- Page 1 Revision 1 Revision 1 January 2006 January 2006 January 2006 S-10 Ab Crunch Owner’s Manual Record Serial Number Here Batca Fitness Systems Tel. (919) 255-1233 www.batcafitness.com Date of Purchase www.batcafitness.com S-10 Owner’s Manual...
- Page 2 Instructions Congratulations on the purchase of your new Batca S-10. This gym will provide you with a lifetime of enjoyment to meet your strength training needs. Batca Fitness Systems strives to build the best quality gyms and to package these gyms in such a way to avoid any damage during shipping.
- Page 3 BFH-50250 5/16"-18 Nylock (Black) BFH-50267 • 9/16” Wrench HCS 3/8"-16 X 3 1/2" P5 BFH-50127 • 3/4” Wrench Cable Strap BFH-50227 • 5/16” Flat Washer (Zinc) 9/16” Ratchet BFH-50151 • Allen Wrench Set • Tape Measure www.batcafitness.com S-10 Owner’s Manual...
- Page 4 Bolt Length Note: Bolt length is measured from the underside of the head of the bolt. Batca Fitness Systems S-10 Owner's Manual...
- Page 5 S-10 Owner’s Manual...
- Page 6 Batca Fitness Systems S-10 Owner's Manual...
- Page 7 S-10 Owner’s Manual...
- Page 8 Anti-Deflection Plate BFH-50146 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50126 HCS 3/8"-16 x 3 1/4" P5 BFH-50130 HCS 3/8"-16 x 4 1/4" P5 BFH-50145 FHSCS 3/8"-16 x 2 1/4" BFH-50255 Rubber Foot Batca Fitness Systems S-10 Owner's Manual...
- Page 9 Figure 2A BFH-50122 HCS 3/8"-16 x 2 1/4" P5 BFH-50530 5" Pulley BFC-50127 Magnetic Weight Stack Pin BFH-50127 HCS 3/8"-16 x 3 1/2" P5 BFM-50635 Selector Shaft All Flat Washers and Nylocks are 3/8” unless otherwise noted. www.batcafitness.com S-10 Owner’s Manual...
- Page 10 Anti-Deflection Plate BFH-50146 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50126 HCS 3/8"-16 x 3 1/4" P5 BFH-50130 HCS 3/8"-16 x 4 1/4" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. Batca Fitness Systems S-10 Owner's Manual...
- Page 11 Pillow Block Bearing BFM-10420 Ab Crunch Cam BFH-50146 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50120 HCS 3/8"-16 x 1 1/2" P5 BFH-50151 5/16” Flat Washer (Zinc) All Flat Washers and Nylocks are 3/8” unless otherwise noted. www.batcafitness.com S-10 Owner’s Manual...
- Page 12 Counter Weight BFM-10334 Ab/Back Pivot Roller BFH-50220 Threaded Collar BFH-50146 3/8" Flat Washer (Black) BFH-50147 3/8" Lock Washer (Black) BFH-50118 HCS 3/8"-16 x 1" P5 All Flat Washers and Nylocks are 3/8” unless otherwise Batca Fitness Systems S-10 Owner's Manual...
- Page 13 3" Plastic Washer BFH-50146 3/8" Flat Washer (Black) BFH-50126 HCS 3/8"-16 x 1 1/4" P5 BFH-50147 3/8" Lock Washer (Black) BFH-50254 HCS 3/8"-16 x 3/4" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. www.batcafitness.com S-10 Owner’s Manual...
- Page 14 HCS 3/8"-16 x 2" P5 BFH-50250 1 1/4" Shoulder Bolt BFH-50267 5/16"-18 Nylock (Black) BFM-10133 Free Floater CAB-12012 Weight Stack to Lockout Cable 1 All Flat Washers and Nylocks are 3/8” unless otherwise noted. Batca Fitness Systems S-10 Owner's Manual...
- Page 15 HCS 3/8"-16 x 5 1/4" P5 BFM-50345 Pulley Cover BFH-50250 1 1/4" Shoulder Bolt BFH-50267 5/16"-18 Nylock (Black) CAB-12009 Ab Crunch to Free Floater Cable BFH-50227 Cable Strap All Flat Washers and Nylocks are 3/8” unless otherwise www.batcafitness.com S-10 Owner’s Manual...
- Page 16 Record your serial number on the front of this manual and keep for your records. The serial number can be found on the side of the cage as seen in the figure to the left.. Batca Fitness Systems S-10 Owner's Manual...
-
Page 17: Cable Adjustments
Note: If the top plate raises off of the second plate in the weight stack, then the cable tension is too tight. You will need to take some of the tension out to lower the Top plate flush with the second plate. www.batcafitness.com S-10 Owner’s Manual... -
Page 18: Preventive Maintenance
Preventive Maintenance Batca Fitness Systems strives to give you the very best in quality, performance and safety through carefully engineered designs and excellent workmanship. In order to maintain this high level of quality the preventative maintenance schedule below should be followed. -
Page 19: Limited Lifetime Warranty
Batca Fitness Systems warrants all of its products against defects in manufacturing, materials and workmanship under nor- mal use and service for one year from date of purchase including paint, chrome, upholstery and grips. Batca Fitness Sys- tems also warrants all cables, belts, bolts, nuts, caps, plugs, bumpers, washers, levelers, decals, gas springs and other hardware for three years after date of purchase;... -
Page 20: Layout Diagram
Layout Diagram The S-10 has a layout dimension of 3’-3” (width) x 3’-8” (length) x 5’-5” (height). There should be a minimum of 18”, preferably 24”, of working space around the entire unit. Batca Fitness Systems S-10 Owner's Manual...
