Troubleshooting

• If the Magic Sat Easy has not found the satellite after a complete search, check the
following:
a) Is the view towards the South free from any obstacle?
b) Is the place you are at within the reception area of the satellite you have chosen?
c) Is the cable connecting the LNB to the antenna firmly fastened? It could have been
ripped off or come loose because of contact with an unexpected obstacle.
d) Are all the connections on the Control Box properly set up?
• If the antenna has stopped after performing tracking, but neither messages nor images
appear on the screen:
a) Have you switched your receiver on ?
b) Have you switched your TV set on ?
c) Have you selected the right satellite ? Make sure that the services you wish to
receive are really available on the required satellite.
• If the control board does not turn on when you press the switch-on button, check the
following:
a) Are the RED and BLACK cables properly connected to the battery? The RED cable
must be on the + pole, the BLACK cable on the – pole
b) Should you have mixed up the cables, first disconnect them, replace the safety fuse
on the bottom of the CONTROL BOX using a similar one (5 A), then re-connect the
RED and BLACK cables properly to the battery.
c) Is the engine on your vehicle running? Turn it off, since this means the safety
system which keeps the antenna down is operating.
SPECIFICATIONS
Search system
Satellites which can be set
Extensions
MISCELLANEA
Power supply
Absorbed current
Current in stand-by
Fuse
Dimensions
Weight
18
Troubleshooting

Technical specifications

Fully automatic, NID recognition according to the DVB-SI
EN 300 468 specifications with DVBS2 tuner.
7
USB 1.0 Port
Control board
12Vdc –20 +30 %
5 A max.
< 5 mA
5 A
160 x 187 x 58 mm (control box)
120 x 35 x 80 mm (control board)
< 1 kg (control box and control board)
< 17 kg (outside driving unit)
Magic Sat Easy Vers. 003
