4. Select Apply. If PPP or PPPoE is selected as the Interface Mode, you will be taken to the
PPP page after selecting Apply. Here you will need to select the type of authentication
needed, authentication passwords, and the Address Type. In most cases, you will want the
Address Type to be Negotiated. Select Apply when all the information is complete.
A CLI
CCESS THE
If needed, you can access the CLI from a Telnet or SSH client. To access the CLI using a Telnet
or SSH client, follow these steps:
1. Connect the unit to your PC, using an Ethernet cable connected to one of the Ethernet ports
(Ethernet 1, 2, 3, or 4) on the rear of the unit.
2. Use a Telnet or SSH client to connect to 10.10.10.1. If you have changed your unit's IP
address, you will need to enter that address.
3. For SSH, log into the unit using the default login (admin) and password (password). For
Telnet, only the default password (password) is required.
4. Enter enable at the > prompt and enter the enable password when prompted. The default
password is password.
C L
HANGE OGIN
1. To modify the user accounts and passwords, from the (config)# prompt, enter the command
username <username> password <password> to modify current user accounts or create a
new one.
2. To modify the Enable mode password, from the (config)# prompt, enter the command
enable password <password>.
3. To modify the Telnet password, from the (config)# prompt, enter the command line telnet 0
4 and then press <Enter>. Enter the command password <password>.
4. Enter do write to save the current configuration.
ADSL
Default
Switch
F D
ACTORY EFAULT
• If the factory default switch (shown in the illustration above) is pressed during bootup (while
the STAT LED is flashing green), the unit will stay in bootstrap mode (the STAT LED will turn
solid amber when the unit is in bootstrap mode). Since the unit has no serial port, Telnet has
been built into the boot code. The default IP address is 10.10.10.1.
• If the factory default switch is pressed and held for 5 seconds after boot, the switch ports
1 through 4 on the NetVanta 3100 Series routers will default to 10.10.10.1 and all firewall
access policies will be removed from that interface.
2
P
ASSWORDS
1
S
WITCH
Support - Phone: 888-423-8726, Email: support@adtran.com
2 3 4
