- Page 1 Reactor 2 App Installation Kit 3A5541D For Reactor 2 Integrated Systems For remotely changing system settings on Graco Reactor 2 E-30i and E-XP2i systems built. For professional use only. Models: 25D614, 25E657 Important Safety Instructions Read all warnings and instructions in this manual ®...
-
Page 2: Table Of Contents
Connect App to Reactor ....10 Graco Information ......16 Operation . -
Page 3: Agency Approvals
Agency Approvals Agency Approvals NOTE: Cellular module kit 25M833 contains Part 25M720. Cellular module kit 25E658 contains Part 25N372. Description Approvals MODULE, cellular, worldwide (25M720) MODULE, cellular, United States and Canada only (25N372) 3A5541D... -
Page 4: Warnings
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable. - Page 5 Warnings 3A5541D...
-
Page 6: Typical Installation
Typical Installation Typical Installation . 1: Typical Cell Module Installation (Integrated Reactor) 3A5541D... - Page 7 Typical Installation . 2: Typical Cell Module Installation (Integrated Reactor 2) Ref. Description Ref. Description Power Supply Cable Cellular Module Air Panel Cover (Compatible with Cellular Mounting Screws Module) ADM* Advanced Display Module Warning Label Antenna Cellular Module CAN Cable Included with Reactor 2 proportioner.
-
Page 8: Overview
1. Shut down system. See your Reactor 2 operation Disconnect Cellular Module, page 13. manual for shutdown instructions. The Reactor 2 App allows the Graco Reactor 2 to be 2. Disconnect incoming power at source. monitored and operated remotely. The Reactor 2 is intended to be controlled by an on-site operator. -
Page 9: Update Adm Software
Installation Update ADM Software NOTE: When the ADM display turns on, you may see the following screens: First: 1. Shut down system. See your Reactor operation Software is checking which manual for shutdown instructions. modules will take the available updates. 2. -
Page 10: Setup
Setup Setup Download the Graco Reactor app on the Apple App ® ™ Store or the Android Google Play store. 1. Open the Reactor App on your smartphone. 2. Read and accept the Terms of Use and data usage notification. -
Page 11: Operation
Operation Operation Reactor 2 App Ref. Description Ref. Description Proportioner Start/Stop Switch Reactor Status Proportioner Mode (Spray, Jog, Park) Reactor Name Pump Pressure Menu Pump Pressure Setpoint Reactor Power Switch Material Usage Heat Zone Settings Cycle Count Heat Zone On/Off Reset Cycle Count Heat Zone Actual Temperature Heat Zone Temperature Setpoint... -
Page 12: Cellular Screen
3. Reconnect your app to the Reactor. See Connect App to Reactor, page 10. NOTE: After resetting your Reactor key, all operators using the Graco Reactor 2 app must reconnect to the Reactor. NOTE: For security of wireless control, change the Reactor key on a regular basis and whenever there is a concern about unauthorized access. -
Page 13: Troubleshooting
Troubleshooting Troubleshooting Disconnect Cellular Module NOTE: Before troubleshooting the Reactor, disconnect the cellular module (A). The Reactor 2 App cannot change Reactor 2 settings while the cellular module is For information on troubleshooting a Reactor, refer to disconnected. the Reactor repair manual. 1. -
Page 14: Parts
Parts Parts Cellular Module and Antenna Accessories Ref. Part Description Qty. 16H880 COVER, air panel 25M833 KIT, cellular module, worldwide Part Description 25E658 KIT, cellular module, United States 25D878 KIT, antenna, external use (not shown) and Canada only 25M828 ANTENNA, paddle 16X129 SCREW, phillips, 8-32, 3/8 long 121002 CABLE, CAN 7▲... -
Page 15: Technical Specifications
Technical Specifications Technical Specifications Cellular Module (25M720) FCC/IC Contains FCC ID XPY1CGM5NNN Contains IC ID (Industry Canada) 8595A-1CGM5NNN The enclosed device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:(1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 16: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
