ADC ML-96 Parts Manual

Adc gas dryer parts manual
Hide thumbs Also See for ML-96:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
ML-96 Parts Manual
Phase 7
2001
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 450569 - 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML-96 and is the answer not in the manual?

Questions and answers

Related Manuals for ADC ML-96

Summary of Contents for ADC ML-96

  • Page 1 ML-96 Parts Manual Phase 7 2001 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450569 - 5...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

  • Page 3: Table Of Contents

    Table of Contents Control Door Assembly ... 4 Phase 7 OPL Microprocessor Control Panel Assembly ... 5 Main Door / Front Panel Assembly ... 6 Main Door Assembly ... 7 Main Door Switch Assembly ... 8 Temperature Sensor Bracket Assembly ... 9 Wrapper Assembly ...

  • Page 4: Control Door Assembly

    Control Door Assembly Illus. No. Part No. Qty. Description 816672 Phase 7 Control Door (for models mfd. as of November 27, 2001) 883293* Phase 7 Control Door with Hinge (for models mfd. prior to November 27, 2001) (includes illus. nos. 2 and 3) 117603 1/8”...

  • Page 5: Phase 7 Opl Microprocessor Control Panel Assembly

    Phase 7 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112577 Phase 7 OPL Keyboard 850984 Phase 7 Microprocessor Controller (computer) Panel ONLY 822767 Phase 7 OPL Reversing Microprocessor Controller (computer) Control Panel Assembly Complete (includes illus. nos. 1 through 7) 887003 Phase 7.2.2 BD with Sensor Activated Fire Extinguishing System (for models mfd.

  • Page 6: Main Door / Front Panel Assembly

    Main Door / Front Panel Assembly Illus. No. Part No. Qty. Description –––––– Main Door (refer to Main Door Assembly on page 7) 150443 Socket Cap Screw 881441 Bottom Hinge Block (white) 882283 Bottom Hinge Block (wrinkle coral blue) 153031 Nylon Washer 150443 Socket Cap Screw...

  • Page 7: Main Door Assembly

    Illus. No. Part No. Qty. Description 801600 Cold Rolled Steel Magnet Main Door Assembly (for models mfd. as of July 21, 2005) 881968 Cold Rolled Steel Main Door Assembly (white) (includes illus. nos. 1 through 10) 882292 Cold Rolled Steel Main Door Assembly (wrinkle coral blue) (includes illus.

  • Page 8: Main Door Switch Assembly

    Main Door Switch Assembly Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Main Door Switch ONLY 881702 Main Door Switch Housing Assembly Complete (white) (includes illus.

  • Page 9: Temperature Sensor Bracket Assembly

    Illus. No. Part No. Qty. Description 859372 Temperature Sensor Bracket Complete (includes illus. nos. 1 through 6 and 9 through 12) 881089 Sensor Bracket 884258 4” Temperature Sensor Probe Assembly 154007 1/4” Push-On Fastener 121028 1/4” Terminal 122701 Socket Terminal ONLY 122605 4-Position Female Connector 122700...

  • Page 10: Wrapper Assembly

    Wrapper Assembly Illus. No. Part No. Qty. Description 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 859367 Bottom Right Wrapper –––––– Idler Shaft (refer to Idler Shaft Assembly on page 14) –––––– Temperature Sensor Bracket (refer to Temperature Sensor Bracket Assembly on page 9) 859368 Bottom Left Wrapper ––––––...

  • Page 11: Lint Drawer Assembly

    Illus. No. Part No. Qty. Description 883305 Lint Drawer Assembly (includes illus. nos. 1 through 3) 115902 Lint Basket Felt 154215 5/32 x 1/4” Rivet * Specify color when ordering. 450569 - 5 Lint Drawer Assembly www.amdry.com...

  • Page 12: Tumbler Assembly

    Tumbler Assembly Illus. No. Part No. Qty. Description 835002 Tumbler Assembly Complete (for models mfd. as of April 9, 2007) (includes illus. nos. 1 through 3) 859389 Tumbler Assembly Complete (for models mfd. prior to April 9, 2007) (includes illus. nos. 1 through 3) 333670 Perforated Tumbler Panel (for models mfd.

