry cloth to wipe clean each sensor: Use soft dry cloth to clean the charging contacts on the charging dock 1. Four cliff sensors on the bottom 2. Infra-red deceleration sensor in the front 3. -
Page 16: Basic Parameters
Basic parameters Main unit Charging dock Specifica Name Specs Name tions Model CDZ03RR or CDZ04RR ***** can be 0 to 9, A to Z, a to Outline Dimension 151x130x98mm Model z, "-", "_", "\", "/" or blank, for marketing purpose.) Power rating Outline Dimensions 353x350x90.5mm... - Page 17 Xiaowa Model Comparison Xiaowa Lite Xiaowa Xiaowa Plus Model（ can be 0 to 9, A to Z, to z, "-", "_", "\", "/" or blank, Xiaowa C1 ***** Xiaowa E2 ***** Xiaowa E3 ***** for marketing purpose.) Cleaning method Wet mopping function...
-
Page 18: Troubleshooting
Troubleshooting If an error occurs, the power indicator will flash red and a voice prompt will sound. Use the table below to resolve these errors Fault display Solution The bumper is stuck. Lightly tap it several times to dislodge any trapped material. - Page 20 2. Error 1, error 15, error 16, error 19, error 20 and error 21 are error codes for other models and not applicable to this machine If the problems persist after using the above recommendations, email our after-sales service teams: US/Non-Europe Support: support@roborock.com 带格式的: 法语(法国) Europe Support: support@roborock-eu.com...
-
Page 21: Eu Declaration Of Conformity
EU Declaration of Conformity Hereby we: Name of manufacturer Beijing Roborock Technology Co.,Ltd. Floor6,Suite6016,6017,6018,BuildingC,Kangjian Baosheng Plaza,� Address No.8 Heiquan Road,Haidian District, Beijing,P.R.CHINA declare that this DoC is issued under our sole responsibility and that the products: Product description Robotic Vacuum Cleaner and Accessories C1*****( * can be 0 to 9, A to Z, a to z, "-", "_", "\", "/"... - Page 22 EU Declaration of Conformity 1.Electromagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements; Harmonized Standard covering the essential requirements of article 3.1(b) of Directive 2014/53/EU and the essential requirements of article 6 of Directive 2014/30/EU RED Directive 2014/53/EU 2.Electromagnetic Compatibility (EMC) standard for radio equipment and services;...
- Page 24 EU Declaration of Conformity 1.Household and similar electrical appliances-Safety-Part 1: General requirements Low Voltage Directive 2014/35/EU 2.Household and similar electrical appliances-Safety-Part 2-29: Particular requirements 1. EN 60335-1:2012 + A11:2014 for battery chargers 2. EN 60335-2-29:2004 + A2:2009 3.Measurement methods for electromagnetic fields of household appliance and similar 3.
-
Page 26: Weee Information
WEEE Information Correct Disposal of this product . This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. -
Page 27: Warranty Information
Warranty Information The seller provides warranty in accordance with the legislation of the customer's own country of residence, with a minimum of 1 year,starting from the date on which the appliance is sold to the end user. The warranty only covers defects in material or workmanship. The repairs under warranty may only be carried out by an authorized service centre. - Page 28 Address of Manufacturer: Floor 6, Suite 6016, 6017, 6018, Building C, Kangjian Baosheng Plaza, No. 8 Heiquan Road, Haidian District, Beijing, P.R. CHINA For more product information, please visit our website: www.roborock.com For after-sales support, please email our after-sales service team: US/Non-Europe Support: support@roborock.com...
