TFortis PSW-1-45-WiFi Operation Manual

Multifunctional unmanaged switch for ip video surveillance systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Multifunctional Unmanaged Switch
for IP Video Surveillance Systems
Power supply elements are under high voltage. It is
strictly forbidden to touch conducting elements of
the power supply unit under voltage.
Before connecting a laptop to port 5 of the switch,
!
put Passive PoE jumpers into the OFF position.
For effective lightning protection the following is
required:
Operation Manual
PSW-1-45-WiFi
Version 2
• proper grounding made according to the
Electrical Code;
• a shielded twisted pair with shielded RJ45
connectors;
• minimum length of the twisted pair and power
supply cables.
1

Advertisement

Table of Contents
loading

Related Manuals for TFortis PSW-1-45-WiFi

Summary of Contents for TFortis PSW-1-45-WiFi

  • Page 1 Operation Manual PSW-1-45-WiFi Multifunctional Unmanaged Switch for IP Video Surveillance Systems Version 2 Power supply elements are under high voltage. It is strictly forbidden to touch conducting elements of the power supply unit under voltage. Before connecting a laptop to port 5 of the switch, put Passive PoE jumpers into the OFF position.

  • Page 2: Table Of Contents

    5.1. Unit mounting ................. 10 5.1.1. Wall mounting ................10 5.1.2. Mounting on the pole ............... 11 5.1.3. Installation into TFortis CrossBox cabinet ........ 11 5.2. Power supply connection ............... 12 5.3. Connecting the cameras and access point ........12...

  • Page 3: Designation

    1. Designation PSW-1-45-WiFi switch is an unmanaged outdoor Fast Ethernet switch used for the construction of IP video surveillance networks. 220 VAC 10/100Base-Tx 10/100Base-TX + PoE Figure 1-1. PSW-1-45-WiFi switch, connection over twisted pair 220 VAC 10/100Base-Tx + PoE 24V 10/100Base-TX + PoE Figure 1-2.
  • Page 4 Weatherproof design The switch body is made of technopolymer resistant to severe operating conditions. Dust and moisture protection casing IP66. Operation in extreme temperatures The switch comprises industrial hardware components with a wide range of operating temperatures. Application of industrial SFP modules will ensure normal operation in the temperature range from –55°C to 65°* (-67 to 149F)*.

  • Page 5: Description

    2. Description 2.1. Appearance Figure 2.1-1. PSW-1-45-WiFi switch, exterior view Figure 2.1-2. PSW-1-45-WiFi switch, interior view (circuit breakers are not included)

  • Page 6: Components Layout

    2.2. Components layout Figure 2.2. Layout of components inside PSW-1-45-WiFi switch During normal processor operation, CPU indicator should blink in 2-second intervals (1 second ON, 1 second OFF).

  • Page 7: Poe Power Supply

    2.3. PoE power supply PSW-1-45-WiFi switch supports the following types of power supply: • IEEE802.3af power supply for ports 1 to 4, • Passive PoE 24V (pairs 4,5 and 7,8) for port 5. Passive PoE on port 5 is activated by the jumper. Before connecting a laptop to port 5, put Passive PoE jumpers into the OFF position.

  • Page 8: Restarting Cameras In Case Of Hanging

    ~246V. 2.5. Restarting cameras in case of hanging PSW-1-45-WiFi switch continuously monitors traffic intensity of the camera. If network activity is lost, the switch will reboot the camera by disconnecting PoE power supply. This function is activated by a jumper for each particular...

  • Page 9: Technical Parameters

    – 6-12 mm cable – 2 glands Reliability • meantime between failures – at least 50 000 hours (5-7 years). 4. Operating conditions PSW-1-45-WiFi switch is designed for 24/7 outdoor operation at the ambient temperatures from –55 to +65C* (-67 to 149 F)*.

  • Page 10: Installation

    *The maximum temperature depends on the load (see diagram) Note 4.1. PSW-1-45-WiFi switch maintains declared parameters at storage temperatures from -55 C to +50 C (-67 to 122 F). 5. Installation 5.1. Unit mounting 5.1.1. Wall mounting The housing has four attachment points at the edges. Marking of the attachment points is shown in Figure 5.1.1.

  • Page 11: Mounting On The Pole

    5.1.2. Mounting on the pole To install PSW-1-45-WiFi switch on the pole, use TFortis mounting panel. Figure 5.1.2. Mounting the switch on the pole 5.1.3. Installation into TFortis CrossBox cabinet TFortis PSW-1-45-WiFi switches have a hermetically sealed housing of technopolymer providing IP66 protection rating. This ensures safe outdoor installation without the need for an additional metal enclosure.

  • Page 12: Power Supply Connection

    5.2. Power supply connection PSW-1-45-WiFi switch is connected to 220V AC power supply. Power supply cable is pulled into the unit trough a cable gland and is connected to the power supply terminal block either directly or via a circuit breaker assembly.

  • Page 13: Manufacturer's Warranty

    6. Manufacturer's warranty The warranty period for the switch is 36 months from the date of sale. Only a complete switch is accepted for servicing and repair. Warranty shall not apply in the following cases: • if the warranty period has expired; •...
