System Configuration P7; Communication Specification P7 - SMC Networks ITV1000-PR Series Operation Manual

System configuration
This product is connected to the field bus (PROFIBUS DP) as a slave.
Master
DP equipment
< Example of system configuration >
Communication specification
Item
Protocol
Version
Note
Baud rate
GSD File
Occupied IN
area
OUT
DIAG 56bit(7Byte)
Communication
data resolution
Output pressure
condition
communication
error
Address setting
Terminator
Note) Baud rate relates to communication distance.
PROFIBUS DP
Slave1
・
DP equipment
Specifications
PROFIBUS DP
DP-V0
9.6k/19.2k/45.45k/93.75k/
187.5k/500k/1.5M/3M/6M/12M bps
GSD(SMC_1412.GSD)
16bit(2Byte)
16bit(2Byte)
12bit (4096 resolution)
Clear
at (Output pressure become zero.)
Switch/ Software setting
Built in (switch setting)
Power SUP.(DC24V)
Slave2
・
The compress
air is supplied
from the first
side.
- 7 -
The pressure
proportional
to the signal
on the second
side is
obtained.
Remarks
Setting by master
th
Lower 2 bit of 7
Refer P8
Refer P8
byte
