Instructions
®
Reactor
For Reactor 2 Electric and Hydraulic Systems
For remotely changing system settings on Graco Reactor 2 E-30, E-XP2, H-30, H-40, H-50,
H-XP2, and H-XP3 systems. For professional use only.
Models: 25D612, 25E656
Important Safety Instructions
Read all warnings and instructions in this manual
and in the Reactor
IMPORTANT
By operating your Reactor 2 system with the cellular
module installed, you are accepting the Graco Reactor
Connect Terms and Conditions and Software License
Agreement ("Terms").
To review the Terms, install the Reactor Connect on
your mobile device or visit www.graco.com.
Connect Installation Kit
®
2 manual. Save all instructions.
3A5540D
EN
Advertisement
Table of Contents
Related Manuals for Graco Reactor 25D612
Summary of Contents for Graco Reactor 25D612
- Page 1 Reactor Connect Installation Kit 3A5540D For Reactor 2 Electric and Hydraulic Systems For remotely changing system settings on Graco Reactor 2 E-30, E-XP2, H-30, H-40, H-50, H-XP2, and H-XP3 systems. For professional use only. Models: 25D612, 25E656 Important Safety Instructions Read all warnings and instructions in this manual ®...
-
Page 2: Table Of Contents
Connect App to Reactor ....11 Graco Information ......18 Operation . -
Page 3: Agency Approvals
Agency Approvals Agency Approvals NOTE: Cellular module kit 25M833 contains Part 25M720. Cellular module kit 25E658 contains Part 25N372. Description Approvals MODULE, cellular, worldwide (25M720) MODULE, cellular, United States and Canada only (25N372) 3A5540D... -
Page 4: Warnings
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable. - Page 5 Warnings 3A5540D...
-
Page 6: Typical Installation
Typical Installation Typical Installation . 1: Typical Reactor Connect Cell Module Installation (Reactor 2 Electric Shown) 3A5540D... - Page 7 Typical Installation . 2: Typical Reactor Connect Cell Module Installation (Reactor 2 Electric Shown) Ref. Description Ref. Description Cellular Module CAN Cable Cellular Module CAN Cable Tee Cellular Module Nuts TCM CAN Cable ADM* Advanced Display Module Antenna Included with Reactor 2 proportioner. Bracket Bracket Screws 3A5540D...
-
Page 8: Overview
Overview Overview The Reactor Connect allows the Graco Reactor 2 to be monitored and operated remotely. The Reactor 2 is intended to be controlled by an on-site operator. In any lock-out, tag-out procedure, take into consideration the To avoid injury due to unexpected machine operation... -
Page 9: Installation
6. Install the TCM CAN cable (F) and the cellular module CAN cable (D) onto the cable tee (E). NOTE: For units with Graco InSite, remove both the mounting screws and the InSite module. Set aside. 7. Using a Phillips screwdriver, loosen the four ADM mounting screws (MS) in the inside of the cabinet 15. -
Page 10: Update Adm Software
Installation Update ADM Software NOTE: When the ADM display turns on, you may see the following screens: First: Software is checking which modules will take the available updates. 1. Shut down system. See your Reactor operation manual for shutdown instructions. 2. -
Page 11: Setup
Setup Setup Download the Graco Reactor Connect on the Apple App ® ™ Store or the Android Google Play store. 1. Open the Reactor Connect on your smartphone. 2. Read and accept the Terms of Use and data usage notification. -
Page 12: Operation
Operation Operation Reactor Connect Ref. Description Ref. Description Proportioner Mode (Spray, Jog, Park) Reactor Status Pump Pressure Reactor Name Pump Pressure Setpoint Menu Material Usage Reactor Power Switch Cycle Count Heat Zone Settings Reset Cycle Count Heat Zone On/Off Heat Zone Actual Temperature * Not available with Reactor 2 Hydraulic systems. -
Page 13: Cellular Screen
3. Reconnect your app to the Reactor. See Connect App to Reactor, page 11. NOTE: After resetting your Reactor key, all operators using the Graco Reactor Connect must reconnect to the Reactor. NOTE: For security of wireless control, change the Reactor key on a regular basis and whenever there is a concern about unauthorized access. -
Page 14: Troubleshooting
Troubleshooting Troubleshooting Disconnect Cellular Module NOTE: Before troubleshooting the Reactor, disconnect the cellular module (A). The Reactor Connect cannot change Reactor 2 settings while the cellular module is For information on troubleshooting a Reactor, refer to disconnected. the Reactor repair manual. 1. -
Page 15: Parts
Parts Parts Cellular Module and Antenna Accessories Ref. Part Description Qty. 25M831 BRACKET Part Description 25M833 KIT, cellular module, worldwide 25D878 KIT, antenna, external use (not shown) 25E658 KIT, cellular module, United States and Canada only 25M828 ANTENNA, paddle 127158 NUT, 8-32 121002 CABLE, can 124654 TEE, CAN 25M832 TAG, agreement (not shown) - Page 16 Parts 3A5540D...
-
Page 17: Technical Specifications
Technical Specifications Technical Specifications Cellular Module (25M720) FCC/IC Contains FCC ID XPY1CGM5NNN Contains IC ID (Industry Canada) 8595A-1CGM5NNN The enclosed device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:(1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 18: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
