O P E R A T I N G I N S T R U C T I O N S
CDB620
Connectivity

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDB620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SICK CDB620

Summary of Contents for SICK CDB620

  • Page 1 O P E R A T I N G I N S T R U C T I O N S CDB620 Connectivity...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Technical data..................21 Dimensional drawing................Accessories..................24 Appendix..................... 25 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...
  • Page 4 CONTENTS 11.1 EU declaration of conformity/Certificates..........11.2 UL conformity.................... O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 5: About This Document

    … highlights useful tips and recommendations as well as information for efficient and trouble-free operation. 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 6: Further Information

    Other publications related to the devices described here • Publications dealing with accessories O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 7: Safety Information

    8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 8: Modifications And Conversions

    Knowledge of the software and hardware environment for the ■ particular application O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 9: Product Description

    ON: Connected to GND of the ID sensor • OFF: Volt-free 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...
  • Page 10 ID sensor (via CMC600) is activated Out 1 The CMC600 module is a prerequisite. O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 11: Transport And Storage

    For storage periods of longer than 3 months, check the general condition of all components and packaging on a regular basis. 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 12: Mounting

    For installation and commissioning of the optional CMC600, refer to the CMC600 operating instructions at www.sick.com. O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK...

  • Page 13: Electrical Installation

    The connection module can be used to ground the device. 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...
  • Page 14 Grounding point 2 Closed current loop with equalizing currents via cable shield O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...
  • Page 15 Within the islands, a stable equipotential bonding prevents equalizing currents on the cable shields. 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 16: Wiring Of The Connection Module

    CAN bus: If the connection module is located at the end of the bus, connect a termination resistor to switch S 2. O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK...

  • Page 17: Terminal Assignment

    Figure 4: Schematic: Structure of a CAN sensor network 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 18: Pin Assignment

    Table 3: Male connector, M12, 5-pin, A-coded Signal Screen CAN H CAN L O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 19: Maintenance

    Do not use cleaning agents. 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 20: Troubleshooting

    SICK AG. Interruptions or modifications to the device by the customer will invalid‐ ate any warranty claims against SICK AG. O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK...

  • Page 21: Technical Data

    Operation: –35 °C ... +40 °C Warehouse: –35 °C ... +70 °C 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 22: Dimensional Drawing

    Figure 8: Device dimensions; unit mm (inch), decimal separator: point Cable gland D-Sub female connector O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...
  • Page 23 Figure 10: Device dimensions; unit mm (inch), decimal separator: point Cable gland D-Sub female connector 8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...

  • Page 24: Accessories

    Accessories and where applicable mounting information can be found online at: • www.sick.com/CDB O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK Subject to change without notice...

  • Page 25: Appendix

    8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620 Subject to change without notice...
