3.5 External Label Roll Mount Installation (Option)
1.
Attach an external
paper roll mount on the
bottom of the printer.
3.
Open the printer's top
cover and separate the
media holders. Then
feeds the media from
the rear external label
entrance chute.
2.
Insert a 3" label spindle into
a paper roll. And install it on
the external paper roll
mount.
4.
Disengage the top cover
support and close the top
cover gently.Use software to
make calibration (Please
refer to chpter 4 and 5.)
11
