- Page 1 INSTALLATION & MAINTENANCE MANUAL BATCxx EMERGENCY BATTEN...
- Page 2 GENERAL INSTRUCTIONS INSTRUCTIONS – BATCxx These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. ons should be read carefully and retained after installation by the end user for future reference and These instructions should be used to aid installation of the following products: BATC4EM / BATC5EM / BATC5EMH / BATC6EM / BATC6EMH ons should be used to aid installation of the following products:...
- Page 3 PART CODE DISTANCE (MM) BATC4EM BATC5EM / BATC5EMH 1265 BATC6EM / BATC6EMH 1529 Ensuring correct polarity is observed, carefully wire as shown in Fig. 2 • • Ensuring correct polarity is observed, carefully wire as shown in Fig. 2 Live (brown) Switched Live (brown) Earth (green/yellow) Neutral (blue)
- Page 4 WARRANTY This product has a warranty of 5 years from date of purchase. Failure to install this product in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch codes will invalidate the warranty. If this product should fail within its warranty period it should be returned to the place of purchase for a free of charge replacement.
