Summary of Contents for Batca C-11
- Page 1 Revision 4 Revision 4 September 2006 September 2006 September 2008 C-11 Assisted Chin/ Dip Owner’s Manual Record Serial Number Here Batca Fitness Systems Tel. (919) 255-1233 www.batcafitness.com Date of Purchase www.batcafitness.com C-11 Owner’s Manual...
- Page 2 Instructions Congratulations on the purchase of your new Batca C-11. This gym will provide you with a lifetime of enjoyment to meet your strength training needs. Batca Fitness Systems strives to build the best quality gyms and to package these gyms in such a way to avoid any damage during shipping.
- Page 3 Allen Wrench Set BFH-50262 Silicone Gel Pack • Tape Measure BFH-50274 HCS 3/8”-16 X 4 3/4” P5 BFH-50627 Linear Bearing BFH-50628 Bearing Retaining Clip BFH-50633 1-1/4” Grip Cap BFM-51279 1-1/4” Grip Sleeve BFH-50632 1-1/4” Grip Collar www.batcafitness.com C-11 Owner’s Manual...
- Page 4 Bolt Length Note: Bolt length is measured from the underside of the head of the bolt. Batca Fitness Systems C-11 Owner's Manual...
- Page 5 C-11 Owner’s Manual...
- Page 6 Batca Fitness Systems C-11 Owner's Manual...
- Page 7 C-11 Owner’s Manual...
- Page 8 Anti-Deflection Plate BFH-50146 3/8" Flat Washer (Black) Figure 1 BFH-50157 3/8"-16 Nylock (Black) BFH-50125 HCS 3/8"-16 X 3" P5 BFH-50129 HCS 3/8"-16 X 4" P5 BFH-50130 HCS 3/8"-16 X 4 1/4" P5 BFH-50255 Rubber Foot Batca Fitness Systems C-11 Owner's Manual...
- Page 9 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50127 HCS 3/8"-16 X 3 1/2" P5 BFH-50126 HCS 3/8"-16 X 3 1/4" P5 BFH-50274 HCS 3/8”-16 X 4 3/4” P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. www.batcafitness.com C-11 Owner’s Manual...
- Page 10 Anti-Tip Figure 3 BFH-50146 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50125 HCS 3/8"-16 X 3" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. BFH-50129 HCS 3/8"-16 X 4" P5 Batca Fitness Systems C-11 Owner's Manual...
- Page 11 HCS 3/8"-16 X 3 1/4" P5 Figure 4 BFH-50112 Screw Cap Cover BFH-50113 Screw Cap Washer BFH-50633 1-1/4” Grip Cap BFM-51279 1-1/4” Grip Sleeve BFH-50632 1-1/4” Grip Collar All Flat Washers and Nylocks are 3/8” unless otherwise noted. www.batcafitness.com C-11 Owner’s Manual...
- Page 12 BFH-50157 3/8"-16 Nylock (Black) BFH-50122 HCS 3/8"-16 X 2 1/4" P5 BFH-50250 1 1/4" Shoulder Bolt BFH-50267 5/16"-18 Nylock (Black) BFH-50256 1/2” Jam Nut All Flat Washers and Nylocks are 3/8” unless otherwise noted. Batca Fitness Systems C-11 Owner's Manual...
- Page 13 BFH-50147 3/8" Lock Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50254 HCS 3/8-16 X 3/4 P5 BFH-50123 HCS 3/8"-16 X 2 1/2" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. BFH-50534 FHSCS 3/8"-16 X 1 1/4" www.batcafitness.com C-11 Owner’s Manual...
- Page 14 • Clean guide rods with a lint-free cloth and apply a thin layer of silicon lubricant (Part # BFH-50262) to each guide rod. This will ensure a glass smooth performance from your weight stack. Batca Fitness Systems C-11 Owner's Manual...
- Page 15 The threaded bolt on the end of the cable must be threaded at least 1/2” the Top Plate of the weight stack. The bolt must also be secured with a 1/2” Jam Nut to ensure a safe and proper connection. www.batcafitness.com C-11 Owner’s Manual...
- Page 16 Preventive Maintenance Batca Fitness Systems strives to give you the very best in quality, performance and safety through carefully engineered designs and excellent workmanship. In order to maintain this high level of quality the preventative maintenance schedule below should be followed.
- Page 17 Batca Fitness Systems warrants all of its products against defects in manufacturing, materials and workmanship under nor- mal use and service for one year from date of purchase including paint, chrome, upholstery and grips. Batca Fitness Sys- tems also warrants all cables, belts, bolts, nuts, caps, plugs, bumpers, washers, levelers, decals, gas springs and other hardware for three years after date of purchase;...
- Page 18 Layout Diagram The C-11 has a layout dimension of 3’-7” (width) x 4’-4” (length) x 7’-4” (height). There should be a minimum of 18”, preferably 24”, of working space around the entire unit. Batca Fitness Systems C-11 Owner's Manual...
