ES35/35 / M35/35ES
Installation/Operator Manual
WARNING: For your safety the
! ! ! ! !
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
●
Do not try to light any appliance.
●
Do not touch any electrical switch;
do not use any phone in your
building.
●
Clear the room, building or area of
all occupants.
●
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
●
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
88 Currant Road, Fall River MA 02720-4781 USA / Telephone: +1 (269) 923-3000 / Fax: +1 (508) 678-9447
American Dryer Corporation
e-mail: mdl-service@whirlpool.com / www.adclaundry.com
AVERTISSEMENT: Assurez-vous de
! ! ! ! !
bien suivre les instructions données
dans cette notice pour réduire au
minimum le risqué d'incendie ou
d'explosion ou pour éviter tout dommage
matériel, toute blessure ou la mort.
— Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
●
Ne pas tenter d'allumer d'appareils.
●
Ne touchez à aucun interrupteur. Ne
pas vous server des téléphones se
trouvant dans la bâtiment.
●
Évacuez la pièce, le bâtiment ou la
zone.
●
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
●
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
— L'installation et l'entretien doivent être
assurés par un installateur ou un
service d'entretien qualifié ou par le
fournisseur de gaz.
WFR 112807- 15
Advertisement
Table of Contents
Related Manuals for ADC M35/35ES
Summary of Contents for ADC M35/35ES
- Page 1 ES35/35 / M35/35ES Installation/Operator Manual AVERTISSEMENT: Assurez-vous de WARNING: For your safety the ! ! ! ! ! ! ! ! ! ! bien suivre les instructions données information in this manual must be dans cette notice pour réduire au followed to minimize the risk of fire or minimum le risqué...
- Page 2 Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory, you can FAX your order to ADC at +1 (508) 678-9447 or telephone your order directly to the ADC Parts Department at +1 (269) 923-3000. Please specify the dryer model number and serial number in addition to the description and part number, so that your order is processed accurately and promptly.
-
Page 3: Table Of Contents
WARNING In the State of Massachusetts, the following installation instructions apply: Proposition 65 ■ Installations and repairs must be performed by Use of this product could expose you to substances a qualified or licensed contractor, plumber, or from fuel combustion that contain chemicals gasfitter qualified or licensed by the State of known to the State of California to cause cancer, Massachusetts. -
Page 4: Safety Precautions
Safety Precautions ____________________ WARNING WARNING Do not use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubber For your safety, the information in this manual must materials. Drying in a heated tumbler may damage be followed to minimize the risk of fire or explosion plastics or rubber and also may be a fire hazard. - Page 5 IMPORTANT: The dryer must be installed in a location/ environment, which the ambient temperature remains between 40° F (4.44° C) and 130° F (54.44° C). NOTES _____________________________________________________ The operation of this appliance may affect the operation of other types of gas appliances, which take their air for safe ____________________________________________________________ combustion from the same room.
-
Page 6: Specifications
Specifications _____________________________________________________________________ MAXIMUM CAPACITY 35 lb 15.88 kg (DRY WEIGHT) PER POCKET TUMBLER DIAMETER 30” 76.20 cm 76.20 cm TUMBLER DEPTH 30” TUMBLER VOLUME 12.27 cu ft 347.44 L PER POCKET TUMBLER/DRIVE MOTOR 1/4 hp 0.19 kW PER POCKET BLOWER/FAN MOTOR 1/2 hp 0.37 kW PER POCKET... - Page 7 Specifications _____________________________________________________________________ NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. WFR 112807- 15 www.adclaundry.com...
-
Page 8: Installation Procedures
Installation Procedures ______________ Unpacking / Setting Up _______________ Installation should be performed by competent professional Remove protective shipping material (i.e., plastic wrap and in accordance with local, state, and country codes. In the optional shipping box) from the dryer. absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- IMPORTANT: Dryer must be transported and handled in LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA... -
Page 9: Fresh Air Supply Requirements
Fresh Air Supply Requirements ______ Exhaust Requirements _______________ This appliance may only be installed in a room that meets Exhaust ductwork should be designed and installed by a the appropriate ventilation requirements specified in the qualified professional. Improperly sized ductwork will create national installation regulations. - Page 10 Outside Ductwork Protection The length of the ductwork from the dryer to the outside exhaust outlet, must not exceed 12 feet (3.66 meters). The To protect the outside end of the horizontal ductwork from minimum diameter of this ductwork must be at least the weather, a 90°...
