HB50 / ES50 / M50ES
Installation/Operator Manual
WARNING: For your safety the information
in this manual must be followed to
minimize the risk of fire or explosion and
to prevent property damage, personal
injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Clear the room, building or area of
all occupants.
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
—Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
—QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareils.
Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
Évacuez la pièce, le bâtiment ou la
zone.
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
—L'installation et l'entretien doivent être
assurés par un installateur ou un
service d'entretien qualifié ou par le
fournisseur de gaz.
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
e-mail: techsupport@amdry.com
www.adclaundry.com
ADC Part No. 113014 - 14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADC HB50
Summary of Contents for ADC HB50
- Page 1 HB50 / ES50 / M50ES Installation/Operator Manual AVERTISSEMENT: Assurez-vous de bien WARNING: For your safety the information suivre les instructions données dans cette in this manual must be followed to notice pour réduire au minimum le risque minimize the risk of fire or explosion and d’incendie ou d’explosion ou pour éviter...
- Page 2 Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory, you can FAX your order to ADC at +1 (508) 678-9447 or telephone your order directly to the ADC Parts Department at +1 (508) 678-9000. Please specify the dryer model number and serial number in addition to the description and part number, so that your order is processed accurately and promptly.
-
Page 3: Table Of Contents
WARNING WARNING Children should not be allowed to play on or near the dryer(s). Children should be supervised if Proposition 65 near dryer(s) in operation. Use of this product could expose you to substances Under no circumstances should the dryer door from fuel combustion that contain chemicals switch(es), lint door/drawer switch(es), or heat known to the State of California to cause cancer,... -
Page 4: Safety Precautions
Safety Precautions ___________________ A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork, and Warning area around the back of the dryer. The frequency of inspection and cleaning can best be determined from For your safety, the information in this manual experience at each location. - Page 5 The “Cool Down” Cycle of tumble dryers should be used to reduce the temperature of the items. They should not be NOTES _____________________________________________________ removed from the tumble dryer or piled or stacked while hot. ____________________________________________________________ Fabric softeners or similar products should not be used in a ____________________________________________________________ tumble dryer to eliminate the effects of the static electricity, unless this practice is specifically recommended by the...
-
Page 6: Specifications
Specifications _____________________________________________________________________ 22.68 kg MAXIMUM CAPACITY (DRY WEIGHT) 50 lb 93.98 cm TUMBLER DIAMETER 37” TUMBLER DEPTH 25-3/4” 65.41 cm TUMBLER VOLUME 16.02 cu ft 453.64 L 0.56 kW TUMBLER/DRIVE MOTOR 3/4 hp 0.37 kW BLOWER/FAN MOTOR 1/2 hp DOOR OPENING (DIAMETER) 27-3/8”... - Page 7 Specifications _____________________________________________________________________ 113014 - 14 www.adclaundry.com...
-
Page 8: Installation Procedures
Installation Procedures ______________ Unpacking / Setting Up _______________ Installation should be performed by competent professional Remove protective shipping material (i.e., plastic wrap and in accordance with local, state, and country codes. In the optional shipping box) from the dryer. absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- IMPORTANT: Dryer must be transported and handled in LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA... -
Page 9: Fresh Air Supply Requirements
Fresh Air Supply Requirements ______ Exhaust Requirements _______________ This appliance may only be installed in a room that meets Exhaust ductwork should be designed and installed by a the appropriate ventilation requirements specified in the qualified professional. Improperly sized ductwork will create national installation regulations. - Page 10 Outside Ductwork Protection To protect the outside end of the horizontal ductwork from the weather, a 90° elbow bent downward should be installed where the exhaust exits the building. If the ductwork travels vertically up through the roof, it should be protected from the weather by using a 180°...
-
Page 11: Electrical Information
IMPORTANT: A separate protected circuit must be A = 8-inch (20.32 cm) B = 20 feet (6 meters) provided to each dryer. The dryer must be connected to the electric supply shown on the data label. In the case of 208 VAC or 240 VAC, the supply voltage must match the electric service specifications of the data label exactly. - Page 12 Electric Models Only For added personal safety, when possible, it is suggested that a separate ground wire (size per local codes) be All electrically heated dryers must be connected to the connected from the ground connection of the dryer to a electric service shown on the dryer’s data label.
