Bathroom Thermo Ventilator / 浴室換氣暖風機
MODEL / 型號
V-251BW-HK
Installation Manual / 安裝手冊
Contents / 目錄
1. Safety Precautions / 安全須知 ..........................................................................................2
3. Selecting Installation Position / 選擇安裝位置 ..................................................................5
4. Method of Installation / 安裝方法 ......................................................................................6
5. Checks after Installation / 安裝後檢查 ........................................................................... 12
6. Trial Operation / 運轉試驗.............................................................................................. 12
7. Checking and Changing Initial Values / 檢查和變更初始值 ........................................... 14
8. Explanations to the Customer / 向客戶介紹 .................................................................. 14
9. Troubleshooting / 故障排除............................................................................................ 15
■ Correct installation is essential to achieve full performance and
functionality of this product and to ensure safety. Carefully read
this Installation Manual before installation.
■ This product is for domestic use. Do not use it for commercial
applications.
■ The bipolar switch, connection unit, and earth leakage circuit
breaker are not included with this product. Purchase commercially
available products separately.
■ In the event of any conflict between the English and Traditional
Chinese, the English version shall prevail.
[ 220 V single-phase / 220 V 單相 ]
For Dealers and Contractor / 經銷商和承包商專用
■ 正確安裝對於實現本產品的完整效能與功能
以及確保安全性至關重要。安裝前請仔細閱
讀本安裝手冊。
■ 本產品僅供家用。請勿將其用於商業用途。
■ 本產品不附帶雙極開關、連接單元和接地漏
電斷路器。請自行購買市售產品。
■ 若英文版與繁體中文版之間有任何衝突，以
英文版為準。
1810876HF7301
Page / 頁次
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric V-251BW-HK
Summary of Contents for Mitsubishi Electric V-251BW-HK
-
Page 1: Table Of Contents
1810876HF7301 Bathroom Thermo Ventilator / 浴室換氣暖風機 MODEL / 型號 V-251BW-HK [ 220 V single-phase / 220 V 單相 ] Installation Manual / 安裝手冊 For Dealers and Contractor / 經銷商和承包商專用 Contents / 目錄 Page / 頁次 1. Safety Precautions / 安全須知 ..................2 2. Names and Dimensions of Parts (Dimensional Drawings) / 部件名稱和尺寸(尺寸圖) ..4 3. Selecting Installation Position / 選擇安裝位置 ..............5 4. Method of Installation / 安裝方法 ..................6 5. Checks after Installation / 安裝後檢查 ................12 6. Trial Operation / 運轉試驗.................... -
Page 2: Safety Precautions / 安全須知
1. Safety Precautions / 安全須知 The table below classifies the degree of danger The symbols used in this manual and on the main from incorrectly handling or using the product. unit indicate the following meanings. 下表對產品不當處理或使用的危險程度進行了分類。 本手冊和主機上使用的符號表示以下含義。 Incorrect handling or use Prohibited The product must be grounded Warning... - Page 3 Warning / 警告 Use a 220 V AC single-phase power supply. 使用220 V AC單相電源。 Using a power supply other than 220 V AC single-phase may 使用220 V AC單相電源以外的電源 cause fire or electric shock. 可能造成火災或觸電。 Electrical work and main unit installation must be performed 電氣作業及主機安裝必須由符合資 safely and reliably by qualified personnel certified by the 質的機電工程署(EMSD)認證人員以 Electrical and Mechanical Services Department (EMSD).
-
Page 4: Names And Dimensions Of Parts (Dimensional Drawings) / 部件名稱和尺寸(尺寸圖)
Names and Dimensions of Parts (Dimensional Drawings) 部件名稱和尺寸(尺寸圖) Panel base Filter Main unit Inlet 面板底座 Panel 濾網 主機 進風口 面板 Mounting holes (4 positions) 安裝孔(4個) Inlet Inlet 進風口 進風口 Circulation 循環 Main unit display Power cable 主機顯示器 (PVC cable (1.5 mm Fixing clip (16AWG) x 3C, effective Ventilation 固定夾 length: approx. 1.5 m)) 換氣 Baffle plate ■ Panel open / 面板打開 電源線... -
Page 5: Selecting Installation Position / 選擇安裝位置
3. Selecting Installation Position / 選擇安裝位置 ■ The product is for bathroom window installation - 起油霧的位置(可能造成故障) only. - 環境溫度超出0℃至40℃範圍的位置(可能造成故障) ■ 本產品僅適用於浴室窗戶安裝。 - 溫度始終高於40℃的位置(在高溫環境下，恆溫器 會阻止加熱器運轉) Mounting frame - 墻裝插座下 安裝架 ■ The system must not be installed within 100 mm from objects (including wet clothes and laundry Aluminium pipes). -
Page 6: Method Of Installation / 安裝方法
3. Selecting Installation Position / 選擇安裝位置 (continued / 續) ■ Requirements during installation [Others / 其他] ■ 安裝期間要求 - To use this product for general ventilation of the house requires ventilation measures (such [Main unit / 主機] as an undercut) in the door of the room. - Install the main unit in the mounting frame - Do not use an impact driver to tighten the from inside the bathroom. - Page 7 1. Make the mounting frame. Installing the main unit 1. 製作安裝架。 安裝主機 Make the mounting frame as shown below. * The maximum length of the mounting frame is 600 mm. Warning / 警告 如下圖所示製作安裝架。 Firmly secure the main unit with screws. * 安裝架的最大長度為600 mm。 It could fall and cause an injury. 用螺絲牢牢固定主機和面板。 275±3 Mounting frame 可能會墜落並造成傷害。 安裝架 1. Caulk around the opening part of the mounting frame.
