7.5 Technical Parameters of Cellular Module

Cellular module
LTE parameters
WCDMA parameters
GPRS/EDGE parameters
Antenna Requirements
VSWR – <2:1 (Antenna input impedance response as function of frequency. This shows
the antenna resonances and its bandwidth).
SMA – 50
For good diversity performance, the primary and secondary antennas should have dif-
ferent polarizations.
LUCOM GmbH — Flößaustr. 22a — 90763 Fürth — Tel.: +49 911/ 957 606 00 — E-Mail: info@lucom.de — www.lucom.de
LTE FDD Cat.4
Bit rate: 150 Mbps (DL) / 50 Mbps (UL)
Supported frequencies: B20 (800 MHz), B8 (900 MHz), B3
(1800 MHz), B1 (2100 MHz), B7 (2600 MHz)
Transmit power: 23 2.7 dBm
Bit rate: 42.0 Mbps (DL) / 5.76 Mbps (UL)
Supported frequencies: B8 (900 MHz), B1 (2100 MHz)
Transmit power: 24+1/-3 dBm
GPRS bit rate: 85.6 kbps (DL) / 85.6 kbps (UL)
EDGE bit rate: 236.8 kbps (DL) / 236.8 kbps (UL)
GPRS multislot class 10, EDGE multislot class 12
Supported frequencies: 900 MHz, 1800 MHz
GSM900 transmit power: 33 2 dBm
GSM1800 transmit power: 30 2 dBm
Table 9: Technical parameters of cellular module
