J S E R I E S
O u t d o o r · G a s · F i r e p l a c e
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
--An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Solid fuels shall not be burned in this appliance.
J Series Outdoor Gas Fireplace
WARNING: Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Read the
installation, operating, and maintenance
instructions thoroughly before installing or
servicing this equipment.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING: FOR OUTDOOR USE ONLY
Report # 0284GF009S
1
Installation,
Operation
and
Owner's Manual
J-60
J-60-ST
Gas Fireplaces
EuropeanHome.com
July 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J-60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for European Home J-60

Summary of Contents for European Home J-60

  • Page 1 Installation, Operation Owner’s Manual J S E R I E S J-60 J-60-ST O u t d o o r · G a s · F i r e p l a c e Gas Fireplaces WARNING: Improper installation, adjustment,...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Important Safety Information About Propane Specifications Clearances Installation Gas Installation Operating the Fireplace Maintenance Parts List Warranty Appendix A EuropeanHome.com J Series Outdoor Gas Fireplace...

  • Page 3: Important Safety Information

    Read these instructions carefully before installing or trying to operate this Vent Free decorative gas appliance. Thank you for purchasing a J Series Outdoor Gas Fireplace by European Home. This fireplace has been designed to provide you with safe, trouble-free operation.

  • Page 4: Important Safety Information About Propane

    IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS This gas fireplace is equipped at the factory for use with natural gas. If conversion to propane (LP) is desired, the optional factory-supplied conversion kit must be used. When using propane (LP), the gas supply cylinder to be used must be: 1) constructed and marked in accordance with the U.S.

  • Page 5: Specifications

    SPECIFICATIONS and DIMENSIONS SPECIFICATIONS Model J60, J60-ST Natural Propane Input Btu/hr 76,000 76,000 Minimum in. w.c. 7” w.c. Supply Pressure (NG) 1.74 kPa Minimum in. w.c. 11” w.c. Supply Pressure 2.74 kPa (LP) in. w.c. 6.3” w.c. Manifold Pressure (NG) 1.57 kPa in.
  • Page 6 SPECIFICATIONS and DIMENSIONS Dimension 651/8” Model J60 (single sided) 60” 491/4” 27” 171/2” 71/2” 18” Dimension J60-ST 651/8” Model J60-ST (see through) 60” 491/4” 27” 171/2” 71/2” 18” EuropeanHome.com J Series Outdoor Gas Fireplace...

  • Page 7: Clearances

    CLEARANCES CLEARANCES TO COMBUSTIBLES MANTEL TRIM Clearances (Front Elevation View) TRIM Clearances (Top Plan View) SIDEWALL 4” Top of fireplace to combustibles 0” Back of fireplace to back combustible wall 4.5” Side of fireplace opening to combustible trim 5.5” Fireplace opening to side wall in front of fireplace 0”...

  • Page 8: Installation

    INSTALLATION WHEN ENCLOSING YOUR FIREPLACE THE USE OF NON-COMBUSTIBLE BUILDING MATERIALS IS REQUIRED. PLEASE READ AND UNDERSTAND THE FOLLOWING. COMBUSTIBLE MATERIALS Materials that can catch fire and burn are considered combustible. Any material that is made of, or faced with, wood, wood pulp, paper, plastic or any other material that can catch fire and burn is considered combustible.
  • Page 9 INSTALLATION Any accumulated rain water will drain from a 7/8” opening in the center rear of the fireplace bottom. This opening must not be blocked. The water which runs through this opening will accumulate in the base of your enclosure and must be allowed to drain away from the enclosure. An appropriate length of 11/2” - 2” PVC pipe installed at the base of the enclosure which would run down and out, is recommended.

  • Page 10: Gas Installation

    GAS INSTALLATION Note The J Series Outdoor Gas Fireplace is shipped from the factory for use with natural gas. A kit to convert the fireplace to propane (LP) is available. The conversion must be performed by a qualified service person. Contact your local gas supplier. This product must be installed by a licensed plumber or gasfitter.
  • Page 11 GAS INSTALLATION PROPANE CYLINDER ENCLOSURE If you are planning to operate your J Series Outdoor Gas Fireplace using a propane cylinder, it must be placed in an enclosure that meets the following specifications: The floor of the enclosure must be located 2 inches (50 ) above the ground and must be non-combustible.

  • Page 12: Operating The Fireplace

    OPERATING the FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING, smell all around the heater area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

  • Page 13: Maintenance

    MAINTENANCE A qualified service agency should conduct an annual inspection and maintenance of your J Series Outdoor Gas Fireplace to keep it running safely. The following procedures should be performed only by a qualified service person. The gas supply should be turned off whenever a maintenance procedure is performed. All parts of the fireplace that are removed for servicing must be replaced prior to operation.

  • Page 14: Parts List

    PARTS LIST Replacement Parts List Electronic Ignition (takes 1 AAA battery) Gas Valve Pilot Assembly Main Burner Orifice J SERIES OUTDOOR GAS FIREPLACE PARTS LIST Gas Valve (Manual) REPL-JVF-GS-GV-01 Electronic Ignition REPL-JVF-GS-IM-01 Pilot Assembly REPL-JVF-GS-PA-01 For replacement parts and customer service, please contact your local hearth products dealer.
  • Page 15 INSTALLATION RECORD The installer should complete the form below that describes the details of the installation. Having this written record of installation information available will greatly expedite troubleshooting should any problems arise with your fireplace. The installer should keep a duplicate of this form for their records as well. DATE PURCHASED: ______________________________________ DEALER:...
  • Page 16 J Series Outdoor Gas Fireplace and cover against defects in materials and workmanship for a period of FIVE (5) YEARS from the date of original retail purchase. If a defect exists, European Home will, at its option, either (1) provide needed components using new or refurbished replacement parts or (2) exchange the product with one which is new or which has been manufactured from new or serviceable used parts and is at least functionally equivalent to the original product.
  • Page 17 APPENDIX A NOTES EuropeanHome.com J Series Outdoor Gas Fireplace...
  • Page 18 EUROPEAN HOME a division of Europa Ja, Inc. 376 Washington Street Suite 203 Malden, MA 02148 www.europeanhome.com IGJVF-150713 EuropeanHome.com J Series Outdoor Gas Fireplace...
