- Page 1 Multifunction Gigabit Managed Switch with PoE support (IEEE802.3af) for IP Video Surveillance Systems PSW-1G4F-Box Operating Manual Version 1...
- Page 2 Warning! Power supply elements are under high voltage. It is strictly forbidden to touch conducting elements of the power supply unit under voltage. When connecting a computer to the switch, remove PoE jumpers for this port. SFP port operates only at 1000 Mbps. Fast Ethernet SFP modules will not operate.
-
Page 3: Table Of Contents
Table of contents 1 Purpose ........................4 2 Features ........................5 3 Description ......................7 3.1 Appearance ......................7 3.2 Cabinet ........................ 8 3.3 Optical distribution frame ..................8 3.4 Switch board and power supply units ..............9 3.4.1 PoE jumpers ....................10 3.4.2 230VAC power supply backup jumpers ............ -
Page 4: Purpose
1 Purpose PSW-1G4F-Box is a multifunction gigabit outdoor managed switch used for the construction of IP video surveillance networks. Figure 1 - PSW-1G4F-Box connection scheme... -
Page 5: Features
The switch may supply PoE to any camera compliant with IEEE802.3af standard. Power supply of camera housings via PoE During operation with TFortis TH camera housings the switch uses a standard twisted pair to power both the camera (IEEE802.3af) and the camera housing... - Page 6 Cold start For safe and guaranteed start of video cameras in freezing weather, TFortis TH equipment allows for preheating of camera housings. Automatic cameras restart in case of hanging The switch controls operation of the camera.
-
Page 7: Description
3 Description 3.1 Appearance Figure 3.1.1 - PSW-1G4F-Box - external appearance Figure 3.1.2 - PSW-1G4F-Box - interior... -
Page 8: Cabinet
3.2 Cabinet Cabinet features 100% corrosion protection due to glass-filled polycarbonate IK10 impact protection rating due to fiber glass reinforcement Dust and moisture protection – IP66. Fire resistance – UL94-5VA Electrical insulation – 1500VDC UV resistance – UL 508. 3.3 Optical distribution frame Figure 3.3 - Optical distribution frame... -
Page 9: Switch Board And Power Supply Units
3.4 Switch board and power supply units Figure 3.4.1 - Switch board and power supply units Figure 3.4.2 - Layout of components inside PSW -1G4F-Box... -
Page 10: Poe Jumpers
3.4.1 PoE jumpers PSW-1G4F-Box switch supports IEEE802.3af and Passive PoE power supply. Selection of power supply options is specified by the jumper configuration (Table 3.4.1). Power is supplied via pairs 1, 2 and 3, 6 over data (Option A) or by free pairs 4, 5 and 7, 8 (Option B). - Page 11 Figure 3.4.3 - Power supply scheme over PoE for different variants.
-
Page 12: 230Vac Power Supply Backup Jumpers
3.4.2 230VAC power supply backup jumpers PSW-1G4F-Box switches have two power supply units. The left PSU is designed to supply power to the switch and video cameras over PoE. The right PSU has two operating modes selected by RES_PWR jumper according to Table 3.4.2. -
Page 13: Poe Indicators
3.4.7 PoE indicators The PoE A indicator is ON when power is supplied over data (pairs 1, 2 and 3, 6). The PoE B indicator is ON when power is supplied by free pairs (pairs 4, 5 and 7, 8). 3.4.8 LINK indicators Blinking of LINK indicators show that data are transmitted via the corresponding port. - Page 14 alarm message to be sent to the server via SNMP Traps, SMTP or Syslog protocols (see detailed information in the Configuration Manual). Figure 3.6.1 - Tamper sensor on the switch cover Figure 3.6.2 - Tamper sensor on the switch enclosure...
