J S E R I E S
O u t d o o r · G a s · Fi r e p l a c e
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
--An LP cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Solid fuels shall not be burned in this appliance.
JVF-M2 Series Outdoor Gas Fireplace
WARNING: Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Read the
installation, operating, and maintenance
instructions thoroughly before installing or
servicing this equipment.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING: FOR OUTDOOR USE ONLY
This manual is available in Canadian French
upon request.
Report #
0284GF009S
1
Installation,
Operation,
and
Owner's Manual
JVF-60-M2-S
JVF-60-M2-ST
Gas Fireplaces
January 2019
IGM2S-190417
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for European Home J series
Summary of Contents for European Home J series
- Page 1 Installation, Operation, Owner’s Manual J S E R I E S JVF-60-M2-S JVF-60-M2-ST O u t d o o r · G a s · Fi r e p l a c e Gas Fireplaces WARNING: Improper installation, adjustment, WARNING: If the information in these alteration, service or maintenance can instructions is not followed exactly, a fire cause injury or property damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information Important Safety Information About Propane Specifications and Dimensions Clearances Installation Electric Installation Gas Installation Enclosing the Fireplace Framing Trim and Finish Operating the Fireplace Maintenance Installation Record Warranty Appendix A: LP Installation JVF-M2 Series Outdoor Gas Fireplace IGM2S-190417... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this gas appliance. Thank you for purchasing a J-M2 Series Outdoor Gas Fireplace by European Home. This fireplace has been designed to provide you with safe, trouble-free operation. -
Page 4: Important Safety Information About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS This gas fireplace is equipped at the factory for use with natural gas. If conversion to propane (LP) is desired, the optional factory-supplied conversion kit must be used. When using propane (LP), the gas supply cylinder to be used must be: 1) constructed and marked in accordance with the U.S. -
Page 5: Specifications And Dimensions
SPECIFICATIONS AND DIMENSIONS SPECIFICATIONS JVF-60-M2-S Model JVF-60-M2-ST Natural (Propane) Input Maximum Btu/hr 65,678 64,211 Input Minimum Btu/hr 49,901 48,308 in. w.c. 11.0 Maximum Supply Pressure 1.74 2.74 in. w.c. 10.25 Manifold Pressure Maximum 1.37 2.55 in. w.c. Manifold Pressure Minimum 0.87 Electrical Rating V AC... - Page 6 SPECIFICATIONS AND DIMENSIONS FIGURE 2: JVF-M2-60-S FIGURE 3: JVF-M2-60-ST JVF-60-M2-S JVF-60-M2-ST 695/8” 1769 (overall width 60” 1524 (viewable width) 491/4” 1251 (burner length) UNIT WEIGHT Pounds Kilograms 171/2” (viewable height) 81.6 71/2” (base to opening) 18” (overall depth) 28” (overall height) *overall width does NOT include the nailing flanges JVF-M2 Series Outdoor Gas Fireplace IGM2S-190417...
- Page 7 20180912_J_M2_Listing_Label_1-ST.indd 1 9/20/2018 9:45:13 AM A sample listing label image is shown above. A metal listing label is attached to every European Home fireplace and contains important certification information. The listing label must not be removed from the fireplace. JVF-M2 Series Outdoor Gas Fireplace...
- Page 8 SPECIFICATIONS AND DIMENSIONS WHEN ENCLOSING YOUR FIREPLACE THE USE OF NON-COMBUSTIBLE BUILDING MATERIALS IS REQUIRED. PLEASE READ AND UNDERSTAND THE FOLLOWING. COMBUSTIBLE MATERIALS Materials that can catch fire and burn are considered combustible. Any material that is made of, or faced with; wood, wood pulp, paper, plastic or any other material that can catch fire and burn is considered combustible.
-
Page 9: Clearances
CLEARANCES CLEARANCES TO COMBUSTIBLES MANTEL FIGURE 5: Clearances (Front Elevation View) FIGURE 6: Clearances (Plan / Top View) TRIM SIDEWALL Top of fireplace to ceiling of enclosure 4” Back of fireplace to back combustible wall 0” Side of fireplace opening to combustible trim 4.5”... -
Page 10: Installation
INSTALLATION LOCATING THE FIREPLACE When locating your J Series Outdoor Gas Fireplace, you must ensure that the proper clearances to combustible materials are maintained and your fireplace must be installed outdoors, NOT indoors. The fireplace may be installed unsheltered but wind may cause a flame outage and/or excessive sooting. -
Page 11: Electric Installation
ELECTRIC INSTALLATION Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. This appliance must be electrically grounded in accordance with local codes, or, in the absence of local codes, with either the National Electrical Code ANSI/NFPA 70, for installations in the U.S. or the Canadian Electrical Code, CSA C22. - Page 12 ELECTRIC INSTALLATION ELECTRIC INSTALLATION LED LIGHT SCHEMATIC 120V AC Outlet Power Supply VLM60W-12 Antenna Control Module LED Strip FIGURE 11: J-M2 LED Lighting Schematic Diagram JVF-M2 Series Outdoor Gas Fireplace IGM2S-190417...
