J S E R I E S
O u t d o o r · G a s · F i r e p l a c e
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
--An LP cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Solid fuels shall not be burned in this appliance.
J Series Outdoor Gas Fireplace
WARNING: Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Read the
installation, operating, and maintenance
instructions thoroughly before installing or
servicing this equipment.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING: FOR OUTDOOR USE ONLY
Report # 0284GF009S
1
Installation,
Operation,
and
Owner's Manual
J-60-1
J-60-ST
Gas Fireplaces
EuropeanHome.com
April 2017
Advertisement
Table of Contents
Related Manuals for European Home J-60-1
Summary of Contents for European Home J-60-1
- Page 1 Installation, Operation, Owner’s Manual J S E R I E S J-60-1 J-60-ST O u t d o o r · G a s · F i r e p l a c e Gas Fireplaces WARNING: Improper installation, adjustment,...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information Important Safety Information About Propane Specifications and Dimensions Clearances Installation Gas Installation Operating the Fireplace Maintenance Parts List Installation Record Warranty Appendix A LP Conversion Appendix B EuropeanHome.com J Series Outdoor Gas Fireplace... -
Page 3: Important Safety Information
Read these instructions carefully before installing or trying to operate this Vent Free decorative gas appliance. Thank you for purchasing a J Series Outdoor Gas Fireplace by European Home. This fireplace has been designed to provide you with safe, trouble-free operation. -
Page 4: Important Safety Information About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS This gas fireplace is equipped at the factory for use with natural gas. If conversion to propane (LP) is desired, the optional factory-supplied conversion kit must be used. When using propane (LP), the gas supply cylinder to be used must be: 1) constructed and marked in accordance with the U.S. -
Page 5: Specifications And Dimensions
SPECIFICATIONS and DIMENSIONS SPECIFICATIONS Model(s) J-60-1, J-60-ST Natural Propane Input Btu/hr. 76,000 76,000 in. w.c. 7” w.c. Minimum NG Supply Pressure 1.74 kPa in. w.c. 11” w.c. Minimum LP Supply Pressure 2.74 kPa in. w.c. 6.3” w.c. NG Manifold Pressure 1.57 kPa... - Page 6 Dimension J-60-1 & J-60-ST A (overall width) 651/8”* B (viewable width) 60” C (burner length) 491/4” Model J-60-1 shown open, above, and closed, below. D (viewable height) 171/2” E (floor to opening) 71/2” F (overall depth) 18” G (overall height) 27”...
- Page 7 ANSI Z223.1 standard. Installation For installation on (or over) Non-Combustible Floors Only and service must be must be performed by a qualified installer, service agency or the gas supplier. manufactured by: EUROPEAN HOME 376 Washington Street Malden, MA 02148 tel: (781) 324-8383 www.europeanhome.com...
-
Page 8: Clearances
CLEARANCES CLEARANCES TO COMBUSTIBLES MANTEL TRIM Clearances (Front Elevation View) TRIM Clearances (Top Plan View) SIDEWALL 4” Top of fireplace to combustibles 0” Back of fireplace to back combustible wall 4.5” Side of fireplace opening to combustible trim 5.5” Fireplace opening to side wall in front of fireplace 0”... -
Page 9: Installation
INSTALLATION WHEN ENCLOSING YOUR FIREPLACE THE USE OF NON-COMBUSTIBLE BUILDING MATERIALS IS REQUIRED. PLEASE READ AND UNDERSTAND THE FOLLOWING. COMBUSTIBLE MATERIALS Materials that can catch fire and burn are considered combustible. Any material that is made of, or faced with, wood, wood pulp, paper, plastic or any other material that can catch fire and burn is considered combustible. - Page 10 An appropriate length of 11/2” - 2” PVC pipe installed at the base of the enclosure which would run down and out, is recommended. These openings must be checked for blockage periodically. ROUGH OPENING DIMENSIONS Dimension J-60-1 J-60-ST A (Width) 651/2” 703/4”...
- Page 11 The fire media must be installed according to these instructions. This fireplace must use only the fire media provided by European Home. An excessive amount of fire media may adversely affect the performance of the fireplace. WARNING: All previously applied loose material must be removed prior to reapplication.
-
Page 12: Gas Installation
GAS INSTALLATION Note The J Series Outdoor Gas Fireplace is shipped from the factory for use with natural gas. A kit to convert the fireplace to propane (LP) is available. The conversion must be performed by a qualified service person. Contact your local gas supplier. This product must be installed by a licensed plumber or gasfitter. - Page 13 GAS INSTALLATION PROPANE CYLINDER ENCLOSURE If you are planning to operate your J Series Outdoor Gas Fireplace using a propane cylinder, it must be placed in an enclosure that meets the following specifications: The floor of the enclosure must be located 2 inches (50 ) above the ground and must be non-combustible.
-
Page 14: Operating The Fireplace
OPERATING the FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING, smell all around the heater area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. -
Page 15: Maintenance
MAINTENANCE A qualified service agency should conduct an annual inspection and maintenance of your J Series Outdoor Gas Fireplace to keep it running safely. The following procedures should be performed only by a qualified service person. The gas supply should be turned off whenever a maintenance procedure is performed. All parts of the fireplace that are removed for servicing must be replaced prior to operation. -
Page 16: Parts List
PARTS LIST J SERIES OUTDOOR GAS FIREPLACE PARTS LIST Part Description Part Number Manual Spark Ignition (uses 1 AAA battery) REPL-JVF-GS-IGN-01 Gas Valve REPL-JVF-GS-GV-01 Pilot Assembly REPL-JVF-GS-PA-01 Cover Access Tool REPL-JVF-CP-JCT-01 NG Burner Orifice REPL-GS-OR-39 For replacement parts and customer service, please contact your local hearth products dealer. -
Page 17: Installation Record
The installer should complete the Customer Record and the Installer Record, below. This information is necessary for any contact with European Home Technical Support. The Customer Record remains with the customer and the Installer Record is kept by the installer. - Page 18 FIVE (5) YEARS from the date of original retail purchase. If a defect exists, European Home will, at its option, either (1) provide needed components using new or refurbished replacement parts or (2) exchange the product with one which is new or which has been manufactured from new or serviceable used parts and is at least functionally equivalent to the original product.
- Page 19 J-Series LP Conversion Guide Instructions for J-Series LP conversion This kit is to be used to convert the J-60-1 and J-60-ST models from natural gas to propane. It is not to be used to convert any other models. The conversion must be performed only by a qualified service person or agency.
- Page 20 APPENDIX B STOP! THIS CONVERSION MUST ONLY BE PERFORMED BY A QUALIFIED SERVICE AGENCY OR PERSON 6. Remove the Pilot Back Shield from the Pilot Tower. 1. Remove any burner media and the hearth panel from the fireplace. 2. Remove the six 3/8” nuts from the burner base and one #10 screw from the control panel and remove the burner assembly.
- Page 21 APPENDIX A APPENDIX B 10. Remove the #8 screws and air shutters from the burner 13. Before installing the burner base back into the fireplace inlet tubes. the burner must be connected to a propane supply cylinder and leak tested. Open the propane supply cylinder and apply a leak test solution to the Regulator/Hose and the 1/2”...
- Page 22 Designed and manufactured in the United States by: EUROPEAN HOME a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com IGJVF601M1-170405 Rev. B EuropeanHome.com J Series Outdoor Gas Fireplace...
