- Page 1 ECR90 Extractor Installation, use and maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 safety (LVD) and Electromagnetic interference compatibility (EMC). IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 • Do not use silicone sealant to secure the hood to the wall. • You must be able to isolate the extractor from the mains electrical supply after installation. • This extractor has been designed to be used in a room with a volume of less than 36m3.
-
Page 5: Using Your Extractor
Using your Extractor For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking. Control Panel A - Power off button B - Speed level buttons C - Light button Fig. - Page 6 You can clean your extractor effectively by simply using a dilute solution of water and mild detergent and drying to a shine with a clean cloth, for example the CDA E-Cloth. Cleaning the grease filters The grease filters should be kept clean to minimise the risk of fire.
- Page 7 After rinsing and drying, reassemble the grease filter to the hood by reversing the removal process. Please note: Cleaning the grease filters in the dishwasher may lead to discolouration. This is normal and does not constitute a fault with the appliance.
-
Page 8: Mains Electricity Connection
Mains Electricity Connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A FUSE. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. - Page 9 Assembly and electrical connection should be carried out by specialised personnel. When installing this product we recommend you seek the help of another individual. DOUBLE POLE SWITCHED FUSED SPUR OUTLET USE A 3 AMP FUSE...
-
Page 10: Electrical Information
1. Check that the mains supply has not been switched off. 2. Check that the fuse in the spur has not blown. Contact CDA Customer Care A: Customer Care Department, The CDA Group Ltd, Harby Road, Langar, Nottinghamshire, NG13 9HY T: 01949 862 012 F: 01949 862 003 E: customer.care@cda.eu... -
Page 11: Mounting Your Extractor
Mounting your Extractor When the extractor is to be installed above an electric hob, the minimum distance between the hob and extractor must exceed 600mm (650mm is recommended). When the extractor is to be installed above a gas hob, the minimum distance Gas: 750mm recommended. -
Page 12: Installation
IN THE ABSENCE OF ANY INSTRUCTIONS SUPPLIED WITH THE GAS HOB, THE MINIMUM DISTANCE BETWEEN THE HOB AND EXTRACTOR MUST BE AT LEAST 760mm. The width of any hob must not be greater than the width of the extractor installed above it. Installation The metal casing of this appliance has been coated with a preservative to protect it during transport and storage. - Page 13 Tools required Mark wall as required (see table 2) Figu re 2 - M ar k wal l as req ui red (see ta bl e 1) Fig. 5 Fig. 6 Drill holes Fit wall fixings and top screws - Ensure Figu re 3 - D rill h oles that any fixings you use are appropriate for the wall type.
- Page 14 Fig. 12 Fig. 11 Adjust and secure the chimney Mount the chimney Fig. 14 Fig. 13 E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 15 Measured power consumption in standby mode Sound power level 69.8 (D) Hood c i f 56.3 (A) Hood E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 16 Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