-
Page 13: Gas Information
Gas Information ______________________ IMPORTANT: A strain relief must be used where the input wiring enters the oven assembly. It is your responsibility to have all plumbing connections, Electrically Heated Models Only materials, and workmanship conform to local and state regulations or codes of the country of destination. In the The electrical input connections are made at the rear service absence of such codes, all plumbing connections, box located at the right upper section of the dryer. - Page 14 CE and Australian Dryers There is an N.P.T. to B.S.P.T. adaptor included with each dryer, which must be installed to the gas inlet. The adaptor is shipped in the tumbler. IMPORTANT: Pipe joint compounds that resist the action of natural, propane, and butane gases must be used. Heat Input / Gas Consumption / Orifice (Injector) Data Gas Specifications for Non-CE and Non-AGA Approved Dryers**...
- Page 15 The following conversion allows the dryer to be operated with either propane, butane, or LPG. The use of gas valve kit (ADC P/N 140414) disables the internal regulator of the gas valve. Therefore, the gas supply is ungoverned and an external regulator must be provided at the source of the supply (example L.P.
- Page 16 Be sure the tab at the rear of the gas train engages into the natural gas. mounting slot. Connect the union and the 3 electrical plugs. Parts Required for Conversion: Affix L.P. Conversion Label (ADC P/N 114515) to the dryer’s Description ADC P/N data label. Vent Cap and Spring 140415 Complete L.P.
-
Page 17: Gas Pressure Testing
This appliance must only be operated with the screw (under vent cap). Remove spring under screw gas type indicated on the dryer’s data plate. If and replace with spring from kit (ADC P/N 140415). the appliance is converted (gas type changed), a data Replace regulator adjustment screw. -
Page 18: Steam Information
Steam Information ____________________ Steam Requirements – High Pressure It is your responsibility to have all plumbing connections made Operating Steam Pressure by a qualified professional to ensure that the steam plumbing 1.0 MPa Maximum psig* installation is adequate and conforms with local, state, and country regulations or codes. -
Page 19: Water Information
Water Connections Flexible hoses or couplings must be used. The dryer vibrates slightly when it runs and this will cause the steam The water connection is made to the 3/4”-11.5 NH hose coil connections to crack if they are hard piped to the supply adaptor, which is shipped in the tumbler and must be installed and return mains. -
Page 20: Preoperational Test
Microprocessor Programs / Selections • STEAM MODELS – Check to ensure all steam shutoff valves are open. Each microprocessor controller (computer) has been preprogrammed by the factory with the most commonly used Preoperational Test __________________ parameter (program) selections. If computer program changes are required, refer to the computer programming manual, which was shipped with the dryer. -
Page 21: Shutdown Instructions
IMPORTANT: A separate warranty card must be Shipping charges are not the responsibility of ADC. All completed and returned for each individual dryer. returns should be “prepaid” to the factory. Any “C.O.D.” or “COLLECT”... -
Page 22: Routine Maintenance
Steam Dryers IMPORTANT: No replacements, credits, or refunds will be issued if the claim cannot be processed due to insufficient Clean the steam coil fins. It is suggested that compressed information. The party filing the claim will be notified in air and a vacuum cleaner with brush attachment be used. -
Page 23: Data Label Information
Data Label Information ____________________________________________________________ CE Label Standard Label When contacting ADC, the information on the data label is required to ensure proper service/parts assistance. The data AGA Label label is located at the upper left rear of the dryer behind the back guard. -
Page 24: Programming
Programming _________________________ Event Codes Defined: Top Pocket / Bottom E1 / E4: While attempting to turn on the burner, no burner return Enter Service Mode by Inserting Key and Turning Clockwise signal was received within RADIANT SENSOR COOL DOWN TIME. Main Service Mode window will appear and offer 5 selections: 1: Machine Info 2: Program Setup... - Page 25 NOTES __________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ 113014 - 14 www.adclaundry.com...
- Page 26 ADC Part No. 113014 14 - 03/26/14...
