Venetia - Shoe Storage
Assembly Instructions - Important: Retain these instructions
In order to prevent overturning, this product must be
used with the wall attachment device provided
Dimensions
Width - 80cm
Depth - 33cm
Height - 86cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0330 016 1114
For any other queries please contact the Customer Helpline on: 0345 640 2020
for future reference
Woodgrain
and Black
WARNING!
More help is available throughout this
booklet by scanning in the QR codes
or typing in the links
White
and Grey
906/5716
323/9603
541/8745
709/8675
792/4543
MADE IN
BRITAIN
Issue 25 - 17/12/19