-
Page 15: Integrated Lightning Protection
3.7 Integrated lightning protection PSW-1G4F-Box switch has built-in lightning protection modules that protect Ethernet ports and ~230VAC power circuits from common-mode and differential electromagnetic interferences. The switches are resistant to powerful microsecond pulse interferences according to GOST R 51317.4.5 standard as per Table 3.7.1 with performance criteria B (temporary disruption of performance or functioning with further recovery without operator's intervention). -
Page 16: Automatic Circuit Breaker
3.10.1 Cold start The most critical moment in camera operation is its start at low temperature. Cold start may result in failure of an expensive camera. To prevent that, TFortis TH camera housings of PSW-1G4F-Box switch have a preliminary heating function. -
Page 17: Cable Tester
Video camera restart using Link signal The switch continuously (once a minute) monitors the Link signal from the IP camera. If the switch fails to detect the Link signal, then a one-minute timer is started, and after that the connection is monitored again. If the Link signal does not appear, the switch removes power for 10 seconds and supplies it again, rebooting the camera. -
Page 18: Remote Camera Polling
By default, VCT operates on an average algorithm and does not take into account the specific features of a particular cable, which can affect the accuracy of the measurement. To improve the accuracy of the cable tester, it is recommended to calibrate it. -
Page 19: Operating Conditions
supply voltage ~ 230VAC (from 187V up to 253V); maximum power consumption – not more than 120W; Design dimensions 300х400х150 mm maximum weight – 3 kg environmental protection rating IP66; impact protection rating IK10 ... -
Page 20: Ip Address Setting
6.2 IP address setting All software functions of the switch can be managed, configured and monitored using the built-in web interface and Telnet. Below is the description of web-based configuration. Configuration via Telnet (see the Configuration Manual). The switch can be managed from remote stations at any point of the network via a standard web browser (for example, Microsoft Internet Explorer). -
Page 21: Setting Poe On Ports
To solve this problem, use the Comfort Start function. To do this, go to the Comfort Start section on the Special Function tab and enable the option. By default, it is OFF. The function is available only with TFortis TH camera housings. -
Page 22: Activation Of Redundancy Protocols
6.6 Activation of redundancy protocols If you connect the switches into a ring, then you need to enable the RSTP protocol. Otherwise, if there are alternative paths, your network will not be functional. By default, RSTP is turned off. 7 Installation of the switch 7.1 Installation of the cabinet on the wall The cabinet has four attachment points that do not contact the interior. -
Page 23: Installation Of The Cabinet On Lamp Posts
Drilling of the housing will lead of loss of the switch integrity and, as a result, loss of product warranty. 7.1 Installation of the cabinet on poles To mount the cabinet on the pole, use TFortis-1 Attachment Set for square and round posts. Figure 7.2 - TFortis-1 Attachment Set. -
Page 24: Power Supply Connection
strength member, metal supports with screws are used. Optical fibers are laid in a splice cassette for 32 shrinkable plastic sleeves. Welded pigtails are connected to SC adapters located on the adapter plane. Then the adapters are connected to SFP modules with the use of optical patch cords. It is allowed to connect the pigtails directly to SFP without any unnecessary connections. -
Page 25: Camera Connection
Figure 7.4.2 - Connection from various power supply sources For ease of maintenance the automatic circuit breaker is included in the scope of supply. Grounding of the switch is mandatory. Grounding resistant should not exceed 4 Ohm. 7.5 Camera connection Camera connection recommendations: 1. -
Page 26: Manufacturer's Warranty
RJ-45 RJ-45 White Orange White orange Orange Orange White Green White Green Blue Blue White Blue White Blue Green Green White Brown White Brown Brown Brown Figure 7.5 - Standard cable separation. 8 Manufacturer's warranty The warranty period for the switch is 3 years from the date of sale. Only a complete switch is accepted for servicing and repair. -
Page 27: Technical Support
Email at tfortis@fort-telecom.ru All technical documents are available at: https://tfortis.com/support/dokumentaciya-na-produkciyu/ Schedule Power consumption calculation Power consumption of TFortis PSW switch is calculated by the following formula For the switch itself power consumption is not more than 5W. - Page 28 Example It is required to calculate power consumption of TFortis PSW-2G4F-Box switch with three AV1310 cameras with TFortis TH-02 camera housings connected to it. Вт ...