-
Page 11: Electrical Information
Electrical Information ________________ WARNING (Gas Models Only) Electrical Requirements Dryers built for use with a voltage between 200 and All electrical connections must be made by a properly 230/240 must verify the input voltage during licensed and competent electrician. This is to ensure that installation. - Page 12 Electric Models Only Electrical Connections All electrically heated dryers must be connected to the A wiring diagram is located behind the control panel for electric service shown on the dryer’s data label. The connection data. connecting wires must be properly sized to handle the rated If local codes permit, power to the dryer can be made by the current.
-
Page 13: Gas Information
The only electrical input connections to the dryer are the IMPORTANT: Failure to comply with these codes or 3-phase (3ø) power leads (L1, L2, L3, and sometimes ordinances, and/or the requirements stipulated in this neutral) and ground. Single-phase (1ø) power for the control manual, can result in personal injury and improper circuit and for any single-phase (1ø) motors (if present) is operation of the dryer. - Page 14 Gas Connections WARNING (CE Dryers Only) Inlet connection ..1/2” N.P.T. 3/8” B.S.P.T. (CE and Australian dryers) This appliance must only be operated with the gas Inlet supply size ..1/2” Diameter Pipe (minimum) type indicated on the dryer’s data plate. If the appliance is converted (gas type changed), a data plate amendment must be obtained from American Dryer Corporation for CE approved units.
- Page 15 Piping / Connections NOTE: Undersized gas supply piping can create a low or inconsistent pressure, which will result in erratic operation The dryer is provided with two 1/2” N.P.T. (3/8” B.S.P.T. for CE of the burner ignition system. and Australian dryers) inlet pipe connections (1 for each tumbler) at the rear of the dryer.
-
Page 16: Converting From One Family Of Gas To Another
P/N 114083) and affix this label as close as possible to the with either propane, butane, or other liquefied petroleum dryer’s existing dryer rating (data) label/plate. gases. The use of gas valve kit (ADC P/N 140414) disables the internal regulator of the gas valve. Therefore, the gas Non-CE Dryers... - Page 17 (gas type changed), a data adjustment screw (under vent cap). Remove spring plate amendment must be obtained from American under screw and replace with spring from kit (ADC P/N Dryer Corporation. 140415). Replace regulator adjustment screw. Conversions done improperly can result in a fire or Install the gas train back into the dryer gas train enclosure.
-
Page 18: Gas Pressure Testing
Gas Pressure Testing _________________ If the rear area of the dryer or the water supply is located in an area where it will be exposed to cold/freezing For proper operation, the gas pressure must be correct, temperatures, provisions must be made to protect these consistent and maintained at the gas pressure rates shown water lines from freezing. -
Page 19: Preparation For Operation / Start-Up
WARNING When a gas dryer is first started (during initial start-up), it has a tendency not to ignite on the first ignition attempt. This is because the gas supply piping is filled with air, so it ELECTRICAL SHOCK HAZARD may take a few minutes for the air to be purged from the lines. -
Page 20: Shutdown Instructions
Service / Parts Information __________ Select temperature by pressing “HI,” “MED,” or “LO.” The cycle will start and the L.C.D. will display the Dry Cycle Service selected and the remaining time. Service must be performed by a qualified trained technician. The dryer will continue through the drying and cooling cycles, If service is required, contact the reseller from whom the until the vended time has expired. -
Page 21: Routine Maintenance
To avoid the hazard of electrical shock, discontinue Shipping charges are not the responsibility of ADC. All electrical supply to the dryer. returns should be “prepaid” to the factory. Any “C.O.D.” or “COLLECT”... -
Page 22: Adjustments
Data Label Information ________________ Standard Label When contacting ADC, the information on the data label is required to ensure proper service/parts assistance. The data label is located at the upper left rear of the dryer behind the back guard. -
Page 23: Programming
Programming _________________________ Event Codes Defined: Top Pocket / Bottom E1 / E4: While attempting to turn on the burner, no burner return Enter Service Mode by Inserting Key and Turning Clockwise signal was received within RADIANT SENSOR COOL DOWN TIME. Main Service Mode window will appear and offer 5 selections: 1: Machine Info 2: Program Setup... - Page 24 WFR 112807 15 - 06/05/18...
