Assembly instructions
16) Connect the grey cable (motors) to the MOTOR UNIT connector and the white
coaxial cable (antenna) to the LNB connector of the Control Box.
17) Connect the Receiver to the RECEIVER connector (Fig. 16). You can connect any
satellite receiver, either digital or analog.
18) Connect the BLACK cable of the Control Box to the NEGATIVE POLE of the
vehicle 12 Volt Battery, and the RED cable to the POSITIVE POLE + (remember
not to mix the + and - poles up), using 2 cables of a cross section of 2.5
19) The GREEN safety cable of the Control Unit must be connected to the consensus
of the vehicle startup console (in many cases such consensus is located on Pin 15
in the main terminal board). In this way, whenever the motor is started, this cable
receives a positive + 12 Vdc voltage, which will automatically lower the antenna and
lock all functions of the Control Unit simultaneously (Fig.15).
the alternator) can give rise to equipment malfunction and/or damage resulting in loss of
the warranty.