- Page 8 4. Method of Installation / 安裝方法 (continued / 續) 3. Install the main unit. Electrical work 3. 安裝主機。 電氣作業 Insert the main unit horizontally into the opening in the mounting frame. Warning / 警告 Use the four mounting screws (4 x 25) supplied to firmly secure the main unit in the mounting frame. 將主機水平插入安裝架的開口中。 Do not cut or extend the power cable. 使用隨附的四個安裝螺絲(4 x 25)將主機牢牢固定在安裝 Doing so could cause a fire. 架中。 請勿切割或延長電源線。...
- Page 9 2. Pass the power cable along the bath- Caution / 注意 room wall. 2. 將電源線沿著浴室牆壁佈設。 Earth leakage circuit breaker (leakage When changing the power cable pull-out current not exceeding 30 mA) and circuit breaker shall be directly connected to position from left to right the supply terminals and shall have a 將電源線拉出位置從左側改為右側時...
- Page 10 4. Method of Installation / 安裝方法 (continued / 續) 2. Turn the fixing clips between the panel Note / 備註 and panel base at the left and right sides. - Do not use an impact driver to tighten the screws in the panel.
- Page 11 Installing the remote controller Adjusting the horizontal air direction 安裝遙控器 調整水平風向 1. Insert batteries in the remote controller. Set the direction of the louvres. 1. 將電池裝入遙控器。 The vertical air direction can be adjusted using the remote controller. (1) Remove the rear cover with a coin. 設定百葉方向。 (2) Insert the batteries correctly. 可以使用遙控器調整垂直風向。 (3) Firmly attach the rear cover. (1) 用硬幣拆下後蓋。 (1) Hold down on the remote controller (for 3 (2) 正確裝入電池。 seconds) to open the baffle plate. (3) 牢牢裝好後蓋。 (2) Hold and move the centre louvres at the left and right. The louvres move in sets of three at the left Rear cover and right.
-
Page 12: Checks After Installation / 安裝後檢查
5. Checks after Installation / 安裝後檢查 Check the following items before trial operation. Be sure to put a tick mark in the corresponding tick box □. Perform trial operation after making these checks. 運轉試驗前請檢查以下項目。 務必在相應的勾選框中打上勾號□。 請先進行這些檢查，然後再執行運轉試驗。 (1) Product installation check / 產品安裝檢查 Reference page / 參考頁次... - Page 13 3 Operation checks / 運轉檢查 Check the operation according to the table below. After checking the operation, hold down the button for at least 3 seconds to fully stop the product, and then turn off the circuit breaker. 根據下表檢查運轉。檢查運轉後，按住 按鈕至少3秒以完全停止產品，然後關閉斷路器。 Operating mode Operation Display Description □ 運轉模式 操作 描述 顯示器 Check that ventilation occurs at the Press the button. 24-hour inlet on the main unit panel. □ ventilation 按 按鈕。 檢查主機面板上的進風口是否換氣。 24小時換氣 Check that ventilation occurs at the Press the button. inlet on the main unit panel. (The air The function toggles each volume for 24-hour ventilation is the time the button is pressed. Ventilation same as for low ventilation) □ 換氣...
-
Page 14: Checking And Changing Initial Values / 檢查和變更初始值
7. Checking and Changing Initial Values / 檢查和變更初始值 Refer to the Instruction Manual. 請參閱使用說明書。 8. Explanations to the Customer / 向客戶介紹 ● If the customer is unavailable, the explanations can be made to the person who placed the order (the owner, etc.) or manager. ● Explain the correct method of use according to the separate Instruction Manual. Emphasize the importance of following the "Safety Precautions" section, which describes important safety- related information. ● After installation, hand this Installation Manual to the customer. Also hand the supplied Instruction Manual and display stickers to the customer. ● 若客戶無法在場，應向下訂單的人員(物主等)或經理進行介紹。 ● 根據單獨的使用說明書介紹正確的使用方法。 強調遵循「安全須知」部分的重要性，該部分說明重要的安全相關資訊。 ● 安裝完成後，將本安裝手冊交給客戶。此外，請將隨附的使用說明書和顯示貼紙交給客戶。... -
Page 15: Troubleshooting / 故障排除
9. Troubleshooting / 故障排除 Perform an inspection if any of the following symptoms occurs. Turn off the circuit breaker in the distribution board before starting the inspections. 若出現以下任何現象，請執行檢查。在開始檢查之前，請關閉配電板中的斷路器。 Symptom / 現象 Cause and Remedy / 原因和改進措施 Inspect the circuit breaker. An independent circuit breaker with 13 A Is power supplied to the main unit? or greater capacity is required. 主機是否通電？ 檢查斷路器。 No operation 需要一個容量為13 A或以上的獨立斷路器。 不運轉 Starting operation and switching operation functions can take about 40 This is not a malfunction. seconds. 這不是故障。 開始運轉和切換運轉功能大約需要40秒。 Cooling operation continues for about Operation does not stop This is not a malfunction. 15 seconds after heater operation stops. 無法停止運轉 這不是故障。 加熱器運轉停止後，涼風運轉持續約15秒。 It takes too long to start operation Switching the air flow path or cooling the or switch operation functions This is not a malfunction. main unit can take about 40 seconds. 等很長時間才會開始運轉或切 這不是故障。 切換氣流路徑或主機冷卻大約需要40秒。 換運轉功能... - Page 16 MITSUBISHI ELECTRIC CORPORATION NAKATSUGAWA WORKS 1-3 Komaba-cho, Nakatsugawa-city Gifu-pref. 508-8666, Japan 三菱電機株式会社 中津川製作所 〒508-8666 岐阜県中津川市駒場町1番3号 原產國: 日本 製造商: 三菱電機株式會社...
