European Home VBM-NG-02 Installation, Operation And Owner's Manual

Vision gas burner module

Advertisement

GAS STONES WITH FUSION BASKET
Installation, Operation and Owner's Manual
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance. Installation and service
must be performed by a qualified installer,
service agency or the gas supplier.
Report #284-L-02c-5
1
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
Feb. 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBM-NG-02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for European Home VBM-NG-02

  • Page 1 GAS STONES WITH FUSION BASKET Installation, Operation and Owner’s Manual WHAT TO DO IF YOU SMELL GAS WARNING: If the information in these • Do not try to light any appliance. instructions is not followed exactly, a fire or explosion may result causing property •...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Specifications and Dimensions Before You Begin Fireplace Requirements Installing the Burner Gas Supply Stone Configuration Operating Instructions Maintenance Troubleshooting Parts List Warranty...
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION 1. This appliance must be installed only in a solid-fuel burning fireplace with a working flue and constructed of noncombustible material. 2. A fireplace screen must in place when the appliance is operating and must provide for the flow of combustion air.
  • Page 4 AVERTISSEMENT: Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque d’incindie ou d’explosion ou pour éviter tout dommage matériel, toute blessure ou la mort. Ne pas entreposer ni utilizer d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de tout autre appareil.
  • Page 5 Vision Gas Burner Module, Model VBM-NG-02 Vision Gas Burner Module, Model VBM-LP-02 This appliance is equipped for: Natural Gas/Gaz Naturel Propane Cet appareil est équipé pour: Input Rating Btu/hr 42,000 43,500 Debit Calorifique Min. Input (Btu/hr) 27,000 27,000 Puissance Minimum...
  • Page 6: Specifications And Dimensions

    SPECIFICATIONS and DIMENSIONS Natural Gas Propane (LP) Manifold Pressure: 4.0” (1.0 kPa) 10.0” ( 2.5 kPa) Maximum Supply Pressure: 7.0” (1.7 kPa) 13.0” (3.2 kPa) Minimum Supply Pressure: 4.0” (1.0 kPa) 11.0” (2.7 kPa) Orifice Size: 6 Port #55 DMS #48 DMS Canadian Efficiency P.4: High Fire Input:...
  • Page 7 SPECIFICATIONS and DIMENSIONS...
  • Page 8 SPECIFICATIONS and DIMENSIONS 0.75 0.75 22.50 3.00 Rear of Fireplace Room Premise gas supply should terminate within shaded area, shown on plan view, above.
  • Page 9: Before You Begin

    BEFORE YOU BEGIN Before starting the installation of your Gas Stones with Fusion Basket be sure to have the following tools and supplies: • Adjustable wrench • Phillips and straight-blade screwdrivers • Tape measure and framing square • Safety glasses and gloves •...
  • Page 10: Fireplace Requirements

    FIREPLACE REQUIREMENTS Your Gas Stones with Fusion Basket must sit fully inside your fireplace so that it Figure 1 properly drafts up the chimney flue. Be certain that the burner of your Gas Stones with Fusion Basket is behind the fireplace lintel.
  • Page 11 MANTEL CLEARANCES 12.0” 5.0” 10.0” 8.0” Top of existing fireplace opening Existing fireplace opening Figure 2a Combustible mantels may be no closer to the fireplace opening than the distances shown in the Figure 2a side view, above.
  • Page 12: Installing The Burner

    INSTALLING THE BURNER Place 4 AA batteries in the battery case and con- nect the battery case to the receiver as shown in Figure 3a. Ensure that the wiring is connected as shown in Figure 3b. RESET button Red-tipped Yellow-tipped Wire (TC) Wire (SW) RESET...
  • Page 13 After the gas supply has been connected, open the main supply and apply a soapy water solution to all the fittings to check for gas leaks. Never use a flame to test for leaks. If you are installing a propane burner, check that the air shutter (see Figure 5) is in the open position. Replace the burner in the burner module.
  • Page 14: Stone Configuration

    STONE CONFIGURATION The Gas Stones with Fusion Basket can be operated with, or without, the decorative stones and/or embers. The following is the recommended configuration. Slight differences in the placements are acceptable. When using the stones and embers, begin by placing one layer of the embers evenly over the entire burner top as shown in Figure 7.
  • Page 15 Figure 9 Next, place two large stones and three small stones on the burner as shown in Figure 9. Then place two medium and four small stones along the front edge of the burner as shown in Figure 10. Figure 10...
  • Page 16 Figure 11 Finally, place the remaining two large, one medium and three small stones on top as shown in Figure 11.
  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING! WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand.
  • Page 18 LIGHTING THE FIRE 1. STOP! Read the safety information above. 2. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand. 3. Push the OFF button on the remote control to insure the LARGE appliance is off.
  • Page 19 Note: The system shuts off the appliance completely if there is no change in the flame height for 5 days. Igniting the Appliance. Ensure the ON/OFF switch is in the ON position. On the remote control, simultaneously press and hold the OFF andÇbuttons. An acoustic signal indicates that the start sequence has begun.
  • Page 20: Maintenance

    MAINTENANCE A qualified service agency should conduct an annual inspection and maintenance of your Gas Stones with Fusion Basket, the fireplace, chimney, and the installation to keep it running safely. The following procedures should be performed only by a qualified service person. The gas supply should be turned off whenever a maintenance procedure is performed.
  • Page 21: Troubleshooting

    TROUBLESHOOTING OBSERVED PROBLEM: POSSIBLE CAUSE: REMEDY: A. No transmission (motor does not 1. Receiver must learn new code. 1. Reset system as above. turn) 2. Dead batteries. 2. Replace batteries. 3. The receiver is surrounded by 3. Change the position of the antenna. metal, reducing the transmission range.
  • Page 22 OBSERVED PROBLEM: POSSIBLE CAUSE: REMEDY: D. No pilot flame and control contin- 4. Over tightened thermocouple. 4. Replace valve and thermocouple inter- ues to spark rupter. 5. Receiver 5. Replace receiver and reprogram code as above. E. Pilot is lit and control continues 1.
  • Page 23: Parts List

    The flames should look like those in the picture above. PARTS LIST Burner Module, NG GSBM-NG-01 Burner Module, LP GSBM-LP-01 Stone Kit VPK-01 Pilot Assembly VPA-01 Fusion Basket VSB-01 For replacement parts and customer service, contact: EUROPEAN HOME +1 (781) 324-8383...
  • Page 24 PRODUCT INSTALLATION RECORD Installer: Please complete this form. Customer: Please retain this information. Purchased From Date of Purchase Installed By Date of Installation Fireplace Serial Number Fuel Type...
  • Page 25 NOTES...
  • Page 26 EUROPEAN HOME a division of Europa Ja, Inc. 376 Washington Street Suite 203 Malden, MA 02148 www.europeanhome.com rev. 160217...