  • Page 13: Phase 7 Rotational Sensor Assembly

    Illus. No. Part No. Qty. Description 819064 Tumbler Shaft Support Assembly Complete (includes illus. nos. 1 through 8) 835339 Tumbler Shaft Support Bracket 102394 Tumbler Friction Pad 153005 3/8” Lock Washer 150619 3/8-16 x 1” Tap Bolt 153004 3/8” Flat Washer 180018 4”...

  • Page 14: Idler Shaft Assembly

    Idler Shaft Assembly Illus. No. Part No. Qty. Description 859328 Idler Shaft Assembly Complete (includes illus. nos. 1 through 10) 390232 Idler Shaft ONLY 180033 6” Wheel 180038 1” Taper Lock Bushing 880205 1” Pillow Block Bearing 152004 5/16-18 Hex Nut 153002 5/16”...

  • Page 15: Drive Shaft Assembly

    Illus. No. Part No. Qty. Description 859329 Drive Shaft Assembly Complete (includes illus. nos. 1 through 11) 390243 Drive Shaft ONLY 180033 6” Wheel 180038 1” Taper Lock Bushing 880205 1” Pillow Block Bearing 152004 5/16-18 Hex Nut 153002 5/16” Lock Washer 153001 5/16”...

  • Page 16: Drive Motor Assembly

    Drive Motor Assembly American Dryer Corporation 450569 - 5...
  • Page 17 Illus. No. Part No. Qty. Description 882245 Drive Motor Assembly Complete (includes illus. nos. 1, 2, 6, and 9 through 11) 882237 Motor Mount ONLY 152004 5/16-18 Hex Nut 150501 5/16-18 x 3/4” Tap Bolt 153001 5/16” Flat Washer 153002 5/16”...

  • Page 19: Direct Spark Ignition Burner Assembly

    Illus. No. Part No. Qty. Description 142924 1” to 3/4” Reducing Coupling 331291 Gas Valve Pipe Bracket 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 142735 3/4” x 14” Bi Nipple 142601 3/4” Union 142504 3/4” x 90° Elbow 142734 3/4”...

  • Page 20: Motorized Impellor (Fan) Assembly

    Motorized Impellor (Fan) Assembly Illus. No. Part No. Qty. Description 882319 Coop Cone (white) 882328 Coop Cone (wrinkle coral blue) 887140 Motorized Impellor (fan) – 208 Volt 60 Hz ONLY (for models mfd. as of February 23, 2007) 887139 Motorized Impellor (fan) – 208 Volt 60 Hz ONLY (for models mfd.

  • Page 21: Pneumatic Valve Assembly

    Illus. No. Part No. Qty. Description 330987 Micro Valve Bracket 836002 Air Jet Solenoid 150111 1/4-20 x 1/2” Phillips Round Head Machine Screw 152014 1/4-20 Free Spin Wash Nut 151000 #6-32 Pal Nut 100472 1/4” x 1/8” Male Connector 150002 #6-32 x 1”...

  • Page 22: Reversing Relay Panel Assembly For Models Mfd. Prior To February 10, 2006

    Reversing Relay Panel Assembly For Models Mfd. prior to February 10, 2006 Illus. No. Part No. Qty. Description 150008 #6-32 x 1-1/4” Phillips Round Head Machine Screw 120701 4-Position Terminal Block 859356 208 Volt Reversing Relay Panel Assembly Complete (includes illus. nos. 1 through 15) 323743 Reversing Relay Panel ONLY 151000...

  • Page 23: Reversing Relay Panel Assembly For 208-240 Volts For Models Mfd. As Of February 10, 2006

    Illus. No. Part No. Qty. Description 150539 #8 x 1-1/4” PH Phillips AB Zinc Screw 120701 4-Position Terminal Block 323743 Relay Panel 152002 1/4-20 Hex Nut 153021 1/4” Lock Washer 121012 Ground Lug 136057 0.5-Amp 3AG Slo-Blo Fuse 150301 #8-18 x 7/16” Phillips Head TEK Screw 136008 Fuse Holder 132496...

