Operation Manual
PSW-2G+
Multifunction Gigabit Managed Switch
with PoE+ (IEEE802.3at)
for IP- video surveillance systems
Version 6
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSW-2G+ and is the answer not in the manual?

Questions and answers

Related Manuals for TFortis PSW-2G+

Summary of Contents for TFortis PSW-2G+

  • Page 1 Operation Manual PSW-2G+ Multifunction Gigabit Managed Switch with PoE+ (IEEE802.3at) for IP- video surveillance systems Version 6...
  • Page 2 Touching conducting components of active power supply units is forbidden. ATTENTION! When TFortis camera housings connected, set mode PoE_B = Passive via the WEB-interface. By default, PoE_B = Auto. ATTENTION! If mode PoE_B = Passive is active at the port, connect computer to it only by 4-wire (2 paired) Ethernet cable.

  • Page 3: Table Of Contents

    Table of Contents 1. Designation ..................4 2. Description ..................6 2.1. Appearance .................. 6 2.2. Element arrangement ............... 8 2.3. Power Supply over PoE ............9 2.4. Optical Distribution Frame ............11 2.5. Tamper sensor ............... 11 2.6. Lightning protection ..............12 2.7.

  • Page 4: Designation

    1. Designation Device PSW-2G+ is an outdoor Multifunction Gigabit Managed Switch with built-in optical distribution frame. Designed for networking of IP- video surveillance systems. Figure 1. Connection diagram for the PSW-2G+ Weatherproof version The body of the device is made of a techno-polymer that is resistant to severe operating conditions.
  • Page 5 Power supply for Camera housings over PoE Switch operating with TFortis TH camera housings powers both video camera and Camera housing via PoE (up to 30W per port). Built-in Optical Distribution Frame Presence of the Optical Distribution Frame allows distributing optics inside the device and connecting it to SFP modules.

  • Page 6: Description

    2. Description 2.1. Appearance Figure 2.1-1. PSW-2G+ outside view Figure 2.1-2. PSW-2G+ inside appearance...
  • Page 7 Figure 2.1-3. PSW-2G+ disassembled...

  • Page 8: Element Arrangement

    2.2. Element arrangement Figure 2.2. Element arrangement of the PSW-2G+...

  • Page 9: Power Supply Over Poe

    During normal operation of the processor, a CPU indicator must light intermittently with a frequency of 2s. (1 sec. - on, 1 sec. - off.) DEFAULT Indicator is on, when the device is in factory settings (IP 192.168.0.1). 2.3. Power Supply over PoE The switch PSW-2G+ supports power supply via double PoE+ (IEEE 802.3at), due to which it became possible to power any PoE-video camera over simple Ethernet cable.
  • Page 10 If you use TFortis TH camera housing, then it is necessary to set the power according to mode B to the Passive PoE mode via the WEB interface on the Port Settings tab. In this case, the video camera will be powered according to mode A and the camera housing will be powered according to mode B.

  • Page 11: Optical Distribution Frame

    2.4. Optical Distribution Frame Cable fixing elements Cover Places for optic cable fastening Plate for adapters Columns for fastening optic cable string (SC – 8 pcs.) Splice-cassette (shrinkable plastic sleeves-16 pcs.) ODF front panel (SC – 8 pcs.) Places fastening optic cable Figure 2.4.

  • Page 12: Lightning Protection

    Figure 2.5-1. Tamper sensor on the board Figure 2.5-2. The door of the tamper sensor on the unit cover IMPORTANT! Make sure that you correctly orient the cover of the unit when you close it. The detector should fall between tamper sensor beads. 2.6.
  • Page 13 Table 2.6-1. Degree of rigidity according to the Port Voltage pulse value, kW + 10% table 1 GOST R 51317.4.5 Power lines of the switch “wire- wire” Power lines of the switch “wire- ground” Symmetrical communication lines of the switch “wire-ground” Table 2.6-2.

  • Page 14: Additional Functions

    Precisely a cold start can cause the failure of an expensive video camera. To avoid such cases, unit PSW-2G+ is implemented with preheating of TFortis TH camera housings. The essence of it is that after power is applied to the unit, initially will be powered heating elements of camera housings, and only then in 1 hour, the video camera itself.

  • Page 15: Diagnostic Functions

    address of your video camera. Make sure your video camera is responding to the PING (see diagnostic functions section). Video camera restart when reducing the flow from the camera The PSW-2G+ switch constantly controls traffic level (intensity) from the camera. If the activity falls below the set level the switch restarts the camera by removing power from the PoE.

  • Page 16: Technical Parameters

    Technical parameters Gigabit Ethernet Ports • 1000Base-X with SFP connector; • Number of ports - 2; Fast Ethernet Ports • 10/100Base-Tx with RJ-45 connector; • number of ports - 4; • supports Auto-MDIX for the port 10/100Base-Tx; • supports flow control of IEEE 802.3x; •...

  • Page 17: Presetting

    The switch PSW-2G+ maintains declared parameters at storage temperatures from -55C to +50C (-67 to 122F). 5. Presetting 5.1. Restore switch to Factory Settings Before starting work, put the PSW-2G+ switch into the default settings. For this, you should press and hold DEFAULT button until DEFAULT indicator lights up.

  • Page 18: Setting Up Username And Password

    A (pairs 1,2 and 3,6) or by option B (pairs 4,5 and 7,8). If you want to connect a PoE video camera installed into the TFortis TH camera housing, you must set the PoE_A = Auto, PoE_B = Passive via the WEB interface on the Port Settings tab.

  • Page 19: Enabling Backup Protocols

    TFortis TH camera housing. IMPORTANT! When this option is enabled, after the power is applied to the switch, the cameras will only turn on after time of Soft Start Time. To force the cameras to turn on, click on Manual Start.

  • Page 20: Optic Connection

    6.2 Optic connection Inside the PSW-2G+ is installed Optical Distribution Frame. Optical cable is put into large cable glands that are on the lower tier of the unit. The optical cable is attached to the metal base of the distribution frame using nylon ties or metal clamps.

  • Page 21: Connection Of Video Cameras

    The PSW-2G+ has 54V DC backup power. The supply cable is brought into the unit through the cable gland and connected to the terminal block on the switch circuit board. Calculation of the cable cross-section is based on the maximum consumption that does not exceed 250W. IMPORTANT! The switch can be operated without a backup power supply.
  • Page 22 • due to non-compliance with the rules of connection and operation, as well as non-compliance of power specified in the operating manual; • due to force majeure, third party action and other reasons that doesn’t depend on manufacturer.