-
Page 13: Gas Installation
GAS INSTALLATION Note The J Series Outdoor Gas Fireplace is shipped from the factory for use with natural gas. A kit to convert the fireplace to propane (LP) is available. The conversion must be performed by a qualified service person. Contact your local gas supplier. Installation guide located in Appendix A This product must be installed by a licensed plumber or gasfitter. - Page 14 GAS INSTALLATION PROPANE (LP) CYLINDER ENCLOSURE If you are planning to operate your J Series Outdoor Gas Fireplace using a portable propane cylinder, it must be placed in an enclosure that meets the following specifications: A) One side of the enclosure must be left open and a chain located 12 “ (30.5 )above the floor of the enclosure must span the opening to prevent the tank from tipping.
-
Page 15: Enclosing The Fireplace
INSTALLATION ENCLOSING THE FIREPLACE/FRAMING All enclosures for the J-M2 fireplace require an air inlet and an air outlet. These openings in the enclosure must allow for the free flow of air through the unit. The air inlet opening must be located on the same side of the fireplace as the gas control and should be located near the bottom of the fireplace. -
Page 16: Framing
INSTALLATION ROUGH OPENING / FRAMING A wall switch is included in a water-tight control box. Installation of the control box must be where children cannot reach for safety reasons. FIGURE 15 FIGURE 16 ROUGH OPENING DIMENSIONS While combustible framing is permitted, metal Dimension JVF-60-M2-S JVF-60-M2-ST... -
Page 17: Trim And Finish
INSTALLING THE WALL PANELS The J Series Outdoor Gas Fireplace is shipped with two stainless steel wall panels. One to cover the fireplace controls and one decorative. These panels have a metal stud protruding from the top end of the panel. - Page 18 INSTALLING THE FIRE MEDIA The J Series Outdoor Gas Fireplace is shipped with fire media which is to be installed on top of the burner. Be certain that the fire media does not cover the pilot burner as well as no media is between the glass panels and burners to prevent glass breakage.
- Page 19 TRIM and FINISH Colbalt Fireglass Carrara Pebbles Beach Stones with Driftwood Beach Stones JVF-M2 Series Outdoor Gas Fireplace IGM2S-190417...
-
Page 20: Operating The Fireplace
OPERATING the FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING, smell all around the heater area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. - Page 21 OPERATING the FIREPLACE USING THE LED LIGHT REMOTE The LED remote control comes with a battery installed. When using the LED remote control, point the remote at the control side of the fireplace. The eye which receives the signal is located on the control side of the fireplace.
-
Page 22: Maintenance
MAINTENANCE A qualified service agency should conduct an annual inspection and maintenance of your J Series Outdoor Gas Fireplace to keep it running safely. The following procedures should be performed only by a qualified service person. The gas supply should be turned off whenever a maintenance procedure is performed. All parts of the fireplace that are removed for servicing must be replaced prior to operation. - Page 23 MAINTENANCE JVF-M2 SERIES REPLACEMENT PARTS LIST Part Description Part Number 24” Connection Wire Repl-JVF-GS-CWC-01 72” 8 Pin Wiring Harness Repl-JVF-GS-MWH-01 AC Adapter Repl-JVF-GS-AC-ADAPTER Clear Glass (60-S only) (1 Piece) JVF-GLASS-S-CLEAR Clear Glass (60-ST only) (2 Pieces) JVF-GLASS-ST-CLEAR Control Module Repl-JVF-GS-CM-01 Frosted Glass (60-S only) (2 Pieces) JVF-GLASS-S-FROST Frosted Glass (60-ST only) (2 Pieces)
-
Page 24: Installation Record
The installer should complete the Customer Record and the Installer Record, below. This information is necessary for any contact with European Home Technical Support. The Customer Record remains with the customer and the Installer Record is kept by the installer. -
Page 25: Warranty
European Home Warranty The J Series Outdoor Gas Fireplace European Home warrants the gas controls and burner of the J Series Outdoor Gas Fireplace against defects in materials and workmanship for a period of TWO (2) YEAR from the date of original retail purchase. -
Page 26: Appendix A: Lp Installation
APPENDIX A INDEX WARNING This conversion kit shall be installed by a qualified service LP (PROPANE) CONVERSION agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the Authority having jurisdiction. If the information in these instructions is Applicable Models: not followed exactly, a fire, explosion or production of carbon JVF-60-M2-S... - Page 27 APPENDIX A INDEX STOP! THIS CONVERSION MUST ONLY BE PERFORMED BY A QUALIFIED SERVICE AGENCY OR PERSON 1. Remove any burner media and clean unit 8. Remove the six 3/8” nuts from the burner base. 2. Remove glass capture panels and optional wind guard 9.
- Page 28 APPENDIX A INDEX 12. To convert the Pilot from natural gas to propane, turn 16. Remove the #8 screws and air shutters from the burner the pilot barrel 1/4 turn counter clockwise with a 7/16” wrench. inlet tubes. Take care not to damage the metal orifice strip. 17.
- Page 29 APPENDIX A NOTES JVF-M2 Series Outdoor Gas Fireplace IGM2S-190417...
- Page 30 INDEX APPLIANCE LED 21 Certifications 7 Operating 20 Rating Label 7 LISTING LABEL 7 Enclosure 14 Pressures 5 CERTIFICATIONS Safety 4 Listing Label 7 CLEARANCES Combustibles 9 Mantel 9 MAINTENANCE 22 - 23 Burner 22 Cleaning 22 Fire Media 22 DIMENSIONS LED Lights 22 Clearances to Combustibles 9...
- Page 31 Designed and manufactured in the United States by: EUROPEAN HOME a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com JVF-M2 Series Outdoor Gas Fireplace IGM2S-190417...