  • Page 24: Reversing Relay Panel Assembly For 380-416 Volts For Models Mfd. As Of March 2, 2006

    Reversing Relay Panel Assembly for 380-416 Volts For Models Mfd. as of March 2, 2006 Illus. No. Part No. Qty. Description 150539 #8 x 1-1/4” PH Phillips AB Zinc Screw 120701 4-Position Terminal Block 323743 Relay Panel 152002 1/4-20 Hex Nut 153021 1/4”...

  • Page 25: Reversing Relay Panel Assembly For 460-480 Volts For Models Mfd. As Of March 2, 2006

    Illus. No. Part No. Qty. Description 150539 #8 x 1-1/4” PH Phillips AB Zinc Screw 120701 4-Position Terminal Block 323743 Relay Panel 136057 0.5-Amp 3AG Slo-Blo Fuse 152002 1/4-20 Hex Nut 153021 1/4” Lock Washer 121012 Ground Lug 135501 2-Pole 1-Amp Circuit Breaker 150301 #8-18 x 7/16”...

  • Page 26: Air Jet Assembly For Models Mfd. Prior To April 2, 2004

    Air Jet Assembly For Models Mfd. prior to April 2, 2004 Illus. No. Part No. Qty. Description 143100 1/4” Aluminum Tubing (sold by the foot) 143287 1/4” x 1/8” M.P.T. Male Run Tee 143259 1/4” x 1/8” F.P.T. Bulkhead Fitting 143115 1/4”...

  • Page 27: Air Jet Assembly For Models Mfd. As Of April 2, 2004

    Illus. No. Part No. Qty. Description 859401 Air Jet Tubing II 143259 Bulkhead Fitting, 1/4 Tube x 1/8” F.P.T. 143115 4’ 1/4” Dia Poly-Flo Tube 143154 1/4” Poly Union 143250 1/8” M.P.T. Brass Plug 330987 Bracket 143149 1/4” Poly x 1/8” M.P.T. 90° Elbow 822734 Air Jet Solenoid 150002...

  • Page 28: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 105500 Sail Switch Actuator Rod 319202 Sail Switch Damper (flat) 154002 1/8” Push-On Fastener 802800 Sail Switch Box with Cover and Bracket ONLY 802801 Sail Switch Box Assembly Complete (includes illus. nos. 1 through 4 and 6 through 10) 150309 #10-16 x 1/2”...

  • Page 29: F.s.s. Temperature Probe Assembly

    Illus. No. Part No. Qty. Description 822752 Fire Suppression System Temperature Probe Assembly (includes illus. nos. 1 through 5) 154007 Push-On Fastener 390390 Sensor Bracket ONLY 150301 #8-18 Phillips Pan Head TEK Screw 122647 Connector ONLY 122700 450569 - 5 F.S.S.

  • Page 30: Solenoid Assembly For Models Mfd. Prior To October 2, 2002

    F.S.S. Solenoid Assembly For Models Mfd. prior to October 2, 2002 Illus. No. Part No. Qty. Description 165114 Solenoid Valve 24 VAC 50/60 Hz 143220 3/8” F.P.T. Brass Tee 143251 3/8” M.P.T. Brass Plug 143208 3/8” Comp x 3/8” M.P.T. Brass Connector 143108 20”...

  • Page 31: Solenoid Assembly For Models Mfd. As Of October 2, 2002

    Illus. No. Part No. Qty. Description 143581 Fire Suppression System 3 GPM 0.375 N.P.T. Spray Nozzle 143303 0.375 N.P.T. Brass Lock Nut 136987 Water Jet Pressure Switch 143025 0.75-11.5 NH x 0.375 N.P.T. Nylon Hose Adapter 143251 0.375 M.P.T. Brass Plug 182579 0.375 M.P.T.

  • Page 32: Exhaust Collar Assembly

    Exhaust Collar Assembly Illus. No. Part No. Qty. Description 883281 Adapter Collar with Back Draft Damper 152014 1/4-20 Free Spin Wash Nut American Dryer Corporation 450569 - 5...
  • Page 33 Notes _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ 450569 - 5 www.amdry.com...
  • Page 34 ADC Part No. 450569 5 - 01/20/09 - 0...
